Page 1217 of 4801

NISSAN TEANA 2014 Service Manual
P0031, P0032 A/F SENSOR 1 HEATER
EC-217
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
• Discard any sensor which has been dropped from a he
ight of more than 0.5 m (19.7 in) o

Page 1218 of 4801

NISSAN TEANA 2014 Service Manual
EC-218
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0037, P0038 HO2S2 HEATER
P0037, P0038 HO2S2 HEATER
DTC LogicINFOID:0000000009462168
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC

EC-218
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0037, P0038 HO2S2 HEATER
P0037, P0038 HO2S2 HEATER
DTC LogicINFOID:0000000009462168
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 11 V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON and select “DATA MONITOR” mode of “ENGINE” using CONSULT.
2. Start engine and warm it up to normal operating temperature.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Start engine and keep the engine speed between 3,500 and 4,000 rpm for at least 1 minute under no load.
5. Let engine idle for 1 minute.
6. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-218, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462169
1.CHECK HO2S2 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect heated oxygen sensor 2 (HO2S2) harness connector.
3. Turn ignition switch ON.
4. Check the voltage between HO2S2 harness connector and ground.
DTC No. Trouble diagnosis name
(Trouble diagnosis con-
tent) DTC detecting condition Possible cause
P0037 HO2 HTR (B1)
(HO2S heater control cir-
cuit low bank 1 sensor 2) The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively low voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) • Harness or connectors
(Heated oxygen sensor 2 heater cir-
cuit is open or shorted.)
• Heated oxygen sensor 2 heater
P0038 HO2 HTR (B1)
(HO2S heater control cir-
cuit high bank 1 sensor 2) The current amperage in the heated oxygen sensor
2 heater circuit is out of the normal range.
(An excessively high voltage signal is sent to ECM
through the heated oxygen sensor 2 heater.) • Harness or connectors
(Heated oxygen sensor 2 heater cir-
cuit is shorted.)
• Heated oxygen sensor 2 heater
+
−Voltag e
HO2S2
Connector Terminal F42 2 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1219 of 4801

NISSAN TEANA 2014 Service Manual
P0037, P0038 HO2S2 HEATEREC-219
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-detected parts.
2.C

Page 1220 of 4801

NISSAN TEANA 2014 Service Manual
EC-220
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0037, P0038 HO2S2 HEATER
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE HEATED OXYGEN SENSOR 2
Replace heated oxygen sensor

Page 1221 of 4801

NISSAN TEANA 2014 Service Manual
P0075 INTAKE VALVE TIMING CONTROLEC-221
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0075 INTAKE VALVE TIMING CONTROL
DTC LogicINFOID:0000000009462171
DTC DETECTION LOGIC
DTC

P0075 INTAKE VALVE TIMING CONTROLEC-221
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0075 INTAKE VALVE TIMING CONTROL
DTC LogicINFOID:0000000009462171
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-221, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462172
1.CHECK INTAKE VALVE TIMING (IVT) CO NTROL SOLENOID VALVE POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect IVT control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check the voltage between intake valve timing control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK IVT CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0075 INT/V TIM V/CIR-B1
(Intake valve control sole-
noid circuit bank 1) • ECM detects an abnormal voltage in the intake
valve timing control solenoid valve control circuit.
• ECM detects an abnormal voltage in the intake valve timing intermediate lock control solenoid
valve control circuit. • Harness or connectors
(Intake valve timing control solenoid
valve circuit is open or shorted.)
(Intake valve timing intermediate
lock control solenoid valve circuit is
open or shorted.)
• Intake valve timing control solenoid valve
• Intake valve timing intermediate lock
control solenoid valve
+
−Voltag e
IVT control solenoid valve
Connector Terminal F59 1 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1222 of 4801

NISSAN TEANA 2014 Service Manual
EC-222
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0075 INTAKE VALVE TIMING CONTROL
3. Check the continuity between IVT control sol
enoid valve harness connector and IPDM E/R harness con-
nector.
4. Also chec

Page 1223 of 4801

NISSAN TEANA 2014 Service Manual
P0075 INTAKE VALVE TIMING CONTROLEC-223
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
3. Check the continuity between IVT intermediate lo
ck control solenoid valve harness conne

