Page 417 of 4801

NISSAN TEANA 2014 Service Manual
ENGINE COOLANTCO-37
< PERIODIC MAINTENANCE > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
• Do not allow the coolant to
contact the drive belts.
• Perform this step when engine is cold.
5. When dr

Page 418 of 4801

NISSAN TEANA 2014 Service Manual
CO-38
< PERIODIC MAINTENANCE >[VQ35DE]
ENGINE COOLANT
4. Install the Tool by installing the radiator cap adapter onto the
radiator neck opening. Then attach the gauge body assembly
with the refill t

CO-38
< PERIODIC MAINTENANCE >[VQ35DE]
ENGINE COOLANT
4. Install the Tool by installing the radiator cap adapter onto the
radiator neck opening. Then attach the gauge body assembly
with the refill tube and the venturi assembly to the radiator cap
adapter.
5. Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed
position.
• Use recommended coolant or equivalent.
Refer to MA-11, "FOR USA AND CANADA : Fluids and Lubri-
cants".
CAUTION:
Do not use any cooling system additives such as radiator
sealer. Additives may clog th e cooling system and cause
damage to the engine, transm ission and/or cooling system.
6. Install an air hose to the venturi assembly, the air pressure must be within specification.
CAUTION:
The compressed air supply must be equipped with an air dryer.
7. The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Coolant will be vi sible rising in the refill hose. Once the refill hose is
full of coolant, close the ball valve. This will purge any air trapped in the refill hose.
8. Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude
locations, use the vacuum specifications based on the altitude
above sea level.
9. When the vacuum gauge has reached the specifi ed amount, disconnect the air hose and wait 20 seconds
to see if the system loses any vacuum. If the vacuum level drops, perform any necessary repairs to the
system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for any leaks.
10. Place the coolant container (with the refill hose insert ed) at the same level as the top of the radiator. Then
open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling
system is full when the vacuum gauge reads zero.
CAUTION:
Do not allow the coolant container to get too low when filling, to avoid air from being drawn into
the cooling system.
11. Remove the Tool from the radiator neck opening.
12. Fill the cooling system reservoir tank to the specif ied level and install the radiator cap. Run the engine to
warm up the cooling system and t op up the system as necessary.
13. Install the engine under cover. Refer to EXT-17, "Removal and Installation"
.
FLUSHING COOLING SYSTEM
Tool number : KV991J0070 (J-45695)
Engine coolant capacity
(with reservoir tank) : Refer to
CO-53, "Capacity"
.
Compressed air
supply pressure : 549 - 824 kPa (5.6 - 8.4 kg/cm
2,
80 - 119 psi)
LLIA0058E
Altitude above sea level Vacuum gauge reading
0 - 100 m (328 ft) : 28 inches of vacuum
300 m (984 ft) : 27 inches of vacuum
500 m (1,641 ft) : 26 inches of vacuum
1,000 m (3,281 ft) : 24 - 25 inches of vacuum
LLIA0057E
Revision: November 20132014 Altima NAM

Page 419 of 4801

NISSAN TEANA 2014 Service Manual
ENGINE COOLANTCO-39
< PERIODIC MAINTENANCE > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
1. Fill the radiator from the filler neck above the r
adiator upper hose and reservoir tank with clean water and

Page 420 of 4801

NISSAN TEANA 2014 Service Manual
CO-40
< REMOVAL AND INSTALLATION >[VQ35DE]
RADIATOR
REMOVAL AND INSTALLATION
RADIATOR
Exploded ViewINFOID:0000000009460415
WARNING:
Do not remove the radiator cap when the engine is hot. Serious bu

Page 421 of 4801

NISSAN TEANA 2014 Service Manual
RADIATORCO-41
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
Removal and InstallationINFOID:0000000009460416
REMOVAL
1. Remove radiator cap and drain coolant from radiator. Re

RADIATORCO-41
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
Removal and InstallationINFOID:0000000009460416
REMOVAL
1. Remove radiator cap and drain coolant from radiator. Refer to
CO-12, "Changing Engine Coolant".
CAUTION:
• Perform this step when the engine is cold.
• Do not spill coolant on the drive belt.
2. Remove front air duct. Refer to EM-29, "Removal and Installation"
.
3. Disconnect coolant reservoir hose from the radiator.
4. Remove fender protector side cover (LH/RH). Refer to EXT-26, "FENDER PROTECTOR : Exploded
View".
5. Disconnect radiator hose (upper) and radiat or hose (lower) from the radiator.
CAUTION:
Do not allow the coolant to contact the drive belt.
NOTE:
The radiator hose clamps on the radiator hose (upper ) and on the radiator hose (lower), are not serviced
separately. Radiator hose clamps are part of the radiator hose assembly and serviced as one unit with the
radiator hose.
6. Disconnect the CVT oil cooler hoses.
7. Remove the front bumper fascia. Refer to EXT-17, "Removal and Installation"
.
8. Remove A/C condenser. Refer to HA-30, "COMPRESSOR : Removal and Installation"
.
CAUTION:
Be careful not to damage condenser core.
9. Remove the radiator mounts (upper).
10. Remove radiator. CAUTION:
Do not damage or scratch the radiator core when removing.
INSTALLATION
Installation is in the reverse order of removal.
• After installation, refill coolant and check for leaks. Refer to CO-12, "Changing Engine Coolant"
and CO-11,
"System Inspection".
CAUTION:
Do not spill coolant in engi ne compartment. Use a shop cloth to absorb coolant.
InspectionINFOID:0000000009460417
INSPECTION AFTER INSTALLATION
• Check that the reservoir tank cap is tightened.
• Check for leakage of engine coolant using Tool (B) and suitable tool (A). Refer to CO-35, "System Inspection"
.
WARNING:
Do not remove the radiator cap wh en the engine is hot. Seri-
ous burns could occur from high pressure coolant escaping
from the radiator.
CAUTION:
Higher pressure than specified may cause radiator damage.
• Start and warm up the engine. Visually check that there is no leakage of engine coolant and CVT fluid (CVT
models). Tool number : EG17650301 (J-33984-A)
Testing pressure : Refer to CO-53, "Radiator"
.
AWBIA0740ZZ
Revision: November 20132014 Altima NAM

Page 422 of 4801

NISSAN TEANA 2014 Service Manual
CO-42
< REMOVAL AND INSTALLATION >[VQ35DE]
COOLING FAN
COOLING FAN
Exploded ViewINFOID:0000000009460418
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur fro

Page 423 of 4801

NISSAN TEANA 2014 Service Manual
COOLING FANCO-43
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
3. Remove the core support cover clips (A), then remove the core
support cover (1).
4. Remove front air duct. R

Page 424 of 4801

NISSAN TEANA 2014 Service Manual
CO-44
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000009460420
Removal and InstallationINFOID:0000000009460421
WARNING:
Do not remove the radiator cap when the
