3. Check continuity between optical sensor harness connector M66 and BCM harness connector M17.
4. Check continuity between optical sensor harness connector M66 terminal 1 and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Repair or replace the harness or connectors.
4.CHECK OPTICAL SENSOR SIGNAL OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect optical sensor connector and BCM connector.
3. Check continuity between optical sensor harness connector and BCM harness connector.
4. Check continuity between optical sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace the optical sensor. Refer to EXL-141, "Removal and Installation".
NO >> Repair or replace harness or connectors.
5.CHECK OPTICAL SENSOR GROUND FOR OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the BCM harness connector M17.
3. Check continuity between optical sensor harnes s connector M66 terminal 3 and BCM harness connector
M17 terminal 17.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Repair or replace harness or connector.
Optical sensor BCM Continuity
Connector Terminal Connector Terminal
M66 1 M17 3 Yes
(+) (− )Continuity
Connector Terminal
M66 1 Ground No
Optical sensor BCM Continuity
Connector Terminal Connector Terminal
M66 2 M17 4 Yes
Connector Terminal ( −)Continuity
M66 2 Ground No
Optical sensor BCM Continuity
Connector Terminal Connector Terminal
M66 3 M17 17 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2378 of 4801

EXL-112
< DTC/CIRCUIT DIAGNOSIS >
HAZARD SWITCH
HAZARD SWITCH
Component Function CheckINFOID:0000000009463603
1.CHECK HAZARD SWITCH SIGNAL BY CONSULT
CONSULT DATA MONITOR
1. Turn ignition switch ON.
2. Select HAZARD SW of BCM (F LASHER) Data Monitor item.
3. While operating the hazard switch, check the monitor status.
Is the inspection result normal?
YES >> Hazard switch circuit is normal.
NO >> Refer to EXL-112, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009463604
Regarding Wiring Diagram information, refer to EXL-60, "Wiring Diagram".
1.CHECK HAZARD SWITCH SIGNAL INPUT
1. Turn ignition switch OFF.
2. Disconnect hazard switch connector.
3. Turn ignition switch ON.
4. Check voltage between hazard s witch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK HAZARD SWITCH SIGNAL OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector M17.
3. Check continuity between hazard har ness connector and BCM harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
Monitor item Condition Monitor status
HAZARD SW Hazard switch ON On
OFF Off
(+) (− ) Vol tag e
(Approx.)
Hazard switch
Connector Terminal
M54 2 Ground
JPMIA0154GB
Hazard switch BCM Continuity
Connector Terminal Connector Terminal
M54 2 M17 36 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2379 of 4801
HAZARD SWITCHEXL-113
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
3.CHECK HAZARD SWITCH SIGNAL SHORT CIRCUIT
Check continuity between hazard switch harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Repair or replace harness or connector.
4.CHECK HAZARD SWITCH GROUND OPEN CIRCUIT
Check continuity between hazard switch harness connector and ground.
Is the inspection result normal?
YES >> Replace hazard switch. Refer to EXL-140, "Removal and Installation".
NO >> Repair or replace harness or connector.
Hazard switch
GroundContinuity
Connector Terminal
M54 2 No
Hazard switch GroundContinuity
Connector Terminal
M54 1 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2380 of 4801

EXL-114
< SYMPTOM DIAGNOSIS >
EXTERIOR LIGHTING SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
EXTERIOR LIGHTING SYSTEM SYMPTOMS
Symptom TableINFOID:0000000009463605
CAUTION:
Perform the self-diagnosis with CONSULT before th e symptom diagnosis. Perform the trouble diagno-
sis if any DTC is detected.
Symptom Possible cause Inspection item
Headlamp does not
switch to the high beam. One side•Bulb
•Fuse
• Harness between IPDM E/R and the front combination lamp
• Harness between the front combination lamp and ground
• IPDM E/R Headlamp (HI) circuit
Refer to EXL-91
.
Both sides — Symptom diagnosis
"BOTH SIDE HEADLAMPS DO
NOT SWITCH TO HIGH BEAM"
Refer to EXL-117
.
High beam indicator lamp is not turned ON.
(Headlamp switches to the high beam.) • Combination meter
•BCM • Combination meter.
Data monitor "HI-BEAM IND"
• BCM (HEAD LAMP) Active test "HEADLAMP"
Headlamp does not
switch to the low beam. Both sides• Combination switch (lighting
and turn signal switch)
• Harness between the combina- tion switch (lighting and turn sig-
nal switch) and BCM
•BCM Combination switch (lighting and
turn signal switch)Refer to BCS-79
.
High beam request signal
•BCM
• IPDM E/R IPDM E/R
Data monitor "HL HI REQ"
Headlamp does not turn
ON. One side•Fuse
•Bulb
• Harness between IPDM E/R and the front combination lamp
• Harness between the front combination lamp and ground
• IPDM E/R Headlamp (L
O) circuit
Halogen, refer to EXL-93
.
Xenon, refer to EXL-95
Both sides — Symptom diagnosis
"BOTH SIDE HEADLAMPS (LO)
ARE NOT TURNED ON"
Refer to EXL-119
.
Headlamp does not turn
OFF. When the ignition
switch is turned ON •BCM
• Combination switch (lighting and turn signal switch) Combination switch (lighting and
turn signal switch)
Refer to BCS-8
.
The ignition switch is
turned OFF (After acti-
vating the battery sav-
er). IPDM E/R —
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2381 of 4801

