NISSAN TEANA 2014 Service Manual
DIAGNOSIS SYSTEM (ECM)EC-601
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
The length of time the 1,000th-digit numeral flashes on
and off is 1.2 seconds consisting of an ON (0.6-

DIAGNOSIS SYSTEM (ECM)EC-601
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
The length of time the 1,000th-digit numeral flashes on
and off is 1.2 seconds consisting of an ON (0.6-sec-
onds) - OFF (0.6-seconds) cycle.
The 100th-digit numeral and lower digit numerals consis t of a 0.3-seconds ON and 0.3-seconds OFF cycle.
A change from one digit numeral to another occurs at an inte rval of 1.0-second OFF. In other words, the later
numeral appears on the display 1.3 seconds after the former numeral has disappeared.
A change from one trouble code to another occurs at an interval of 1.8-seconds OFF.
In this way, all the detected malfunctions are classi fied by their DTC numbers. The DTC 0000 refers to no mal-
function. Refer to EC-630, "DTC Index"
.
How to Erase Self-diagnostic Results
By performing this procedure, ECM memory is erased and the following diagnostic information is erased as
well.
• Diagnostic trouble codes
• 1st trip diagnostic trouble codes
• Freeze frame data
• 1st trip freeze frame data
• System readiness test (SRT) codes
• Test values
NOTE:
Also, if a battery terminal is disconnected, ECM memory is erased and the diagnostic information as listed
above is erased. (The amount of time required for eras ing may vary from a few seconds to several hours.)
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON.
5. Set ECM in “self-diagnostic results” mode.
6. The diagnostic information has been erased from the backup memory in the ECM. Fully depress the accelerator pedal and keep it depressed for more than 10 seconds.
7. Fully release the accelerator pedal, and confirm the DTC 0000 is displayed.
CONSULT FunctionINFOID:0000000009462541
FUNCTION
*: The following emission-related diagnostic information is cleared when the ECM memory is erased.
• Diagnostic trouble codes
• 1st trip diagnostic trouble codes
• Freeze frame data
• 1st trip freeze frame data
• System readiness test (SRT) codes
• Test values
SELF DIAGNOSTIC RESULT MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to EC-630, "DTC Index".
How to Read DTC and 1st Trip DTC
Diagnostic test mode Function
Self Diagnostic Result Self-diagnostic results such as 1st trip DTC, DTCs and 1st trip freeze frame data or freeze frame data
can be read and erased quickly.
*
Data Monitor Input/Output data in the ECM can be read.
Work support This mode enables a technician to adjust some devices faster and more accurately by following the in-
dications on the CONSULT unit.
Active Test Diagnostic Test Mode in which CONSULT drives some actuators apart from the ECMs and also shifts
some parameters in a specified range.
ECU Identification ECM part number can be read.
DTC Work Support The status of system monitoring tests and the self-diagnosis status/results can be confirmed.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1602 of 4801

NISSAN TEANA 2014 Service Manual
EC-602
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
DTCs and 1st trip DTCs related to the malf
unction are displayed in “self-diag results”.
• When ECM detects a 1st trip DTC, 1t” is

