Page 889 of 4801

NISSAN TEANA 2014 Service Manual UNLOCK SENSORDLK-121 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I J L M A B DLK N O P Is the inspection result normal? YES >> Inspection End. NO >> Replace front lock assembly LH. Refer to DLK-203, "F

Page 890 of 4801

NISSAN TEANA 2014 Service Manual DLK-122 < DTC/CIRCUIT DIAGNOSIS > TRUNK LID OPENER SWITCH TRUNK LID OPENER SWITCH DescriptionINFOID:0000000009461853 Transmits trunk lid open signal to BCM. Component Function CheckINFOID:00000000094

Page 891 of 4801

NISSAN TEANA 2014 Service Manual TRUNK LID OPENER SWITCHDLK-123 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I J L M A B DLK N O P YES >> GO TO 3 NO >> Repair harness or connector. 3.CHECK TRUNK LID OPENER SWITCH GROUND CIRCUIT Check co

Page 892 of 4801

NISSAN TEANA 2014 Service Manual DLK-124 < DTC/CIRCUIT DIAGNOSIS > TRUNK LID OPENER CANCEL SWITCH TRUNK LID OPENER CANCEL SWITCH DescriptionINFOID:0000000009461857 Cancels trunk lid open operation. Component Function CheckINFOID:000

Page 893 of 4801

NISSAN TEANA 2014 Service Manual TRUNK LID OPENER CANCEL SWITCHDLK-125 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I J L M A B DLK N O P Is the inspection result normal? YES >> GO TO 3 NO >> Repair harness or connector. 3.CHECK TRUNK L

Page 894 of 4801

NISSAN TEANA 2014 Service Manual DLK-126 < DTC/CIRCUIT DIAGNOSIS > TRUNK LAMP SWITCH TRUNK LAMP SWITCH DescriptionINFOID:0000000009461861 Detects trunk open/close condition. Component Function CheckINFOID:0000000009461862 1.CHECK FU

Page 895 of 4801

NISSAN TEANA 2014 Service Manual TRUNK LAMP SWITCHDLK-127 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I J L M A B DLK N O P Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness between BCM and trunk lamp swit

Page 896 of 4801

NISSAN TEANA 2014 Service Manual DLK-128 < DTC/CIRCUIT DIAGNOSIS > TRUNK LAMP SWITCH Is the inspection result normal? YES >> Inspection End. NO >> Replace trunk lamp switch and trunk release solenoid. Te r m i n a l Trunk condition
