P117A AIR FUEL RATIOEC-417
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P117A AIR FUEL RATIO
DTC LogicINFOID:0000000009462347
DTC DETECTION LOGIC
NOTE:
If DTC P117A is display

P117A AIR FUEL RATIOEC-417
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P117A AIR FUEL RATIO
DTC LogicINFOID:0000000009462347
DTC DETECTION LOGIC
NOTE:
If DTC P117A is displayed with other DTC, first perf orm the trouble diagnosis for the other DTC. Refer
to EC-105, "DTC Index"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING-1
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
NOTE:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PRECONDITIONING-2
1. Turn ignition switch ON.
2. Clear the mixture ratio self-learning value. Refer to EC-181, "Work Procedure"
.
Will CONSULT be used?
YES >> GO TO 3.
NO >> GO TO 6.
3.PERFORM DTC CONFIRMATION PROCEDURE-1
1. Turn ignition switch ON.
2. Select “COOLAN TEMP/S” in “DATA MONI TOR” mode of “ENGINE” using CONSULT.
3. Start engine.
4. Make sure that “COOLAN TEMP/S” indicates more than 80 °C (176 °F).
>> GO TO 4.
4.PERFORM DTC CONFIRMATION PROCEDURE-2
With CONSULT
1. Select “SYSTEM 1 DIAGNOSIS B B1” and “SYSTEM 1 DIAGNOSIS A B1” in “DATA MONITOR” mode of
“ENGINE” using CONSULT.
2. Drive vehicle under the following conditions for at least 5 consecutive seconds.
CAUTION:
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P117A AIR FUEL RATIO B1
(AIR FUEL RATIO B1) ECM detects a lean/rich air fuel ratio state in any
cylinder for a specified length of time. • Fuel injector
• Exhaust gas leaks
• Incorrect fuel pressure
• Mass air flow sensor
• Intake air leaks
• Lack of fuel
• Incorrect PCV hose connection
• Improper spark plug
• Insufficient compression
• The fuel injector circuit is open or shorted
• ignition coil
• The ignition signal circuit is open or shorted
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1418 of 4801

NISSAN TEANA 2014 Service Manual
EC-418
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P117A AIR FUEL RATIO
• Always drive vehicle at a safe speed.
NOTE:
• Drive the vehicle at approximately 88 km/h (55MPH) allows easy diagnosis.
• Keep

Page 1419 of 4801

NISSAN TEANA 2014 Service Manual
P117A AIR FUEL RATIOEC-419
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
1. Stop engine and visually check exhaust tube, three way catalyst and muffler for dents connection.
2.

Page 1420 of 4801

NISSAN TEANA 2014 Service Manual
EC-420
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P117A AIR FUEL RATIO
Perform the following procedure in a place with
no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Confirm th

EC-420
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P117A AIR FUEL RATIO
Perform the following procedure in a place with
no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Confirm that the engine is cooled down and there are no fire hazards near the vehicle.
3. Disconnect all fuel injector harness connectors.
4. Remove fuel tube assembly. Refer to EM-41, "Removal and Installation"
.
Keep fuel hose and all fuel injectors connected to fuel tube.
5. Disconnect all ignition coil harness connectors.
6. Prepare pans or saucers under each fuel injector.
7. Crank engine for approximately 3 seconds.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace fuel injector. Refer to EM-41, "Removal and
Installation".
7.CHECK FUNCTION OF IGNITION COIL-1
CAUTION:
Perform the following steps in a well -ventilated area with no combustibles.
1. Turn ignition switch OFF.
2. Remove fuel pump fuse from IPDM E/R to release fuel pressure.
NOTE:
CONSULT must not be used to release fuel pressu re. It develops again during the following steps,
if released by using CONSULT.
3. Start the engine.
4. After an engine stall, crank the engine two or three times to release all the fuel pressure.
5. Turn ignition switch OFF.
6. Disconnect all the harness connectors of ignition coil to prevent electric discharge from occurring in igni-
tion coil.
7. Remove ignition coil assembly and spark plug of cylinder. Refer to EM-40, "Removal and Installation"
.
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect spark plug and harness connector to ignition coil.
10. Allow a 13-17mm (0.52-0.66 in) spacing between spark plug and
grounded metal portion as shown in the figure to fix the ignition
coil with a rope or an equivalent.
11. Crank the engine for approximately 3 seconds to see if sparking occurs between spark plug and the grounded metal portion.
CAUTION:
• The discharge voltage becomes 20 kV or higher. There- fore, always stay away from the spark plug and ignition
coil at least 50 cm (19.7 in) during the inspection.
• Leaving a space of more than 17mm (0.66 in) may damage the ignition coil.
NOTE:
When the gap is less than 13 mm (0.52 in), a the sp ark might be generated even if the coil is mal-
functioning.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 10.
8.CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-26, "Compression pressure"
.
Is the inspection result normal?
• Fuel should be sprayed evenly for each fuel injector.
• Fuel must not drip from the tip of fuel injector.
PBIA9666J
Spark should be generated.
JMBIA0066GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1421 of 4801

