Page 921 of 4801

NISSAN TEANA 2014 Service Manual
DOOR LOCK FUNCTION SYMPTOMSDLK-153
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Symptom TableINFOID:

DOOR LOCK FUNCTION SYMPTOMSDLK-153
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Symptom TableINFOID:0000000009461908
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the follo wing table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms are detec ted, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT.
• Intelligent Key is out of key slot.
• All doors are closed.
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH : Symptom TableINFOID:0000000009461909
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the follo wing table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms” are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Symptom Diagnosis/service procedure Reference
page
Power door locks do not operate with door lock
and unlock switch. 1. Check BCM Power supply and ground circuit.
BCS-74
2. Check door lock and unlock switch.DLK-103
3. Check door lock actuator (driver side)DLK-135
4. Check Intermittent Incident. GI-43
Power door locks do not operate with door key
cylinder operation.
(Power door locks operate properly with door
lock and unlock switch.) 1. Check key cylinder switch.
DLK-115
2. Replace power window main switch.PWC-65
(LH
only anti-pinch) or PWC-142

(LH & RH front anti-pinch).
Specific door lock actuator does not operate. 1. Check door lock actuator.Driver side
DLK-135
Passenger sideDLK-136
Rear LHDLK-137
Rear RHDLK-138
2. Check Intermittent Incident. GI-43
Vehicle speed sensing auto door LOCK opera-
tion does not operate. 1. Ensure automatic door lock/unlock function (lock opera-
tion) is enabled. BCS-66
2. Check combination meter vehicle speed signal.
MWI-55
3. Check intermittent incident. GI-43
Ignition OFF interlock auto door UNLOCK
function does not operate. 1. Ensure automatic door lock/unlock function (unlock op-
eration) is enabled. BCS-66
2. Check BCM for DTCs.
BCS-50
3. Check intermittent incident. GI-43
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 922 of 4801

NISSAN TEANA 2014 Service Manual
DLK-154
< SYMPTOM DIAGNOSIS >
DOOR LOCK FUNCTION SYMPTOMS
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT.
• Intelligent Key is out of key

DLK-154
< SYMPTOM DIAGNOSIS >
DOOR LOCK FUNCTION SYMPTOMS
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT.
• Intelligent Key is out of key slot.
• All doors are closed.
INTELLIGENT KEY
INTELLIGENT KEY : Symptom TableINFOID:0000000009461910
REMOTE KEYLESS ENTRY FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Intelligent Key is out of key slot.
• Ignition switch is in OFF or ACC position.
• All doors are closed.
• Retained power operation does not operate.
Symptom Diagnosis/service procedure Reference
page
Door lock/unlock system does not operate by
door request switch. 1. Check BCM power supply and ground circuit.
BCS-74
2. Check door switch.DLK-100
3. Check Intermittent Incident. GI-43
Door lock/unlock system does not operate by
request switch (driver side). 1. Check door request
switch (driver side). DLK-1292. Check outside key antenna (driver side). D L K - 111
3. Check Intermittent Incident. GI-43
Door lock/unlock system does not operate by
request switch (passenger side). 1. Check door request switch (passenger side).
DLK-1292. Check outside key antenna (passenger side).DLK-109
3. Check Intermittent Incident. GI-43
Selective unlock function does not operate by
door request switch (dri ver side) (other door
lock function operate). 1.
Check “DOOR LOCK-UNLOCK
SET” setting in “WORK
SUPPORT”. DLK-43
2.
Check selective unlock function with a remote controller
or door key cylinder. DLK-103
3. Check Intermittent Incident.
GI-43
Selective unlock function does not operate by
door request switch (passenger side) (other
door lock functions operate). 1.
Check “DOOR LOCK-UNLOCK
SET” setting in “WORK
SUPPORT”. DLK-43
2. Check Intermittent Incident.
GI-43
Auto lock function does not operate.1.
Check “AUTO LOCK SET” setting in “WORK SUP-
PORT”. DLK-432. Check door switch.
DLK-100
3. Check Intermittent Incident. GI-43
Symptom Diagnosis/service procedure Reference
page
All of the remote keyless entry functions do
not operate. 1. Check Intelligent Key battery inspection.
DLK-146
2. Check Intermittent Incident. GI-43
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 923 of 4801

NISSAN TEANA 2014 Service Manual
DOOR LOCK FUNCTION SYMPTOMSDLK-155
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Selective unlock function does not operate
by Intelligent Key. 1.
Check “DOOR LOCK-UNLOCK SET” setti

Page 924 of 4801

NISSAN TEANA 2014 Service Manual
DLK-156
< SYMPTOM DIAGNOSIS >
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH : Symptom TableINFOID:0000000009461911
TRUNK OPEN FUNCTION MALF

DLK-156
< SYMPTOM DIAGNOSIS >
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH : Symptom TableINFOID:0000000009461911
TRUNK OPEN FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Intelligent Key is out of key slot.
• All doors are closed.
TRUNK REQUEST SWITCH
TRUNK REQUEST SWITCH : Symptom TableINFOID:0000000009461912
TRUNK OPEN FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Intelligent Key is out of key slot.
• All doors are closed.
INTELLIGENT KEY
INTELLIGENT KEY : Symptom TableINFOID:0000000009461913
TRUNK OPEN FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “WORK FLOW”. Refer to DLK-81, "Work Flow"
.
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following symptoms” are detected, check syste ms shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Intelligent Key is out of key slot.
• All doors are closed.
Symptom Diagnosis/service procedure Reference page
Trunk open function does not operate by trunk
opener switch. 1. Check trunk opener switch.
DLK-122

2. Check trunk lid opener cancel switch. DLK-124
3. Check Intermittent Incident. GI-43
Symptom Diagnosis/service procedure Reference page
Trunk open function does not operate by trunk
opener request switch. 1. Check trunk opener request switch.
DLK-132

2. Check trunk lid opener cancel switch. DLK-124
3. Check outside key antenna (rear bumper). DLK-113
4. Check Intermittent Incident. GI-43
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 925 of 4801

NISSAN TEANA 2014 Service Manual
TRUNK OPEN FUNCTION SYMPTOMSDLK-157
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Symptom Diagnosis/service procedure Reference page
Trunk open function does not operate by Intel-
ligent

Page 926 of 4801

NISSAN TEANA 2014 Service Manual
DLK-158
< SYMPTOM DIAGNOSIS >
WARNING FUNCTION SYMPTOMS
WARNING FUNCTION SYMPTOMS
Symptom TableINFOID:0000000009461914
WARNING FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the f

Page 927 of 4801

NISSAN TEANA 2014 Service Manual
WARNING FUNCTION SYMPTOMSDLK-159
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
Take away warning
does not operate. Door open to close
1. Check door switch.
DLK-100
2. Check inside key a

Page 928 of 4801

NISSAN TEANA 2014 Service Manual
DLK-160
< SYMPTOM DIAGNOSIS >
KEY REMINDER FUNCTION SYMPTOMS
KEY REMINDER FUNCTION SYMPTOMS
Symptom TableINFOID:0000000009461915
KEY REMINDER FUNCTION MALFUNCTION
NOTE:
• Before performing the dia
