Page 1457 of 4801
![NISSAN TEANA 2014 Service Manual
P1800 INTAKE MANIFOLD TUNING VALVEEC-457
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
5. Also check harness for short to ground.
NISSAN TEANA 2014 Service Manual
P1800 INTAKE MANIFOLD TUNING VALVEEC-457
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
5. Also check harness for short to ground.](/manual-img/5/57390/w960_57390-1456.png)
P1800 INTAKE MANIFOLD TUNING VALVEEC-457
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
5. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK INTAKE MANIFOLD TUNING VA LVE MOTOR OUTPUT SIGNAL CIRCUIT
1. Disconnect intake manifold tuning valve motor harness connector.
2. Check the continuity between intake manifold tuning valve motor harness connector and ECM harness
connector.
*1: Except for California
*2: For California
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK INTAKE MANIFOLD TUNING VALVE MOTOR
Check the intake manifold tuning valve motor. Refer to EC-457, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace intake manifold assembly. Refer to EM-30, "Removal and Installation"
.
Component InspectionINFOID:0000000009462391
1.CHECK THROTTLE CONTROL MOTOR
1. Turn ignition switch OFF.
2. Disconnect electric throttle c ontrol actuator harness connector.
3. Check the resistance between electric throttle control actuator terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
+ −
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal
F14
*1
F91*26F8359Existed
+ −
Continuity
Intake manifold tuning valve
motor ECM
Connector Terminal Connector Terminal
F40 1
F14
*1
F91*2
5 Not existed
7 Existed
2 5 Existed
7 Not existed
Electric throttle control actuator Resistance
(Approx.)
+
−
Te r m i n a l s
5 6 3 - 8 Ω [at 25 °C (77 °F)]
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1458 of 4801
EC-458
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1800 INTAKE MANIFOLD TUNING VALVE
NO >> Replace electric throttle control actuator. Refer to
EM-30, "Removal and Installation".
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1459 of 4801
![NISSAN TEANA 2014 Service Manual
P1805 BRAKE SWITCHEC-459
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000009462392
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERF NISSAN TEANA 2014 Service Manual
P1805 BRAKE SWITCHEC-459
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000009462392
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERF](/manual-img/5/57390/w960_57390-1458.png)
P1805 BRAKE SWITCHEC-459
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1805 BRAKE SWITCH
DTC LogicINFOID:0000000009462392
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Fully depress the brake pedal for at least 5 seconds.
3. Erase the DTC.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-459, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462393
1.CHECK STOP LAMP SWIT CH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform the trouble diagnosis for power supply circuit.
2.CHECK STOP LAMP SWITCH GROUND CIRCUIT
1. Disconnect stop lamp relay harness connector.
2. Check the continuity between stop lamp switch harness connector and stop lamp relay harness connec-
tor.
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK STOP LAMP SWITCH
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P1805 BRAKE SW/CIRCUIT
(BRAKE SW/CIRCUIT) A stop lamp switch signal is not sent to
ECM for extremely long time while the ve-
hicle is driving. • Harness or connectors
(Stop lamp switch circuit is open or short-
ed.)
• Stop lamp switch
•Stop lamp relay
+
−Voltag e
Stop lamp switch
Connector Terminal E38 1 Ground Battery voltage
+ −
Continuity
Stop lamp switch Stop lamp relay
Connector Terminal Connector Terminal E38 2 E57 2 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1460 of 4801
![NISSAN TEANA 2014 Service Manual
EC-460
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1805 BRAKE SWITCH
Check the stop lamp switch. Refer to
EC-450, "Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 4.
NISSAN TEANA 2014 Service Manual
EC-460
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1805 BRAKE SWITCH
Check the stop lamp switch. Refer to
EC-450, "Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 4.](/manual-img/5/57390/w960_57390-1459.png)
EC-460
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1805 BRAKE SWITCH
Check the stop lamp switch. Refer to
EC-450, "Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace stop lamp switch. Refer to BR-18, "Exploded View"
.
