• If two adjacent cylinders have respectively low compression pressure and their compression remains low
even after the addition of engine oil, the head gasket is leaking. In such a case, replace the cylinder head
gasket.
8. Install spark plug, ignition co il and harness connectors. Refer to EM-16, "Removal and Installation"
.
Revision: November 20132014 Altima NAM
Page 2026 of 4801
EM-28
< REMOVAL AND INSTALLATION >[QR25DE]
ENGINE ROOM COVER
REMOVAL AND INSTALLATION
ENGINE ROOM COVER
Exploded ViewINFOID:0000000009460476
Removal and InstallationINFOID:0000000009460477
CAUTION:
Do not damage or scratch engine room cover.
REMOVAL
1. Remove the engine room cover bolts using power tool.
2. Lift up on engine room cover firmly to dislodge snap fit mounts.
3. Remove engine room cover.
INSTALLATION
Installation is in the reverse order of removal.
1. Engine room cover 2. RH engine mounting bracket 3. Cylinder head
4. Engine room cover bracket 5. Camshaft bracket 6. Engine room cover bracket
7. Bracket stopper A. View A Front
AWBIA1310GB
Revision: November 20132014 Altima NAM
Page 2027 of 4801
![NISSAN TEANA 2014 Service Manual
AIR CLEANER AND AIR DUCTEM-29
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000009460478
Removal and InstallationINFOID:00000 NISSAN TEANA 2014 Service Manual
AIR CLEANER AND AIR DUCTEM-29
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000009460478
Removal and InstallationINFOID:00000](/manual-img/5/57390/w960_57390-2026.png)
AIR CLEANER AND AIR DUCTEM-29
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000009460478
Removal and InstallationINFOID:0000000009460479
REMOVAL
1. Remove the core support cover. Refer to
EXT-17, "Removal and Installation".
2. Remove front air duct.
3. Remove the engine room cover. Refer to EM-28, "Removal and Installation"
.
4. Disconnect the air duct hose clamps at the electric throttle control actuator and the air cleaner case
assembly.
5. Disconnect the blow-by hose.
6. Remove air duct hose and resonator.
7. Disconnect the mass air flow sensor and remove t he harness retainers from the air cleaner case assem-
bly.
8. Disconnect the transaxle breather hose from the air cleaner case assembly.
9. Remove mass air flow sensor from air cleaner case assembly, as necessary. CAUTION:
Handle the mass air flow sensor with care:
• Do not shock it.
• Do not disassemble it.
• Do not touch the internal sensor.
10. Remove the air cleaner case assembly.
INSTALLATION
Installation is in the reverse order of removal.
1. Air duct hose and resonator 2. Front air duct 3. Grommets
4. Air cleaner mounting bracket 5. Air cleaner mounting bracket 6. Air cleaner case assembly
7. Mass air flow sensor
AWBIA1311GB
Revision: November 20132014 Altima NAM
Page 2028 of 4801
![NISSAN TEANA 2014 Service Manual
EM-30
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000009460480
Removal and InstallationINFOID:0000000009460481
REMOVAL
WARNING:
To avoid the danger o NISSAN TEANA 2014 Service Manual
EM-30
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000009460480
Removal and InstallationINFOID:0000000009460481
REMOVAL
WARNING:
To avoid the danger o](/manual-img/5/57390/w960_57390-2027.png)
EM-30
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000009460480
Removal and InstallationINFOID:0000000009460481
REMOVAL
WARNING:
To avoid the danger of being scalded, never drain the coolant when the engine is hot.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
1. Disconnect battery negative terminal. Refer to PG-73, "Removal and Installation (Battery)"
.
2. Release the fuel pressure. Refer to EC-182, "Work Procedure"
.
3. Partially drain engine coolant. Refer to CO-12, "Changing Engine Coolant"
.
4. Remove the air cleaner and air duct. Refer to EM-29, "Removal and Installation"
.
5. Remove cowl top finisher. Refer to EXT-24, "Removal and Installation"
.
6. Remove strut tower bar. Refer to FSU-19, "Exploded View"
.
7. Disconnect the PCV hose from the intake manifold.
8. Disconnect the EVAP hose and EVAP canister purge volume control solenoid.
1. Electric throttle control actuator 2. Map sensor (California only) 3. Map hose (California only)
4. Clamp 5. Cap (except California) 6. Intake manifold gasket
7. Intake manifold 8. Electric throttle control actuator O-ringA. Refer to INSTALLATION
B. Refer to INSTALLATION C. Refer to INSTALLATION
AWBIA1768ZZ
Revision: November 20132014 Altima NAM
Page 2029 of 4801
![NISSAN TEANA 2014 Service Manual
INTAKE MANIFOLDEM-31
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
9. Disconnect the brake booster vacuum
hose from the intake manifold.
10. Disconnect the fuel quick connec NISSAN TEANA 2014 Service Manual
INTAKE MANIFOLDEM-31
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
9. Disconnect the brake booster vacuum
hose from the intake manifold.
10. Disconnect the fuel quick connec](/manual-img/5/57390/w960_57390-2028.png)
INTAKE MANIFOLDEM-31
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
9. Disconnect the brake booster vacuum
hose from the intake manifold.
