Page 41 of 4801

NISSAN TEANA 2014 Service Manual
BCS-26
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
CONFIGURATION
Refer to
BCS-65, "CONFIGURATION (BCM) : Description".
CAN DIAG SUPPORT MNTR
Refer to LAN-15, "CAN Diagnostic Support Monitor".

Page 42 of 4801

NISSAN TEANA 2014 Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-27
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ACTIVE TEST
TRUNK
TRUNK : CONSULT Function (BCM - TRUNK)INFOID:0000000009462011
CAUTION:
After disconnec

BCS
DIAGNOSIS SYSTEM (BCM)BCS-27
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ACTIVE TEST
TRUNK
TRUNK : CONSULT Function (BCM - TRUNK)INFOID:0000000009462011
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
DATA MONITOR
THEFT ALM
THEFT ALM : CONSULT Function (BCM - THEFT ALM)INFOID:0000000009462012
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
DATA MONITOR
PUSH SW [On/Off] Indicates condition push-button ignition switch.
UNLK SEN -DR [On/Off] Indicates condition of door unlock sensor.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of trunk switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEY CYL LK-SW [On/Off] Indicates condition of lo ck signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unl ock signal from door key cylinder switch.
TRNK/HAT MNTR [On/Off] Indicates condition of trunk room lamp switch.
RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key.
RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key. Monitor Item [Unit] Description
Test item Description
BATTERY SAVER This test is able to check battery saver operation [On/Off].
Monitor Item [Unit] Description
PUSH SW [On/Off] Indicates condition of push-button ignition switch.
UNLK SEN -DR [On/Off] Indicates condition of door unlock sensor.
VEH SPEED 1 [km/h] Indicates vehicle speed signal received from ABS on CAN communication line.
TR CANCEL SW [On/Off] Indicates condition of trunk cancel switch.
TR/BD OPEN SW [On/Off] Indicates condition of trunk opener switch.
TRNK/HAT MNTR [On/Off] Indicates condition of trunk room lamp switch.
RKE-TR/BD [On/Off] Indicates condition of trunk open signal from Intelligent Key.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 43 of 4801

NISSAN TEANA 2014 Service Manual
BCS-28
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
RETAINED PWR
RETAINED PWR : CONSULT Function (BCM - RETAINED PWR)INFOID:0000000009462013
CAUTION:
After disconnect

BCS-28
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
ACTIVE TEST
WORK SUPPORT
RETAINED PWR
RETAINED PWR : CONSULT Function (BCM - RETAINED PWR)INFOID:0000000009462013
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
DATA MONITOR
SIGNAL BUFFER
Monitored Item Description
REQ SW -DR [On/Off] Indicates condition of door request switch LH.
REQ SW -AS [On/Off] Indicates condition of door request switch RH.
REQ SW -BD/TR [ON/OFF] Indicates condition of trunk opener request switch.
PUSH SW [On/Off] Indicates condition of push-button ignition switch.
UNLK SEN -DR [On/Off] Indicates condition of door unlock sensor.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of trunk switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
TR/BD OPEN SW [On/Off] Indicates condition of trunk opener switch.
TRNK/HAT MNTR [On/Off] Indicates condition of trunk room lamp switch.
RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key.
RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key.
RKE-TR/BD [On/Off] Indicates condition of trunk open signal from Intelligent Key.
Test Item Description
FLASHER This test is able to check turn signal lamp operation [LH/RH/Off].
THEFT IND This test is able to check se curity indicator lamp operation [On/Off].
VEHICLE SECURITY HORN This test is able to check vehicle security horn operation [On].
HEADLAMP(HI) This test is able to check vehicle security lamp operation [On].
Support Item Setting Description
SECURITY ALARM SET On Security alarm ON.
Off Security alarm OFF.
Monitor Item [Unit] Description
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 44 of 4801

NISSAN TEANA 2014 Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-29
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
SIGNAL BUFFER : CONSULT Func
tion (BCM - SIGNAL BUFFER)INFOID:0000000009462014
CAUTION:
After disconnect

