NISSAN TEANA 2014 Service Manual
HAC-64
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2581, B2582 IN
TAKE SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Chec

Page 2714 of 4801

NISSAN TEANA 2014 Service Manual
B2581, B2582 INTAKE SENSORHAC-65
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER]
C
D E
F
G H
J
K L
M A
B
HAC
N
O P
3. Check resistance between intake sensor terminals.
Is the inspection resu

Page 2715 of 4801

NISSAN TEANA 2014 Service Manual
HAC-66
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
B2630, B2631 SUNLOAD SENSOR
DTC LogicINFOID:0000000009463136
DTC DETECTION LOGIC
NOTE:
• If DTC is displayed

HAC-66
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
B2630, B2631 SUNLOAD SENSOR
B2630, B2631 SUNLOAD SENSOR
DTC LogicINFOID:0000000009463136
DTC DETECTION LOGIC
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
DTC CONFIRMATION PROCEDURE
1.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT
1. Using CONSULT, perform “SELF- DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC No. is displayed in the self-diagnosis results.
NOTE:
• If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to HAC-
55, "DTC Logic" or HAC-56, "DTC Logic".
• Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, light the sunload sensor with a lamp (60W or more).
Is DTC No.
“B2630” or “B2631” displayed?
YES >> Perform trouble diagnosis for the sunload sensor. Refer to HAC-66, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463137
Regarding Wiring Diagram information, refer to HAC-34, "Wiring Diagram".
1.CHECK SUNLOAD SENSOR POWER SUPPLY
1. Disconnect sunload sensor connector.
2. Turn ignition switch ON.
3. Check voltage between sunload sensor harness connector M56 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK CONTINUITY BETWEEN SUNL OAD SENSOR AND A/C AUTO AMP.
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
DTC Items
(CONSULT screen terms) Diagnostic item is detected when... Possible cause
B2630 SUNLOAD SEN (SHORT) Detected calorie at sunload sensor 1395 w/m
2
(1200 kcal/m2·h) or more • Sunload sensor
• A/C auto amp.
• Harness and connector
(Sunload sensor circuit is open, or
there is a short in the circuit)
B2631 SUNLOAD SEN (OPEN)
Detected calorie at sunload sensor 0 w/m
2
(0 kcal/m2·h)
+
−Voltage
(Approx.)
Sunload sensor
Connector Terminal M56 1 Ground 5 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