EC-602
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
DTCs and 1st trip DTCs related to the malf
unction are displayed in “self-diag results”.
• When ECM detects a 1st trip DTC, 1t” is displayed for “TIME”.
• When ECM has detected a current DTC, “0” is displayed for “TIME”.
• If “TIME” is neither “0” nor “1t”, the DTC occurred in the past and ECM shows the number of times the vehi-
cle has been driven since the last detection of the DTC.
How to Erase DTC and 1st Trip DTC
NOTE:
• If the ignition switch stays ON after repair work, be su re to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
• If the DTC is not for A/T related items (see EC-630, "DTC Index"
), skip step 1.
1. Select “ENGINE” with CONSULT.
2. Select “SELF-DIAG RESULTS”.
3. Touch “ERASE”. (DTC in ECM will be erased.)
Freeze Frame Data and 1st Trip Freeze Frame Data
*: The items are the same as those of 1st trip freeze frame data.
DATA MONITOR MODE
NOTE:
• The following table includes information (items) inapplicable to this vehicle. For information (items) applica- ble to this vehicle, refer to CONSULT display items.
• For reference values of the following items, refer to EC-613, "Reference Value"
.
Monitored Item
Freeze frame data item* Description
DIAG TROUBLE CODE
[PXXXX] The engine control co
mponent part/control system has a trouble code that is displayed as PXXXX. (Refer
to EC-630, "DTC Index"
.)
FUEL SYS-B1 • “Fuel injection system status” at the moment a malfunction is detected is displayed. • One of the following mode is displayed.Mode2: Open loop due to detected system malfunction
Mode3: Open loop due to driving conditions (power enrichment, deceleration enleanment)
Mode4: Closed loop - using oxygen sensor(s) as feedback for fuel control
Mode5: Open loop - has not yet satisfied condition to go to closed loop
FUEL SYS-B2
COMBUST CONDITION These items are displayed but are not applicable to this model.
CAL/LD VALUE [%] The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP [ °C] or
[ ° F] The engine coolant temperature at the moment a malfunction is detected is displayed.
L-FUEL TRM-B1 [%] • “Long-term fuel trim” at the moment a malfunction is detected is displayed. • The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule than short-term fuel trim.
L-FUEL TRM-B2 [%]
S-FUEL TRM-B1 [%] • “Short-term fuel trim” at the moment a malfunction is detected is displayed. • The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel schedule.
S-FUEL TRM-B2 [%]
ENGINE SPEED [rpm] The engine sp eed at the moment a malfunction is detected is displayed.
VEHICL SPEED
[km/h] or [mph] The vehicle speed at the moment a malfunction is detected is displayed.
INT MANI PRES [kPa] These items are displayed but are not applicable to this model.
ABSOL TH·P/S [%] The throttle valve opening angle at the moment a malfunction is detected is displayed.
B/FUEL SCHDL [msec] The base fuel schedule at the moment a malfunction is detected is displayed.
INT/A TEMP SE [ °C] or
[ ° F] The intake air temperature at the moment a malfunction is detected is displayed.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1603 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS SYSTEM (ECM)EC-603
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
×
: Applicable
Monitored item Unit Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MA