BCS
DIAGNOSIS SYSTEM (BCM)BCS-29
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
SIGNAL BUFFER : CONSULT Func
tion (BCM - SIGNAL BUFFER)INFOID:0000000009462014
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
DATA MONITOR
AIR PRESSURE MONITOR
AIR PRESSURE MONITOR : CONSULT Fu nction (BCM-AIR PRESSURE MONITOR)
INFOID:0000000009462015
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentiall y causing a discharged battery and a no-start condition.
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure repor ted by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
SELF DIAGNOSTIC RESULT
NOTE:
Before performing Self Diagnostic Result, be sure to regi ster the transmitter ID or the actual malfunction may
be different from that displayed on CONSULT.
Refer to BCS-52, "DTC Index"
.
DATA MONITOR
ACTIVE TEST
Monitor Item [Unit] Description
PUSH SW [On/Off] Indicates condition of the push-button ignition switch.
Monitor Item [Unit] Description
AIR PRESS FL [kPa, kg/cm
2 or Psi] Indicates air pressure of front LH tire.
AIR PRESS FR [kPa, kg/cm
2 or Psi] Indicates air pressure of front RH tire.
AIR PRESS RR [kPa, kg/cm
2 or Psi] Indicates air pressure of rear RH tire.
AIR PRESS RL [kPa, kg/cm
2 or Psi] Indicates air pressure of rear LH tire.
ID REGST FL1 [Done/Yet] Indicates ID registration status of front LH transmitter.
ID REGST FR1 [Done/Yet] Indicates ID registration status of front RH transmitter.
ID REGST RR1 [Done/Yet] Indicates ID registration status of rear RH transmitter.
ID REGST RL1 [Done/Yet] Indicates ID registration status of rear LH transmitter.
WARNING LAMP [Off/On] Indicates condition of low tire pressure warning lamp in combination meter.
BUZZER [Off/On] Indicates condition of buzzer in combination meter.
Test Item Description
FLASHER This test is able to check turn signal lamp operation [Off/LH/RH].
HORN This test is able to check horn operation [On].
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 45 of 4801

NISSAN TEANA 2014 Service Manual
BCS-30
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
WORK SUPPORT
WARNING LAMP This test is able to check tire pressure warning lamp operation [On/Off].
ID REGIST WARNING This test is able to c

Page 46 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-31
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ECU DIAGNOSIS INFORMATION
BCM (BODY CONTROL MODULE)
Reference ValueINFOID:0000000009462016
NOTE

BCS
BCM (BODY CONTROL MODULE)BCS-31
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ECU DIAGNOSIS INFORMATION
BCM (BODY CONTROL MODULE)
Reference ValueINFOID:0000000009462016
NOTE:
The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II
User Guide for additional information.
• Activate and display TPMS transmitter IDs
• Display tire pressure repor ted by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Check Intelligent Key relative signal strength
• Confirm vehicle Intelligent Key antenna signal strength
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Condition Value/Status
ACC BATTERY SAVER When battery saver is OFF. STOP
ACC RLY -REQ When BCM is not requesting accessory relay activation. Off
When BCM is requesting accessory relay activation. On
AIR COND SW A/C switch OFF Off
A/C switch ON On
AIR PRESS FL Front left tire air pressure value kPa, kg/cm
2, psi
AIR PRESS FR Front right tire air pressure value kPa, kg/cm
2, psi
AIR PRESS RL Rear left ti re air pressure value
kPa, kg/cm
2, psi
AIR PRESS RR Rear right ti re air pressure value
kPa, kg/cm
2, psi
AUTO CRNK TME Remote engine start timer duration. sec
AUTO CRNK TMR When the remote engine start timer is OFF. Off
When the remote engine start timer is ON. On
AUTO LIGHT SW Lighting switch OFF Off
Lighting switch AUTO On
BRAKE SW 1 When the brake pedal is released On
When the brake pedal is depressed Off
BRAKE SW2 Brake pedal released Off
Brake pedal depressed On
BUZZER Buzzer in combination meter OFF Off
Buzzer in combination meter ON On
CDL LOCK SW Door lock/unlock switch does not operate Off
Press door lock/unlock switch to the LOCK side On
CDL UNLOCK SW Door lock/unlock switch does not operate Off
Press door lock/unlock switch to the UNLOCK side On
CONFRM ID ALL The key ID does not match any key ID registered to BCM. Yet
The key ID matches any key ID registered to BCM. DONE
CONFIRM ID4 The key ID does not match the fourth key ID registered to BCM. Yet
The key ID matches the fourth key ID registered to BCM. DONE
CONFIRM ID3 The key ID does not match the third key ID registered to BCM. Yet
The key ID matches the third key ID registered to BCM. DONE
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 47 of 4801

NISSAN TEANA 2014 Service Manual
BCS-32
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
CONFIRM ID2The key ID does not match the second key ID registered to BCM. Yet
The key ID matches the second key ID registered to B

