Page 3953 of 4801

NISSAN TEANA 2014 Service Manual
SEC-128
< DTC/CIRCUIT DIAGNOSIS >
SECURITY INDICATOR LAMP
4.CHECK SECURITY INDICATOR LAMP CIRCUIT
1. Disconnect combination meter connector.
2. Check continuity between combination meter harness con

Page 3954 of 4801

NISSAN TEANA 2014 Service Manual
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF VEHICLE
SEC-129
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
SYMPTOM DIAGNOSIS
ENGINE DOES NOT START WHEN IN TELLIGENT KEY IS INSI

Page 3955 of 4801

NISSAN TEANA 2014 Service Manual
SEC-130
< SYMPTOM DIAGNOSIS >
SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINK
SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINK
DescriptionINFOID:0000000009461196
Security indicator lamp does not b

Page 3956 of 4801

NISSAN TEANA 2014 Service Manual
VEHICLE SECURITY SYSTEM CANNOT BE SETSEC-131
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY S YSTEM CANNOT BE SET
INTELLIGENT KEY
INTELLIGENT KEY : DescriptionINFOID:00000

VEHICLE SECURITY SYSTEM CANNOT BE SETSEC-131
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY S YSTEM CANNOT BE SET
INTELLIGENT KEY
INTELLIGENT KEY : DescriptionINFOID:0000000009461198
ARMED phase is not activated when door is locked using Intelligent Key.
NOTE:
Check that vehicle is under the condition shown in “C onditions of vehicle” before starting diagnosis and check
each symptom.
CONDITION OF VEHICLE (OPERATING CONDITION)
Confirm the setting of “SECURITY ALARM SET” is ON in “WORK SUPPORT” mode of “THEFT ALM” of
“BCM” using CONSULT.
INTELLIGENT KEY : Diagnosis ProcedureINFOID:0000000009461199
1.CHECK INTELLIGENT KEY SYSTEM (REMOTE KEYLESS ENTRY FUNCTION)
Lock/unlock door with Intelligent Key.
Refer to SEC-11, "INTELLIGENT KEY SYSTEM/ENGIN E START FUNCTION : System Description"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check Intelligent Key system (remote keyless entry function). Refer to DLK-144, "Diagnosis Pro-
cedure".
2.CHECK HOOD SWITCH
Check hood swiwtch.
Refer to SEC-125, "Component Function Check"
.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace hood switch.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 1.
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : DescriptionINFOID:0000000009461200
ARMED phase is not activated when door is locked using door request switch.
NOTE:
Check that vehicle is under the condition shown in “C onditions of vehicle” before starting diagnosis, and check
each symptom.
CONDITION OF VEHICLE (OPERATING CONDITION)
Confirm the setting of “SECURITY ALARM SET” is ON in “WORK SUPPORT” mode of “THEFT ALM” of
“BCM” using CONSULT.
DOOR REQUEST SWITCH : Diagnosis ProcedureINFOID:0000000009461201
1.CHECK INTELLIGENT KEY SYS TEM (DOOR LOCK FUNCTION)
Lock/unlock door with door request switch.
Refer to SEC-16, "VEHICLE SECURITY SY STEM : System Description"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check Intelligent Key system (door lock function). Refer to DLK-144, "Diagnosis Procedure"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3957 of 4801

NISSAN TEANA 2014 Service Manual
SEC-132
< SYMPTOM DIAGNOSIS >
VEHICLE SECURITY SYSTEM CANNOT BE SET
2.CHECK HOOD SWITCH
Check hood switch.
Refer to SEC-125, "Component Function Check"
.
Is the inspection result normal?
YES >> GO

Page 3958 of 4801

NISSAN TEANA 2014 Service Manual
VEHICLE SECURITY ALARM DOES NOT ACTIVATE
SEC-133
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
VEHICLE SECURITY ALAR M DOES NOT ACTIVATE
DescriptionINFOID:0000000009461204
Alarm does not

Page 3959 of 4801

NISSAN TEANA 2014 Service Manual
SEC-134
< SYMPTOM DIAGNOSIS >
PANIC ALARM FUNCTION DOES NOT OPERATE
PANIC ALARM FUNCTION DOES NOT OPERATE
DescriptionINFOID:0000000009461206
NOTE:
• Before performing the diagnosis following proce

Page 3960 of 4801

NISSAN TEANA 2014 Service Manual
NATS ANTENNA AMP.SEC-135
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
SEC
N
O P
REMOVAL AND INSTALLATION
NATS ANTENNA AMP.
Exploded ViewINFOID:0000000009461208
Removal and InstallationINFOI
