Page 4777 of 4801

NISSAN TEANA 2014 Service Manual
WW-42
< DTC/CIRCUIT DIAGNOSIS >
WASHER MOTOR CIRCUIT
NO >> GO TO 5.
5. CHECK WASHER MOTOR POWER SUPPLY CONTINUITY
1. Turn ignition OFF.
2. Disconnect the washer motor connector harness.
3. Check con

WW-42
< DTC/CIRCUIT DIAGNOSIS >
WASHER MOTOR CIRCUIT
NO >> GO TO 5.
5. CHECK WASHER MOTOR POWER SUPPLY CONTINUITY
1. Turn ignition OFF.
2. Disconnect the washer motor connector harness.
3. Check continuity between the washer motor harnes s connector E226 and the rear view camera washer
control unit harness connector B16.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the harness or connectors.
6.CHECK REAR VIEW CAMERA WASH ER CONTROL UNIT POWER SUPPLY
1. Disconnect the rear view camera washer control unit.
2. Turn ignition switch ON.
3. Check voltage between the rear view camera washer control unit harness connector B16 and ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 7.
7.CHECK REAR VIEW CAMERA WASHER CO NTROL UNIT POWER SUPPLY CONTINUITY
1. Turn ignition OFF.
2. Check continuity between rear view camera wa sher control unit harness connector B16 and IPDM E/R
harness connector E200.
Is the inspection result normal?
Yes >> Refer to PCS-31, "Diagnosis Procedure".
NO >> Repair or replace the harness or connectors.
8. CHECK WASHER MOTOR GROUND CIRCUIT
Check continuity between combination switch harness connector E226 and ground.
Is the inspection result normal?
YES >> Replace the washer pump. Refer to WW-52, "Removal and Installation".
NO >> GO TO 9.
9. CHECK WASHER MOTOR GROUND CIRCUIT CONTINUITY
1. Turn the ignition switch OFF.
2. Check continuity between rear view camera was her control unit harness connector B16 and front washer
motor E226.
Rear view camera washer control unit Washer motor Continuity
Connector Terminal Connector Terminal
B16 4 E226 1 Yes
Rear view camera washer control unit GroundVo l ta g e
(Approx.)
Connector Terminal
B16 12 Battery voltage
Rear view camera washer control unit IPDM E/R Continuity
Connector Terminal Connector Terminal
B16 12 E200 74 Yes
Washer motor GroundContinuity
Connector Terminal
E226 2 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4778 of 4801

NISSAN TEANA 2014 Service Manual
WASHER MOTOR CIRCUITWW-43
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
WW
N
O P
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace the harness or connectors.
10. CHECK

Page 4779 of 4801

NISSAN TEANA 2014 Service Manual
WW-44
< DTC/CIRCUIT DIAGNOSIS >
WASHER SWITCH
WASHER SWITCH
DescriptionINFOID:0000000009464622
• Washer switch is integrated with combination switch (wiper and washer switch).
• Combination switc

Page 4780 of 4801

NISSAN TEANA 2014 Service Manual
WIPER AND WASHER SYSTEM SYMPTOMSWW-45
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
WW
N
O P
SYMPTOM DIAGNOSIS
WIPER AND WASHER SYSTEM SYMPTOMS
Symptom TableINFOID:0000000009464624
CAUTION:
Perfor

Page 4781 of 4801

NISSAN TEANA 2014 Service Manual
WW-46
< SYMPTOM DIAGNOSIS >
WIPER AND WASHER SYSTEM SYMPTOMS
Front wiper does not
stop HI only
• Combination switch (wiper and washer switch)
•BCM Combination switch (wiper
and washer switch)

WW-46
< SYMPTOM DIAGNOSIS >
WIPER AND WASHER SYSTEM SYMPTOMS
Front wiper does not
stop HI only
• Combination switch (wiper and washer switch)
•BCM Combination switch (wiper
and washer switch)
Refer to BCS-8, "COMBINA-
TION SWITCH READING
SYSTEM : System Descrip-
tion".
Front wiper request signal
•BCM
•IPDM E/R IPDM E/R
Data monitor “FR WIP REQ”
IPDM E/R —
LO only • Combination switch (wiper and washer switch)
•BCM Combination switch (wiper
and washer switch)
Refer to BCS-8, "COMBINA-
TION SWITCH READING
SYSTEM : System Descrip-
tion".
Front wiper request signal
•BCM
•IPDM E/R IPDM E/R
Data monitor “FR WIP REQ”
IPDM E/R —
INT only • Combination switch (wiper and washer switch)
•BCM Combination switch (wiper
and washer switch)
refer to BCS-8, "COMBINA-
TION SWITCH READING
SYSTEM : System Descrip-
tion".
Front wiper request signal
•BCM
•IPDM E/R IPDM E/R
Data monitor “FR WIP REQ”
Front wiper does not
operate normally Intermittent adjustment
cannot be performed • Combination switch (wiper and washer switch)
• Harness between combination switch (wiper and washer switch) and BCM
•BCM Combination switch (wiper
and washer switch)
Refer to BCS-8, "COMBINA-
TION SWITCH READING
SYSTEM : System Diagram".
BCM —
Intermittent control
linked with vehicle
speed cannot be per-
formed Check the vehicle speed detection wiper setting.
Refer to BCS-20, "WIPER : CONSULT Function (BCM - WIPER)"
.
Wiper is not linked to
the washer operation • Combination switch (wiper and washer switch)
• Harness between combination switch (wiper and washer switch) and BCM
•BCM Combination switch (wiper
and washer switch)
Refer to BCS-8, "COMBINA-
TION SWITCH READING
SYSTEM : System Diagram".
BCM —
Does not return to stop
position (Repeatedly
operates for 10 sec-
onds and then stops for
20 seconds. After that,
it stops the operation. •IPDM E/R
• Harness between IPDM E/R and front wiper motor
• Front wiper motor Front wiper auto stop signal
circuit
Refer to WW-38, "Compo-
nent Function Check".
Symptom Probable malfunction location Inspection item
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4782 of 4801

NISSAN TEANA 2014 Service Manual
WIPER AND WASHER SYSTEM SYMPTOMSWW-47
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
WW
N
O P
Washer motor does
not operate (with rear
view camera wash
system) Washer motor does not
operate

Page 4783 of 4801

NISSAN TEANA 2014 Service Manual
WW-48
< SYMPTOM DIAGNOSIS >
FRONT WIPER DOES NOT OPERATE
FRONT WIPER DOES NOT OPERATE
DescriptionINFOID:0000000009464625
The front wiper does not operate under any operation conditions
Diagnosis Proc

Page 4784 of 4801

NISSAN TEANA 2014 Service Manual
FRONT WIPER DOES NOT OPERATEWW-49
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
WW
N
O P
Is the inspection result normal?
YES LO circuit>>Refer to WW-34, "Diagnosis Procedure".
YES HI circuit>>Ref