NISSAN TEANA 2014 Service Manual
P117A AIR FUEL RATIOEC-421
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident".
NO >> Check pistons, pisto

Page 1422 of 4801

NISSAN TEANA 2014 Service Manual
EC-422
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1212 TCS COMMUNICATION LINE
P1212 TCS COMMUNI
CATION LINE
DescriptionINFOID:0000000009462349
This CAN communication line is used to control the smooth engin

EC-422
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1212 TCS COMMUNICATION LINE
P1212 TCS COMMUNI
CATION LINE
DescriptionINFOID:0000000009462349
This CAN communication line is used to control the smooth engine operation during the TCS operation. Pulse
signals are exchanged between ECM and “ABS act uator and electric unit (control unit)”.
Be sure to erase the malfunction information such as DTC not only for “ABS actuator and electric unit
(control unit)” but also for ECM after TCS related repair.
DTC LogicINFOID:0000000009462350
DTC DETECTION LOGIC
NOTE:
• If DTC P1212 is displayed with DTC U1001, first pe rform the trouble diagnosis for DTC U1001. Refer
to EC-208, "DTC Logic"
.
• If DTC P1212 is displayed with DTC P0607, first pe rform the trouble diagnosis for DTC P0607. Refer
to EC-404, "DTC Logic"
.
Freeze frame data is not stored in the ECM for this self-diagnosis.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 10 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-422, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462351
Perform the trouble diagnosis for TCS. Refer to BRC-55, "Work Flow".
NOTE:
If DTC P1212 is displayed with DTC UXXXX and/or P0607, perform the following trouble diagnosis.
• Trouble diagnosis for DTC UXXXX Refer to EC-105, "DTC Index"
.
• Trouble diagnosis for DTC P0607 Refer to EC-404, "DTC Logic"
.
DTC No.CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P1212 TCS/CIRC
(TCS/CIRC) ECM can not receive the information
from “ABS actuator and electric unit
(control unit)” continuously. • Harness or connectors
(CAN communication line is open or shorted.)
• ABS actuator and electric unit (control unit)
• Dead (Weak) battery
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1423 of 4801

NISSAN TEANA 2014 Service Manual
P1217 ENGINE OVER TEMPERATUREEC-423
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1217 ENGINE OVER TEMPERATURE
DTC LogicINFOID:0000000009462352
DTC DETECTION LOGIC
NOTE:
• I