DIAGNOSIS SYSTEM (ECM)EC-603
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
×
: Applicable
Monitored item Unit Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
ENG SPEED rpm ××Indicates the engine speed comput-
ed from the signal of the crankshaft
position sensor (POS) and camshaft
position sensor (PHASE). • Accuracy becomes poor if engine
speed drops below the idle rpm.
• If the signal is interrupted while the engine is running, an abnor-
mal value may be indicated.
MAS A/F SE-B1 V ××The signal voltage of the mass air
flow sensor is displayed. • When the engine is stopped, a
certain value is indicated.
• When engine is running, specifi- cation range is indicated in
“SPEC”.
B/FUEL SCHDL ms ××“Base fuel schedule” indicates the
fuel injection pulse width pro-
grammed into ECM, prior to any
learned on board correction. • When engine is running, specifi-
cation range is indicated in
“SPEC”.
A/F ALPHA-B1
% The mean value of the air-fuel ratio
feedback correction factor per cycle
is indicated. • When the engine is stopped, a
certain value is indicated.
• This data also includes the data
for the air-fuel ratio learning con-
trol.
• When engine is running, specifi-
cation range is indicated in
“SPEC”.
A/F ALPHA-B2
COOLAN TEMP/S °C or °F ×× The engine coolant temperature (de-
termined by the signal voltage of the
engine coolant temperature sensor)
is displayed. When the engine coolant tempera-
ture sensor is open or short-circuit-
ed, ECM enters fail-safe mode. The
engine coolant temperature deter-
mined by the ECM is displayed.
A/F SEN1 (B1) V××
The A/F signal computed from the
input signal of the air fuel ratio (A/F)
sensor 1 is displayed.
A/F SEN1 (B2)
××
HO2S2 (B1) V××
The signal voltage of the heated ox-
ygen sensor 2 is displayed.
HO2S2 (B2) ××
HO2S2 MNTR(B1)
RICH/LEAN ×
Display of heated oxygen sensor 2
signal:
• RICH: means the amount of oxy-
gen after three way catalyst is rel-
atively small.
• LEAN: means the amount of oxy-
gen after three way catalyst is rel-
atively large. When the engine is stopped, a cer-
tain value is indicated.
HO2S2 MNTR(B2) ×
VHCL SPEED SE km/h or
mph ×× The vehicle speed computed from
the vehicle speed signal sent from
combination meter is displayed.
BATTERY VOLT V The power supply voltage of ECM is
displayed.
ACCEL SEN 1 V The accelerator pedal position sen-
sor signal voltage is displayed. ACCEL SEN 2 signal is converted
by ECM internally. Thus, it differs
from ECM terminal voltage signal.
ACCEL SEN 2
TP SEN 1-B1 V××
The throttle position sensor signal
voltage is displayed. TP SEN 2-B1 signal is converted by
ECM internally. Thus, it differs from
ECM terminal voltage signal.
TP SEN 2-B1
××
FUEL T/TMP SE °C or °F The fuel temperature (determined by
the signal voltage of the fuel tank
temperature sensor) is displayed.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1604 of 4801

NISSAN TEANA 2014 Service Manual
EC-604
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
EVAP SYS PRES VThe signal voltage of EVAP control
system pressure sensor is dis-
played.
FUEL LEVEL SE V ×The signal voltage of the fu

EC-604
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
EVAP SYS PRES VThe signal voltage of EVAP control
system pressure sensor is dis-
played.
FUEL LEVEL SE V ×The signal voltage of the fuel level
sensor is displayed.
START SIGNAL On/Off Indicates start signal status [On/Off]
computed by the ECM according to
the signals of engine speed and bat-
tery voltage. After starting the engine, [Off] is dis-
played regardless of the starter sig-
nal.
CLSD THL POS On/Off ××Indicates idle position [On/Off] com-
puted by ECM according to the ac-
celerator pedal position sensor
signal.
AIR COND SIG On/Off ××Indicates [On/Off] condition of the air
conditioner switch as determined by
the air conditioner signal.
PW/ST SIGNAL On/Off ××[On/Off] condition of the power
steering system (determined by the
signal voltage of the power steering
pressure sensor) is indicated.
LOAD SIGNAL On/Off ××Indicates [On/Off] condition from the
electrical load signal.
• On: Rear window defogger switch
is ON and/or lighting switch is in
2nd position.
• Off: Both rear window defogger
switch and lighting switch are
OFF.
IGNITION SW On/Off ××Indicates [On/Off] condition from ig-
nition switch signal.
HEATER FAN SW On/Off ×Indicates [On/Off] condition from the
heater fan switch signal.
BRAKE SW On/Off Indicates [On/Off] condition from the
stop lamp switch signal.
INJ PULSE-B1 msec Indicates the actual fuel injection
pulse width compensated by ECM
according to the input signals. When the engine is stopped, a cer-
tain computed value is indicated.
INJ PULSE-B2
IGN TIMING BTDC ×Indicates the ignition timing comput-
ed by ECM according to the input
signals. When the engine is stopped, a cer-
tain value is indicated.
CAL/LD VALUE % “Calculated load value” indicates the
value of the current air flow divided
by peak air flow.
MASS AIRFLOW g/s Indicates the mass air flow comput-
ed by ECM according to the signal
voltage of the mass air flow sensor.
PURG VOL C/V % • Indicates the EVAP canister purge
volume control solenoid valve
control value computed by the
ECM according to the input sig-
nals.
• The opening becomes larger as the value increases.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1605 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS SYSTEM (ECM)EC-605
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
INT/V TIM (B1)
°CA Indicates [
°CA] of intake camshaft
advance angle.
INT/V TIM (B2)
INT/V SOL(B1)
%

