• Measure the outer diameter of t
he camshaft journal using suitable
tool (A).
Inner Diameter of Camshaft Bracket
• Tighten the camshaft bracket bolts to the specified torque following
the tightening pattern as shown.
• Using inside micrometer (A), measure inner diameter of camshaft bracket (1).
Calculation of Camshaft Journal Clearance
• (Journal clearance) = (inner diameter of camshaft bracket) – (outer diameter of camshaft journal)
• When out of the specified range above, replace either or both the camshaft and the cylinder head assembly.
NOTE:
Inner diameter of the camshaft bracket is manufac tured together with the cylinder head. If the camshaft
bracket is out of specification, replace the whole cylinder head assembly.
Camshaft End Play
Standard No.1 outer di-
ameter : 27.935 - 27.955 mm
(1.0998 - 1.1006 in)
Standard No.2, 3, 4, 5,
outer diameter : 23.435 - 23.455 mm
(0.9226 - 0.9234 in)
PBIC3179J
Step 1 (bolts 9 - 11) : 1.96 N·m (0.2 kg-m, 17 in-lb)
Step 2 (bolts 1 - 8) : 1.96 N·m (0.2 kg-m, 17 in-lb)
Step 3 (bolts 1 - 11) : 5.88 N·m (0.6 kg-m, 52 in-lb)
Step 4 (bolts 1 - 11) : 10.4 N·m (1.02 kg-m, 92 in-lb)
(A) : Intake side
(B) : Exhaust side
: Engine front
ALBIA0846GB
Standard
No.1 : 28.000 - 28.021 mm (1.1024 - 1.1032 in)
Standard
No.2, 3, 4, 5 : 23.500 - 23.521 mm (0.9252 - 0.9260 in)
ALBIA0903GB
Standard : 0.045 - 0.086 mm (0.0018 - 0.0034 in)
