NISSAN TEANA 2014 Service Manual
FRONT COMBINATION LAMPEXL-143
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
5. Rotate the halogen lamp bulb (high beam) counterclockwise and remove.
6. Rotate the side marker

Page 2410 of 4801

NISSAN TEANA 2014 Service Manual
EXL-144
< UNIT DISASSEMBLY AND ASSEMBLY >
FRONT COMBINATION LAMP
Assembly
Assembly is in the reverse order of disassembly.
CAUTION:
After installing, be sure to install the bu lb sockets securely t

Page 2411 of 4801

NISSAN TEANA 2014 Service Manual
REAR COMBINATION LAMPEXL-145
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
REAR COMBINATION LAMP
Exploded View - Non LEDINFOID:0000000009463646
REAR COMBINATION LAMP - NON LED

Page 2412 of 4801

NISSAN TEANA 2014 Service Manual
EXL-146
< UNIT DISASSEMBLY AND ASSEMBLY >
REAR COMBINATION LAMP
Assembly is in the reverse order of disassembly.
CAUTION:
After installing, be sure to install the bu lb sockets securely to ensure w

Page 2413 of 4801

NISSAN TEANA 2014 Service Manual
REAR COMBINATION LAMPEXL-147
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
8. Remove the side marker lamp bulb from bulb socket.
Assembly
Assembly is in the reverse order of d

Page 2414 of 4801

NISSAN TEANA 2014 Service Manual
EXL-148
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:0000000009

Page 2415 of 4801

NISSAN TEANA 2014 Service Manual
EXT-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
D E
F
G H
I
J
L
M
SECTION EXT
A
B
EXT
N
O P
CONTENTS
EXTERIOR
PRECAUTION ................ ...............................3
PRECAUTIONS ........

EXT-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
D E
F
G H
I
J
L
M
SECTION EXT
A
B
EXT
N
O P
CONTENTS
EXTERIOR
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution for Procedure without Cowl Top Cover ......3
Precaution for Work ..................................................3
PREPARATION ............................................5
PREPARATION .............................................. .....5
Special Service Tools .......................................... ......5
Commercial Service Tool ..........................................5
CLIP LIST ............................................................6
Descriptions for Clips .......................................... ......6
PERIODIC MAINTENANCE .........................10
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ........................................................... ....
10
Work Flow ........................................................... ....10
Generic Squeak and Rattle Troubleshooting ..........11
Diagnostic Worksheet .............................................14
REMOVAL AND INSTALLATION ...............16
FRONT BUMPER ........................................... ....16
Exploded View .................................................... ....16
Removal and Installation .........................................17
REAR BUMPER ............................................. ....20
Exploded View .................................................... ....20
Removal and Installation .........................................21
FRONT GRILLE ............................................. ....23
Exploded View .................................................... ....23
Removal and Installation .........................................23
COWL TOP ..................................................... ....24
Exploded View .................................................... ....24
Removal and Installation .........................................24
FENDER PROTECTOR ....................................26
FENDER PROTECTOR ......................................... ....26
FENDER PROTECTOR : Exploded View ...............26
FENDER PROTECTOR : Removal and Installa-
tion ....................................................................... ....
26
REAR WHEEL HOUSE PROTECTOR .................. ....26
REAR WHEEL HOUSE PROTECTOR : Exploded
View ..................................................................... ....
27
REAR WHEEL HOUSE PROTECTOR : Removal
and Installation .................................................... ....
27
FRONT UNDER COVER ...................................28
Exploded View .........................................................28
Removal and Installation .........................................28
REAR UNDER COVER .....................................29
Removal and Installation .........................................29
MUDGUARD .....................................................30
Exploded View .........................................................30
Removal and Installation .........................................30
DOOR SASH MOLDING ...................................31
Exploded View .........................................................31
Removal and Installation .........................................31
SIDE GUARD MOLDING ..................................34
Exploded View ..................................................... ....34
Removal and Installation .........................................34
DOOR OUTSIDE MOLDING .............................35
Exploded View .........................................................35
Removal and Installation .........................................35
ROOF SIDE MOLDING .....................................36
Exploded View .........................................................36
Removal and Installation .........................................36
LICENSE LAMP FINISHER ..............................37
Removal and Installation .........................................37
Revision: November 20132014 Altima NAM