DIAGNOSIS SYSTEM (ECM)EC-605
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
INT/V TIM (B1)
°CA Indicates [
°CA] of intake camshaft
advance angle.
INT/V TIM (B2)
INT/V SOL(B1)
% • The control value of the intake
valve timing control solenoid valve
(determined by ECM according to
the input signals) is indicated.
• The advance angle becomes larg-
er as the value increases.
INT/V SOL(B2)
VIAS S/V-1 On/Off The control condition of the VIAS
control solenoid valve 1 (determined
by ECM according to the input sig-
nals) is indicated.
• On: VIAS control solenoid valve 1 is operating.
• Off: VIAS control solenoid valve 1 is not operating.
VIAS S/V-2 On/Off The control condition of the VIAS
control solenoid valve 2 (determined
by ECM according to the input sig-
nals) is indicated.
• On: VIAS control solenoid valve 2
is operating.
• Off: VIAS control solenoid valve 2 is not operating.
AIR COND RLY On/Off The air conditioner
relay control con-
dition (determined by ECM accord-
ing to the input signals) is indicated.
ENGINE MOUNT IDLE/
TRVL The control condition of the electron-
ic controlled engine mount (deter-
mined by ECM according to the
input signals) is indicated.
• IDLE: Engine speed is below 950
rpm
• TRVL: Engine speed is above 950 rpm
FUEL PUMP RLY On/Off Indicates the fuel pump relay control
condition determined by ECM ac-
cording to the input signals.
VENT CONT/V On/Off The control condition of the EVAP
canister vent control valve (deter-
mined by ECM according to the in-
put signals) is indicated.
• On: Closed
• Off: Open
THRTL RELAY On/Off Indicates the throttle control motor
relay control condition determined
by the ECM according to the input
signals.
A/F S1 HTR(B1)
% • Air fuel ratio (A/F) sensor 1 heater
control value computed by ECM
according to the input signals.
• The current flow to the heater be-
comes larger as the value increas-
es.
A/F S1 HTR(B2) Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1606 of 4801

NISSAN TEANA 2014 Service Manual
EC-606
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
COOLING FANHI/MID/
LOW/OFF • The control condition of the cool-
ing fan (determined by ECM ac-
cording to the input signals) is
indica

EC-606
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
COOLING FANHI/MID/
LOW/OFF • The control condition of the cool-
ing fan (determined by ECM ac-
cording to the input signals) is
indicated.
HI: High speed operation
MID: Middle speed operation
LOW: Low speed operation
OFF: Stop
HO2S2 HTR (B1)
On/Off Indicates [On/Off] condition of heat-
ed oxygen sensor 2 heater deter-
mined by ECM according to the
input signals.
HO2S2 HTR (B2)
ALT DUTY SIG On/Off The control condition of the power
generation voltage variable control
(determined by ECM according to
the input signals) is indicated.
• On: Power generation voltage variable control is active.
• Off: Power generation voltage
variable control is inactive.
I/P PULLY SPD rpm Indicates the engine speed comput-
ed from the input speed sensor sig-
nal.
VEHICLE SPEED km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
TCM is displayed.
IDL A/V LEARN YET/
CMPLT Displays the condition of idle air vol-
ume learning
• Yet: Idle Air Volume Learning has not been performed yet.
• Cmplt: Idle Air Volume Learning
has already been performed suc-
cessfully.
TRVL AFTER MIL km or
mile Distance traveled while MIL is acti-
vated.
ENG OIL TEMP °C or °F The engine oil temperature (deter-
mined by the signal voltage of the
engine oil temperature sensor) is
displayed.
VHCL SPEED SE km/h or
mph The vehicle speed computed from
the vehicle speed signal sent from
combination meter is displayed.
SET VHCL SPD km/h or
mph • The preset vehicle speed is dis-
played.
MAIN SW On/Off Indicates [On/Off] condition from
MAIN switch signal.
CANCEL SW On/Off Indicates [On/Off] condition from
CANCEL switch signal.
RESUME/ACC SW On/Off Indicates [On/Off] condition from
RESUME/ACCELERATE switch sig-
nal.
SET SW On/Off Indicates [On/Off] condition from
SET/COAST switch signal.
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1607 of 4801