4.CHECK STOP LAMP RELAY CONTROL CIRCUIT
1. Check the continuity between stop lamp relay harness connector and ground.
2. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK STOP LAMP SWIT CH SIGNAL POWER SUPPLY
Check the voltage between stop lamp relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform the trouble diagnosis for power supply circuit.
6.CHECK STOP LAMP SWITCH SIGNAL CIRCUIT
1. Disconnect ECM harness connector.
2. Check the continuity between stop lamp relay harness connector and ECM harness connector.
*1: Except for California
*2: For California
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts
7.CHECK STOP LAMP RELAY
Check the stop lamp relay. Refer to EC-461, "Component Inspection (Stop Lamp Relay)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace stop lamp relay.
+
−Continuity
Sto p l am p rela y
Connector Terminal E57 1 Ground Existed
+ −Vo l ta g e
St op la mp rel ay
Connector Terminal E57 5 Ground Battery voltage
+ −
Continuity
Sto p l am p rela y EC M
Connector Terminal Connector Terminal
E57 3 E10
*1
E31*2115 Existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1461 of 4801
![NISSAN TEANA 2014 Service Manual
P1805 BRAKE SWITCHEC-461
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Component Inspection (Stop Lamp Switch)INFOID:0000000009462394
1.CHECK STOP LAMP SWITCH-1
1. Turn ignition NISSAN TEANA 2014 Service Manual
P1805 BRAKE SWITCHEC-461
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Component Inspection (Stop Lamp Switch)INFOID:0000000009462394
1.CHECK STOP LAMP SWITCH-1
1. Turn ignition](/manual-img/5/57390/w960_57390-1460.png)
P1805 BRAKE SWITCHEC-461
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Component Inspection (Stop Lamp Switch)INFOID:0000000009462394
1.CHECK STOP LAMP SWITCH-1
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the continuity between stop lamp switch terminals as per the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH-2
1. Adjust stop lamp switch installation. Refer to BR-13, "Inspection and Adjustment"
.
2. Check the continuity between stop lamp switch terminals as per the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch. Refer to BR-18, "Exploded View"
.
Component Inspection (Stop Lamp Relay)INFOID:0000000009462395
1.CHECK STOP LAMP RELAY
1. Turn ignition switch OFF.
2. Remove stop lamp relay.
3. Check the continuity between stop lamp relay terminals as per the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp relay.
Stop lamp switch
Condition Continuity
+ −
Te r m i n a l s
1 2 Brake pedal Fully released Not existed
Slightly de-
pressed Existed
Stop lamp switch
Condition Continuity
+ −
Te r m i n a l s
1 2 Brake pedal Fully released Not existed
Slightly de-
pressed Existed
Stop lamp relay
Condition Continuity
+-
Te r m i n a l
35 12 V direct current supply between terminals
1 and 2 Existed
No current supply Not existed
JMBIA0848ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1462 of 4801
![NISSAN TEANA 2014 Service Manual
EC-462
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVE
DTC LogicINFOID:0000000009462396
DTC DETECTION LOGIC
DTC CONFIRMATION NISSAN TEANA 2014 Service Manual
EC-462
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVE
DTC LogicINFOID:0000000009462396
DTC DETECTION LOGIC
DTC CONFIRMATION](/manual-img/5/57390/w960_57390-1461.png)
EC-462
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVE
DTC LogicINFOID:0000000009462396
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
• Before performing the following procedure, confirm th at battery voltage is more than 11 V at idle.
• Always perform the test at a temperature above −12 °C (10 °F)
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT.
3. Make sure that “COOLAN TEMP/S” indicates between −12 °C (10 °F) to 59 °C (138 °F).
If not, cool engine down or warm engine up until “COOLAN TEMP/S” indicates between −12 °C (10 °F) to
59 °C (138 °F). Then go to the following steps.
