OPERATION DESCRIPTION
• When the BCM detects that each door request switch (if equipped) is pressed

SYSTEM (INTELLIGENT KEY SYSTEM)DLK-25
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
OPERATION DESCRIPTION
• When the BCM detects that each door request switch (if equipped) is pressed, it activates the outside key
antenna and inside key antenna corresponding to the pres sed door request switch (if equipped) and trans-
mits the request signal to the Intelligent Key. T hen check that the Intelligent Key is near the door.
• If the Intelligent Key is within the outside key ant enna detection area, it receives the request signal and
transmits the key ID signal to the BCM via remote keyless entry receiver.
• BCM receives the key ID signal and compares it with the registered key ID.
• BCM locks/unlocks each door.
• BCM sounds Intelligent Key warning buzzer (lock: 2 ti mes, unlock: 1 time) and blinks hazard warning lamps
(lock: 2 times, unlock: 1 time) at the same time as a reminder.
OPERATION CONDITION
If the following conditions are satisfied, door lock/unl ock operation is performed if the door request switch (if
equipped) is operated.
*: Even with a registered Intelligent Key remaining inside the vehicle, door locks can be locked/unlocked from outside of the v ehicle with
a spare Intelligent Key as long as key IDs are different.
OUTSIDE KEY ANTENNA DETECTION AREA
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in) surrounding the
driver, passenger door handles (1) and rear bumper (2). However,
this operating range depends on the ambient conditions.
SELECTIVE UNLOCK FUNCTION
Lock Operation
When a LOCK signal is sent from door r equest switch (if equipped), all doors are locked.
Unlock Operation
• When an UNLOCK signal from driver side door request swit ch (if equipped) is transmitted, driver side door is
unlocked. When another UNLOCK signal is transmitted within 60 seconds, all other doors are unlocked.
• When an UNLOCK signal from passenger side door reques t switch (if equipped) is transmitted, passenger
side door is unlocked. When another UNLOCK signal is transmitted within 60 seconds, all other doors are
unlocked.
How To Change Selective Unlock Operation Mode
Selective unlock operation mode can be changed using CONSULT.
Refer to BCS-22, "INTELLIGENT KEY : CONSUL T Function (BCM - INTELLIGENT KEY)"
.
HAZARD AND BUZZER REMINDER FUNCTION
During lock or unlock operation by each door request switch (if equipped), the hazard warning lamps and Intel-
ligent Key warning buzzer blinks or honks as a reminder.
Operating Function Of Hazard And buzzer Reminder
Each door request switch (if equipped) opera-
tion Operation condition
Lock • All doors are closed.
• Panic alarm is not activated.
• P (Park) position warning is not activated.
• Intelligent Key is outside the vehicle.
• Intelligent Key is within outside key antenna detection area*.
Unlock • Panic alarm is not activated.
• Intelligent Key is outside the vehicle.
• Intelligent Key is within outside key antenna detection area*.
JMKIA5224ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 794 of 4801

NISSAN TEANA 2014 Service Manual
DLK-26
< SYSTEM DESCRIPTION >
SYSTEM (INTELLIGENT KEY SYSTEM)
Hazard and buzzer reminder does not operate in the following conditions.
• Ignition switch position is ON.
• Door is open (only loc

Page 795 of 4801

NISSAN TEANA 2014 Service Manual
SYSTEM (INTELLIGENT KEY SYSTEM)DLK-27
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY F UNCTION : System DiagramINFOID:0000000009461780