NISSAN TEANA 2014 Service Manual
DIAGNOSIS SYSTEM (ECM)EC-607
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW1 On/Off
Indicates [On/Off] condition from
brake pedal position switch signal or
ASCD clutch

DIAGNOSIS SYSTEM (ECM)EC-607
< SYSTEM DESCRIPTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW1 On/Off
Indicates [On/Off] condition from
brake pedal position switch signal or
ASCD clutch switch.
BRAKE SW2 On/Off Indicates [On/Off] condition of stop
lamp switch signal.
VHCL SPD CUT Non/
Cut • Indicates the vehicle cruise condi-
tion.
NON: Vehicle speed is maintained
at the ASCD set speed.
CUT: Vehicle speed decreased to
excessively low compared with
the ASCD set speed, and ASCD
operation is cut off.
LO SPEED CUT Non/
Cut • Indicates the vehicle cruise condi-
tion.
NON: Vehicle speed is maintained
at the ASCD set speed.
CUT: Vehicle speed decreased to
excessively low, and ASCD oper-
ation is cut off.
AT OD MONITOR On/Off • Indicates [On/Off] condition of
CVT O/D according to the input
signal from the TCM.
AT OD CANCEL On/Off • Indicates [On/Off] condition of
CVT O/D cancel request signal.
CRUISE LAMP On/Off Indicates [On/Off] condition of
CRUISE lamp dete rmined by the
ECM according to the input signals.
SET LAMP On/Off • Indicates [On/Off] condition of
SET lamp determined by the ECM
according to the input signals.
ALT DUTY % Indicates the duty ratio of the power
generation command value. The ra-
tio is calculated by ECM based on
the battery current sensor signal.
BAT CUR SEN mV The signal voltage of battery current
sensor is displayed.
A/F ADJ-B1
— Indicates the correction of a factor
stored in ECM. The factor is calcu-
lated from the difference between
the target air-fuel ratio stored in ECM
and the air-fuel ratio calculated from
A/F sensor 1 signal.
A/F ADJ-B2
P/N POSI SW On/Off ××Indicates [On/Off] condition from the
park/neutral position (PNP) signal.
INT/A TEMP SE °C or °F ×× The intake air temperature (deter-
mined by the signal voltage of the in-
take air temperature sensor) is
indicated.
AC PRESS SEN V The signal voltage from the refriger-
ant pressure sensor is displayed.
VTC DTY EX B2
*——
Monitored item Unit
Monitor Item Selec-
tion
Description Remarks
ECU IN-
PUT SIG- NALS MAIN-
SIG-
NALS
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1608 of 4801

NISSAN TEANA 2014 Service Manual
EC-608
< SYSTEM DESCRIPTION >[VQ35DE]
DIAGNOSIS SYSTEM (ECM)
EVAP LEAK DIAGYe t / C m -
plt Indicates the condition of EVAP leak
diagnosis.
• YET: EVAP leak diagnosis has not been performed yet

Load next 8 pages

Page: < prev 1-10 ... 1569-1576 1577-1584 1585-1592 1593-1600 1601-1608 1609-1616 1617-1624 1625-1632 1633-1640 ... 4808 next >

air condition trunk four wheel drive lug pattern traction control alternator