BCS-32
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
CONFIRM ID2The key ID does not match the second key ID registered to BCM. Yet
The key ID matches the second key ID registered to BCM. DONE
CONFIRM ID1 The key ID does not match the first key ID registered to BCM. Yet
The key ID matches the first key ID registered to BCM. DONE
CRANKING TME Engine start timer duration. sec
CRNK PRBT TME Engine start prohibit timer duration. sec
CRNK PRBT TMR When the engine start prohibit timer is OFF. Off
When the engine start prohibit timer is ON. On
DETE SW -IPDM When selector lever is in P position Off
When selector lever is in any position other than P On
DETE SW PWR When BCM is not supplying power to detent switch. Off
When BCM is supplying power to detent switch. On
DETE/CANCL SW When selector lever is in P position Off
When selector lever is in any position other than P On
DOOR STAT-AS Passenger door LOCK status LOCK
Passenger door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR STAT-DR Driver door LOCK status LOCK
Driver door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR STAT-RL Rear left door LOCK status LOCK
Rear left door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR STAT-RR Rear right door LOCK status LOCK
Rear right door UNLOCK status UNLK
Wait with selective UNLOCK operation (5 seconds) READY
DOOR SW-AS Front door RH closed Off
Front door RH opened On
DOOR SW-BK Trunk closed Off
Trunk opened On
DOOR SW-DR Front door LH closed Off
Front door LH opened On
DOOR SW-RL Rear door LH closed Off
Rear door LH opened On
DOOR SW-RR Rear door RH closed Off
Rear door RH opened On
ENGINE STATE Engine stopped STOP
While the engine stalls STALL
At engine cranking CRANK
Engine running RUN
FA N O N S I G Blower motor fan switch OFF Off
Blower motor fan switch ON On
FR FOG SW Front fog lamp switch OFF Off
Front fog lamp switch ON On
Monitor Item Condition Value/Status
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 48 of 4801

NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-33
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
FR WASHER SW
Front washer switch OFF Off
Front washer switch ON On
FR WIPER LOW Front wiper sw

BCS
BCM (BODY CONTROL MODULE)BCS-33
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
FR WASHER SW
Front washer switch OFF Off
Front washer switch ON On
FR WIPER LOW Front wiper switch OFF Off
Front wiper switch LO On
FR WIPER HI Front wiper switch OFF Off
Front wiper switch HI On
FR WIPER INT Front wiper switch OFF Off
Front wiper switch INT On
FR WIPER STOP Any position other than front wiper stop position Off
Front wiper stop position On
HAZARD SW When hazard switch is not pressed Off
When hazard switch is pressed On
HEAD LAMP SW 1 Headlamp switch OFF Off
Headlamp switch 1st On
HEAD LAMP SW 2 Headlamp switch OFF Off
Headlamp switch 1st On
HI BEAM SW High beam switch OFF Off
High beam switch HI On
ID AUTHENT CANCEL TIMER When I-Key authentication is OFF. STOP
ID OK FLAG Ignition switch ACC or ON Reset
Ignition switch OFF Set
ID REGST FL1 ID registration of front left tire incomplete YET
ID registration of front left tire complete DONE
ID REGST FR1 ID registration of front right tire incomplete YET
ID registration of front right tire complete DONE
ID REGST RL1 ID registration of rear left tire incomplete YET
ID registration of rear left tire complete DONE
ID REGST RR1 ID registration of rear
right tire incomplete YET
ID registration of rear right tire complete DONE
IGN RLY1 F/B Ignition switch OFF or ACC Off
Ignition switch ON On
INT VOLUME Wiper intermittent dial is in a dial position 1 - 7 1 - 7
I-KEY OK FLAG I-Key OFF Key OFF
I-Key ON Key ON
KEY CYL LK-SW Door key cylinder LOCK position Off
Door key cylinder other than LOCK position On
KEY CYL UN-SW Door key cylinder UNLOCK position Off
Door key cylinder other than UNLOCK position On
OPTI SEN (DTCT) Bright outside of the vehicle Close to 5V
Dark outside of the vehicle Close to 0V
OPTI SEN (FILT) Bright outside of the vehicle Close to 5V
Dark outside of the vehicle Close to 0V
PA S S I N G S W Other than lighting switch PASS Off
Lighting switch PASS On
Monitor Item Condition Value/Status
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Load next 8 pages

Page: < prev 1-10 ... 9-16 17-24 25-32 33-40 41-48 49-56 57-64 65-72 73-80 ... 4808 next >

oil dipstick ignition technical specifications child lock oil type immobilizer