P1217 ENGINE OVER TEMPERATUREEC-423
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P1217 ENGINE OVER TEMPERATURE
DTC LogicINFOID:0000000009462352
DTC DETECTION LOGIC
NOTE:
• If DTC P1217 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P1217 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-404, "DTC Logic"
.
If the cooling fan or another component in the cooli ng system malfunctions, engine coolant temperature will
rise.
When the engine coolant temperature reaches an abnorma lly high temperature condition, a malfunction is
indicated.
CAUTION:
When a malfunction is in dicated, be sure to replace the coolant. Refer to CO-12, "Changing Engine
Coolant". Also, replace the engine oil. Refer to LU-10, "Changing Engine Oil".
1. Fill radiator with coolant up to specified level with a filling speed of 2 liters per minute. Be sure to
use coolant with the proper mixture ratio. Refer to MA-12, "FOR USA AND CANADA : Engine Cool-
ant Mixture Ratio".
2. After refilling coolant, run engine to ensure that no water-flow noise is emitted.
DTC CONFIRMATION PROCEDURE
1.PERFORM COMPONENT FUNCTION CHECK
Perform component function check. Refer to EC-423, "Component Function Check"
.
NOTE:
Use component function check to check the overall function of the cooling fan. During this check, a DTC might
not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-424, "Diagnosis Procedure"
.
Component Function CheckINFOID:0000000009462353
1.PERFORM COMPONENT FUNCTION CHECK-1
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pres-
sure fluid escaping from the radiator.
Wrap a thick cloth around cap. Carefully remove the ca p by turning it a quarter turn to allow built-up
pressure to escape. Then turn the cap all the way off.
DTC No.CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P1217 ENG OVER TEMP
(ENG OVER TEMP) • Cooling fan does not operate properly (Over-
heat).
• Cooling fan system does not operate properly
(Overheat).
• Engine coolant was not added to the system using the proper filling method.
• Engine coolant is not within the specified range. • Harness or connectors
(Cooling fan circuit is open or shorted.)
• IPDM E/R
• Cooling fan motor
•Radiator hose
•Radiator
•Radiator cap
• Reservoir tank
• Water pump
• Thermostat
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1424 of 4801

NISSAN TEANA 2014 Service Manual
EC-424
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1217 ENGINE OVER TEMPERATURE
Check the coolant level in the reservoir tank and radiator.
Allow engine to cool befo re checking coolant level.
Is the coolant

EC-424
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1217 ENGINE OVER TEMPERATURE
Check the coolant level in the reservoir tank and radiator.
Allow engine to cool befo re checking coolant level.
Is the coolant level in the reservoir tank and/or radiator below the
proper range?
YES >> Proceed to EC-424, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM COMPONENT FUNCTION CHECK-2
Confirm whether customer filled the coolant or not.
Did customer fill the coolant?
YES >> Proceed to EC-424, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM COMPONENT FUNCTION CHECK-3
With CONSULT
1. Turn ignition switch ON.
2. Perform “FAN DUTY CONTROL” in “ACTIV E TEST” mode of “ENGINE” using CONSULT.
3. Check that cooling fan speed varies according to the percentage.
Without CONSULT
1. Activate IPDM E/R auto active test and check cooling fan motors operation. Refer to PCS-8, "Diagnosis
Description".
2. Check that cooling fan operates.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-424, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009462354
1.CHECK COOLING FAN OPERATION
With CONSULT
1. Turn ignition switch ON.
2. Perform “FAN DUTY CONTROL” in “ACTIV E TEST” mode of “ENGINE” using CONSULT.
3. Check that cooling fan speed varies according to the percentage.
Without CONSULT
1. Activate IPDM E/R auto active test and check cooling fan motors operation. Refer to PCS-8, "Diagnosis
Description".
2. Check that cooling fan operates.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to EC-499, "Diagnosis Procedure"
.
2.CHECK COOLING SYSTEM FOR LEAK-1
Check cooling system for leak. Refer to CO-11, "System Inspection"
.
Is leakage detected?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK COOLING SYSTEM FOR LEAK-2
Check the following for leak.
• Hose (Refer to CO-11, "System Inspection"
.)
• Radiator (Refer to CO-17, "Inspection"
.)
• Water pump (Refer to CO-20, "Removal and Installation"
.)
SEF621W
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Load next 8 pages

Page: < prev 1-10 ... 1385-1392 1393-1400 1401-1408 1409-1416 1417-1424 1425-1432 1433-1440 1441-1448 1449-1456 ... 4808 next >

run flat service battery location child seat octane emergency towing
