Page 953 of 4801

NISSAN TEANA 2014 Service Manual FRONT DOORDLK-185 < REMOVAL AND INSTALLATION > C D E F G H I J L M A B DLK N O P 5. Remove front door hinge nuts (A) (door side) and the door assembly (1). INSTALLATION Installation is in the rever

Page 954 of 4801

NISSAN TEANA 2014 Service Manual DLK-186 < REMOVAL AND INSTALLATION > FRONT DOOR DOOR ASSEMBLY : Adjustment INFOID:0000000009461934 Check the clearance and surface height between front door and each part by visual inspection and ta

Page 955 of 4801

NISSAN TEANA 2014 Service Manual FRONT DOORDLK-187 < REMOVAL AND INSTALLATION > C D E F G H I J L M A B DLK N O P If the clearance and the surface height are out of specific ation, adjust them according to the adjustment proce- du

Page 956 of 4801

NISSAN TEANA 2014 Service Manual DLK-188 < REMOVAL AND INSTALLATION > FRONT DOOR DOOR STRIKER ADJUSTMENT Adjust front door striker so that it becomes parallel with door lock insertion direction. DOOR STRIKER DOOR STRIKER : Removal a

Page 957 of 4801

NISSAN TEANA 2014 Service Manual FRONT DOORDLK-189 < REMOVAL AND INSTALLATION > C D E F G H I J L M A B DLK N O P CAUTION: • Apply anticorrosive agent onto th e front door hinge mating surface. • After installation, check fro

Page 958 of 4801

NISSAN TEANA 2014 Service Manual DLK-190 < REMOVAL AND INSTALLATION > REAR DOOR REAR DOOR DOOR ASSEMBLY DOOR ASSEMBLY : Removal and InstallationINFOID:0000000009461938 CAUTION: • Use two people when removing or installing the re

Page 959 of 4801

NISSAN TEANA 2014 Service Manual REAR DOORDLK-191 < REMOVAL AND INSTALLATION > C D E F G H I J L M A B DLK N O P INSTALLATION Installation is in the reverse order of removal. Tighten rear door hinge nuts (door side) to specified

Page 960 of 4801

NISSAN TEANA 2014 Service Manual DLK-192 < REMOVAL AND INSTALLATION > REAR DOOR Check the clearance and surface height between rear door and each part by visual inspection and tactile feel. If the clearance and the surface height a
