Page 1545 of 4801

NISSAN TEANA 2014 Service Manual
PRECAUTIONSEC-545
< PRECAUTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
•
B1 indicates bank 1, B2 indicates bank 2 as shown in the fig-
ure.
• Never operate fuel pump when there is no fuel i

Page 1546 of 4801

NISSAN TEANA 2014 Service Manual
EC-546
< PREPARATION >[VQ35DE]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000009462478
The actual shape of the tools may differ from those illustrated here.
Commercial Servic

Page 1547 of 4801

NISSAN TEANA 2014 Service Manual
PREPARATIONEC-547
< PREPARATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Fuel filler cap adapter
i.e.: (MLR-8382) Checks fuel tank vacuum relief valve opening
pressure
Socket wrench Removes and

Page 1548 of 4801

NISSAN TEANA 2014 Service Manual
EC-548
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
ENGINE CONTROL SYSTEM
ENGINE CONTROL SYSTEM :
Component Parts LocationINFOID:0000000009462480
ENGINE ROOM
ALB

Page 1549 of 4801

NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-549
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
ENGINE
11. Mass air flow sensor (with intake air temperature sensor)
EC-560, "Mass Air Flow Sensor (With Intake

Page 1550 of 4801

NISSAN TEANA 2014 Service Manual
EC-550
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
EXHAUST
BODY
8.Ignition coil (with power transistor)
(bank 2) EC-560, "Ignition Coil (With Power Transistor)"
9.Camshaft position sensor (PHAS

Page 1551 of 4801

NISSAN TEANA 2014 Service Manual
COMPONENT PARTSEC-551
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
A. Instrument panel
periphery (driver
side) B. Pedal periphery C. Inside fuel tank periphery
D. Behind fuel ta

Page 1552 of 4801

NISSAN TEANA 2014 Service Manual
EC-552
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
Accelerator Pedal Position Sensor
INFOID:0000000009462481
The accelerator pedal position sensor is installed on the upper end
of the accelerator

EC-552
< SYSTEM DESCRIPTION >[VQ35DE]
COMPONENT PARTS
Accelerator Pedal Position Sensor
INFOID:0000000009462481
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The
ECM uses this signal for the engine operation such as fuel cut.
Air Fuel Ratio (A/F) Sensor 1INFOID:0000000009462482
DESCRIPTION
The air fuel ratio (A/F) sensor 1 is a planar one-cell limit current sen-
sor. The sensor element of the A/F sensor 1 is composed an elec-
trode layer, which transports ions. It has a heater in the element.
The sensor is capable of precise measurement = 1, but also in the
lean and rich range. Together with its control electronics, the sensor
outputs a clear, continuous signal throughout a wide range.
The exhaust gas components diffuse through the diffusion layer at
the sensor cell. An electrode layer is applied voltage, and this current
relative oxygen density in lean. Also this current relative hydrocar-
bon density in rich.
Therefore, the A/F sensor 1 is able to indicate air fuel ratio by this
electrode layer of current. In additi on, a heater is integrated in the
sensor to ensure the required operating temperature of approxi-
mately 800 °C (1,472 °F).
8. EVAP control system pressure sensor EC-558, "EVAP Control System Pressure Sensor"
9. EVAP canister vent control valve EC-558, "EVAP Canister Vent Control Valve"
10. EVAP canisterEC-557, "EVAP Canister"
No. Component Function
JPBIA4615ZZ
PBIB1741E
JPBIA4038GB
JPBIA5446GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