P0075 INTAKE VALVE TIMING CONTROLEC-223
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
3. Check the continuity between IVT intermediate lo
ck control solenoid valve harness connector and IPDM
E/R harness connector.
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
7.CHECK IVT INTERMEDIATE LOCK CONT ROL SOLENOID VALVE GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between IVT intermediate lock control solenoid valve harness connector and ECM
harness connector.
*1: Except for California
*2: For California
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace error-detected parts.
8.CHECK IVT INTERMEDIATE LOCK CONTROL SOLENOID VALVE
Check the IVT intermediate lock control solenoid valve. Refer to EC-224, "Component Inspection (IVT Inter-
mediate Lock Control Solenoid Valve)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace IVT intermediate lock control solenoid valve. Refer to EM-61, "Exploded View"
.
Component Inspection (IVT Control Solenoid Valve)INFOID:0000000009462173
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-I
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Check resistance between intake valve timing control solenoid valve terminals as follows.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace intake valve timing control solenoid valve. Refer to EM-61, "Exploded View"
.
+−
Continuity
IVT intermediate lock con-
trol solenoid valve IPDM E/R
Connector Terminal Connector Terminal F51 1 F83 59 Existed
+ −
Continuity
IVT intermediate lock con-
trol solenoid valve ECM
Connector Terminal Connector Terminal
F51 2 F13
*1
F90*256 Existed
Terminals Resistance
1 and 2 7.0 - 7.5 Ω [at 20 °C (68 °F)]
1 or 2 and ground ∞
Ω
(Continuity should not exist)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1224 of 4801

NISSAN TEANA 2014 Service Manual
EC-224
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0075 INTAKE VALVE TIMING CONTROL
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-II
1. Remove intake valve timing control solenoid valve. Refer to EM-61,

EC-224
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0075 INTAKE VALVE TIMING CONTROL
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-II
1. Remove intake valve timing control solenoid valve. Refer to EM-61, "Exploded View"
.
2. Provide 12 V DC between intake valve timing control solenoid
valve terminals 1 and 2, and then interrupt it. Make sure that the
plunger moves as shown in the figure.
CAUTION:
Do not apply 12 V DC continuously for 5 seconds or more.
Doing so may result in damage to the coil in intake valve
timing control solenoid valve.
NOTE:
Always replace O-ring when intake valve timing control
solenoid valve is removed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace intake valve timing control solenoid valve. Refer to EM-61, "Exploded View"
.
Component Inspection (IVT Intermediate Lock Control Solenoid Valve)INFOID:0000000009462174
1.CHECK INTAKE VALVE TIMING INTERMEDIA TE LOCK CONTROL SOLENOID VALVE-I
1. Turn ignition switch OFF.
2. Disconnect intake valve timing intermediate lock control solenoid valve harness connector.
3. Check resistance between intake valve timing interm ediate lock control solenoid valve terminals as fol-
lows.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace intake valve timing intermediate lock control solenoid valve. Refer to EM-61, "Exploded
View".
2.CHECK INTAKE VALVE TIMING INTERMEDIATE LOCK CONTROL SOLENOID VALVE-II
1. Remove intake valve timing intermediate lock control solenoid valve. Refer to EM-61, "Exploded View"
.
2. Provide 12 V DC between intake valve timing intermediate lock control solenoid valve terminals 1 and 2, and then interrupt it.
Make sure that the plunger moves as shown in the figure.
CAUTION:
Do not apply 12 V DC continuously for 5 seconds or more.
Doing so may result in damage to the coil in intake valve
timing intermediate lock control solenoid valve.
NOTE:
Always replace O-ring when in take valve timing intermedi-
ate lock control solenoid valve is removed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace intake valve timing intermediate lock control solenoid valve. Refer to EM-61, "Exploded
View".
JMBIA2107ZZ
Terminals Resistance
1 and 2 7.0 - 7.5 Ω [at 20 °C (68 °F)]
1 or 2 and ground ∞
Ω
(Continuity should not exist)
JMBIA2107ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