4. Fully release accelerator pedal and wait at least 10 seconds.
5. Depress accelerator pedal and wait at least 10 seconds.
6. Check 1st trip DTC.
With GST
Following the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-462, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462397
1.CHECK INTAKE MANIFOLD RUNNER CO NTROL VALVE MOTOR POWER SUPPLY
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector.
*1: Except for California
*2: For California
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P2004 TUMBLE CONT/V
(Intake manifold runner control
stuck open bank 1) The target angle of intake manifold runner
control valve controlled by ECM and the in-
put signal from intake manifold runner con-
trol valve position sensor is not in the normal
range. • Harness or connectors
(Intake manifold runner control valve
motor circuit is open or shorted.)
• Intake manifold runner control valve motor
• Intake manifold runner control valve is
stuck
ECM
Vo l ta g e
+-
Connector Terminal Connector Terminal
F13
*1
F90*250 E10*1
E31*2128 Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1463 of 4801
![NISSAN TEANA 2014 Service Manual
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVEEC-463
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK INTAKE MA NISSAN TEANA 2014 Service Manual
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVEEC-463
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK INTAKE MA](/manual-img/5/57390/w960_57390-1462.png)
P2004 INTAKE MANIFOLD RUNNER CONTROL VALVEEC-463
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ECM harness connector and IPDM E/R harness connector.
*1: Except for California
*2: For California
5. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR OUTPUT SIGNAL CIRCUIT
1. Disconnect intake manifold runner control valve motor harness connector.
2. Check the continuity between intake manifold runner control valve motor harness connector and ECM harness connector.
*1: Except for California
*2: For California
3. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR
Check the intake manifold runner control valve motor. Refer to EC-463, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace intake manifold assembly. Refer to EM-30, "Removal and Installation"
.
Component InspectionINFOID:0000000009462398
1.CHECK INTAKE MANIFOLD RUNNER CONTROL VALVE
With CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT.
+ −
Continuity
ECM IPDM E/R
Connector Terminal Connector Terminal
F13
*1
F90*250 F83 59 Existed
+ −
Continuity
Intake manifold runner con-
trol valve motor ECM
Connector Terminal Connector Terminal
F41 1
F13
*1
F90*2
49 Not existed
51 Existed
2 49 Existed
51 Not existed
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 1464 of 4801
![NISSAN TEANA 2014 Service Manual
EC-464
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
3. Make sure that “COOLAN TEMP/S” indicates between −12 °C (10 °F) to 59 °C (138 °F).
If not, cool engi NISSAN TEANA 2014 Service Manual
EC-464
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
3. Make sure that “COOLAN TEMP/S” indicates between −12 °C (10 °F) to 59 °C (138 °F).
If not, cool engi](/manual-img/5/57390/w960_57390-1463.png)
EC-464
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P2004 INTAKE MANIFOLD
RUNNER CONTROL VALVE
3. Make sure that “COOLAN TEMP/S” indicates between −12 °C (10 °F) to 59 °C (138 °F).
If not, cool engine down or warm engine up until “COOLAN TEMP/S” indicates between −12 °C (10 °F) to
59 °C (138 °F). Then go to the following steps.
4. Fully release accelerator pedal and make sure that “TUMBLE POS SEN” indicates between 2.8 V to 4.1
V.
5. Depress accelerator pedal and make sure that “TUMBLE POS SEN” indicates between 0.2 V to 1.4 V.
6. Check 1st trip DTC.
With GST
Following the procedure “With CONSULT” above.
Is 1st trip DTC detected?
YES >> Replace intake manifold assembly. Refer to EM-30, "Removal and Installation".
NO >> GO TO 2.
2.CHECK INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR
1. Turn ignition switch OFF.
2. Disconnect intake manifold runner control valve motor harness connector.
3. Check the resistance between intake manifold runner control valve motor terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace intake manifold assembly. Refer to EM-30, "Removal and Installation"
.
Intake manifold runner control valve
motor Resistance
(Approx.)
+ −
Te r m i n a l s
1 2 3 - 8 Ω [at 25 °C (77 °F)]
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