EXTERIOR LIGHTING SYSTEM SYMPTOMSEXL-115
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
Headlamp is not turned ON/OFF with the lighting
switch AUTO. • Combination switch (lighting
and turn signal switch)
• Harness between the combina- tion switch (lighting and turn sig-
nal switch) and BCM
•BCM
• IPDM E/R Combination switch (lighting and
turn signal switch)
Refer to BCS-79.
• Optical sensor
• Harness between the optical
sensor and BCM
•BCM Optical sensor
Refer to EXL-110
.
Daytime light system does not activate. —Symptom diagnosis
"DAYTIME LIGHT SYSTEM INOP-
ERATIVE"
Refer to EXL-118
.
Front fog lamp is not
turned ON. One side
• Front fog lamp bulb
• Harness between IPDM E/R
and the front fog lamp
• Harness between the front fog lamp and ground
• IPDM E/R Front fog lamp circuit
Refer to EXL-101
.
Both side — Symptom diagnosis
"BOTH SIDE FRONT FOG LAMPS
ARE NOT TURNED ON"
Refer to EXL-121
.
Parking lamp is not turned
ON. One side•Fuse
• Parking lamp bulb
• Harness between IPDM E/R
and the front/rear combination
lamp
• Harness between the front/rear
combination lamp and ground
• IPDM E/R Parking lamp circuit
Refer to EXL-103
.
Both sides — Symptom diagnosis
"PARKING, LICENSE PLATE AND
TAIL LAMPS ARE NOT TURNED
ON"
Refer to EXL-120
.
Turn signal lamp does not
blink. Indicator lamp is nor-
mal.
(The applicable side
performs the high flash-
er activation). • Harness between BCM and
each turn signal lamp
• Turn signal lamp bulb
• Door mirror (if equipped with
turn signals in the door mirrors) Turn signal lamp circuit
Refer to EXL-106
.
Turn signal indicator lamp
does not blink. One side Combination meter —
Both sides
(Always) • Turn signal indicator lamp sig-
nal
• Combination meter
•BCM • Combination meter.
Data monitor "TURN IND"
• BCM (FLASHER) Active test "FLASHER"
Both sides
(Does blink when acti-
vating the hazard warn-
ing lamp with the
ignition switch OFF) • The combination meter power
supply and the ground circuit
• Combination meter Combination meter
Power supply and the ground circuit
Refer to MWI-58
.
• Hazard warning lamp does not activate.
• Hazard warning lamp continues activating. (Turn signal is normal) • Hazard switch
• Harness between the hazard switch and BCM
•BCM Hazard switch
Refer to EXL-112
.
Symptom Possible cause Inspection item
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2382 of 4801
EXL-116
< SYMPTOM DIAGNOSIS >
NORMAL OPERATING CONDITION
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000009463606
XENON HEADLAMP
• The brightness and color of the light may vary slightly immediately after turning the headlamp ON. This con-
dition will remain until the xenon bulb becomes stable. This is normal.
• Illumination time lag may occur between right and left. This is normal.
AUTO LIGHT SYSTEM
The auto light system may not turn the headlamp ON/OF F immediately after passing a dark area or a bright
area (short tunnel, sky bridge, shadowed area etc.). This is normal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2383 of 4801

BOTH SIDE HEADLAMPS DO NOT SWITCH TO HIGH BEAM
EXL-117
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
K
M A
B
EXL
N
O P
BOTH SIDE HEADLAMPS DO NOT SWITCH TO HIGH BEAM
DescriptionINFOID:0000000009463607
The headlamps (both sides) do not switch to high beam when the lighting switch is in the HI or PASS setting.
Diagnosis ProcedureINFOID:0000000009463608
1.COMBINATION SWITCH (LIGHTING AND TURN SIGNAL SWITCH) INSPECTION
Check the combination switch (lighting and turn signal switch). Refer to BCS-79, "Symptom Table"
.
Is the inspection results normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning part.
2.CHECK HEADLAMP (HI) REQUEST SIGNAL INPUT
CONSULT DATA MONITOR
1. Select HL HI REQ of IP DM E/R DATA MONITOR item.
2. While operating the lighting switch, check the monitor status.
Is the inspection results normal?
YES >> GO TO 3
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
3.HEADLAMP (HI) CIRCUIT INSPECTION
Check the headlamp (HI) circuit. Refer to EXL-91, "Diagnosis Procedure"
.
Is the inspection results normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace the malfunctioning part.
Monitor item Condition Monitor status
HL HI REQ Lighting switch
(2nd) HI or PASS ON
Except for HI or PASS OFF
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 2384 of 4801

EXL-118
< SYMPTOM DIAGNOSIS >
DAYTIME LIGHT SYSTEM INOPERATIVE
DAYTIME LIGHT SYSTEM INOPERATIVE
DescriptionINFOID:0000000009463609
The daytime light system is inoperative even though the combination switch (lighting and turn signal switch)
and parking brake switch are in the normal setting, also whenever engine is operating.
Diagnosis ProcedureINFOID:0000000009463610
1.CHECK DAYTIME LIGHT OPERATION
1. Perform BCM(HEADLAMP) DAYTIME RUNNING LIGHT active test. Refer to BCS-19, "HEADLAMP :
CONSULT Function (BCM - HEADLAMP)".
2. Check that the daytime lights turn on.
Is the inspection results normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> GO TO 2.
2.CHECK DAYTIME LIGHT RELAY FUSE
1. Turn ignition switch OFF.
2. Check that the following fuse is not blown.
Is the fuse blown?
YES >> Replace the blown fuse after repairing the affected circuit.
NO >> GO TO 3.
3.CHECK DAYTIME LIGHT BULBS
Check the daytime light bulbs are not open.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace the bulbs.
4.PERFORM DAYTIME LIGH T CIRCUIT INSPECTION
Check the daytime light circuit. Refer to EXL-98, "Diagnosis Procedure"
.
Is the inspection results normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> Repair or replace the malfunctioning part.
Unit Fuse No. Capacity
Daytime light 43 10 A
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