10. Disconnect the fuel quick connector from the fuel tube assembly. Refer to EM-41, "Removal and Installa-
tion".
11. Disconnect the water hoses from the electric throttle control actuator.
NOTE:
When removing only intake manifold, position electric throttle control actuator aside without disconnecting
the water hose.
12. Loosen bolts in reverse order as shown, then remove electric throttle control actuator and electr ic throttle control actuator O-
ring.
CAUTION:
Handle carefully to avoid any damage.
13. Disconnect the radiator hose (upper) from the water outlet. Refer to CO-16, "Exploded View"
.
14. Disconnect electrical harness connectors from the tumble control valve, tumble control valve position sen-
sor, and power valve motor.
15. Remove the fuel tube assembly. Refer to EM-41, "Removal and Installation"
.
16. Remove the bolts and nuts in the reverse order shown using power tools and remove the intake manifold assembly with gas-
ket.
CAUTION:
Cover engine openings to pr event entry of foreign materi-
als.
NOTE:
Disregard No. 6 when loosening.
INSTALLATION
Installation is in the reverse order of removal. Fo llow the tightening sequences and specifications below and
perform the following:
• Perform the “Throttle Valve Closed Position Learning” when harness connector of electric throttle control
actuator is disconnected. Refer to EC-178, "Work Procedure"
.
• Perform the “Idle Air Volume Learning” and “Throttle Valve Closed Position Learning” when electric throttle
control actuator is replaced. Refer to EC-179, "Work Procedure"
or EC-178, "Work Procedure".
Intake Manifold
1. Securely install gasket to the mounting groove.
CAUTION:
Do not reuse gasket.
AWBIA1359ZZ
ALBIA1159ZZ
Revision: November 20132014 Altima NAM
Page 2030 of 4801
![NISSAN TEANA 2014 Service Manual
EM-32
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
2. If studs were removed, install them and tighten to specification.
3. Tighten in numerical order as shown. CAUTION:
After tightening th NISSAN TEANA 2014 Service Manual
EM-32
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
2. If studs were removed, install them and tighten to specification.
3. Tighten in numerical order as shown. CAUTION:
After tightening th](/manual-img/5/57390/w960_57390-2029.png)
EM-32
< REMOVAL AND INSTALLATION >[QR25DE]
INTAKE MANIFOLD
2. If studs were removed, install them and tighten to specification.
3. Tighten in numerical order as shown. CAUTION:
After tightening the five bolts in the order shown, the 1, 6
position designates that the fi rst bolt tightened is to be
retightened to specification.
Electric Throttle Control Actuator
1. Install a new O-ring on the electric throttle control actuator. CAUTION:
Do not reuse electric throttl e control actuator O-ring.
2. Tighten the bolts of electric th rottle control actuator equally and
diagonally in several steps in numerical order as shown.
INSPECTION AFTER INSTALLATION
Make sure there are no fuel leaks at connections as follows:
1. Apply fuel pressure to fuel lines by turning ignition switch ON (with engine stopped). Then check for fuel leaks at connections.
NOTE:
Use mirrors for checking on connections out of the direct line of sight.
2. Start the engine and rev it up and check for fuel leaks at connections.
WARNING:
Do not touch engine immediately after stopping as engine is extremely hot.
Studs : 9.4 N·m (0.96 kg-m, 83 in-lb)
Bolts 1, 2, 3, 4, 5, 6 : 25.0 N·m (2.6 kg-m, 18 ft-lb)
Nuts 4, 5 : 25.0 N·m (2.6 kg-m, 18 ft-lb)
Bolt 7 : 45.0 N·m (4.6 kg-m, 33 ft-lb)
ALBIA0825GB
AWBIA1359ZZ
Revision: November 20132014 Altima NAM
Page 2031 of 4801
![NISSAN TEANA 2014 Service Manual
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-33
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
EXHAUST MANIFOLD AND THREE WAY CATALYST
Exploded ViewINFOID:0000000009460482
Remov NISSAN TEANA 2014 Service Manual
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-33
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
EXHAUST MANIFOLD AND THREE WAY CATALYST
Exploded ViewINFOID:0000000009460482
Remov](/manual-img/5/57390/w960_57390-2030.png)
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-33
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
EXHAUST MANIFOLD AND THREE WAY CATALYST
Exploded ViewINFOID:0000000009460482
Removal and InstallationINFOID:0000000009460483
REMOVAL
1. Remove the engine under cover. Refer to
EXT-17, "Removal and Installation".
2. Remove the exhaust front tube. Refer to EX-5, "Exploded View"
.
3. Remove the front air duct and air cleaner assembly. Refer to EM-29, "Removal and Installation"
.
4. Disconnect the air fuel ratio (A/F) sensor 1 electrical harness connector.
5. Remove the exhaust manifold cover (upper).
6. Remove the air fuel ratio (A/F) sensor 1 (1) using Tools (A), (if necessary).
CAUTION:
• Be careful not to damage air fuel ratio (A/F) sensor.
• Discard any air fuel ratio (A/F) sensor which has been
dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; replace with a new
one.
7. Remove the oil level gauge and oil level gauge guide. Refer to EM-36, "Exploded View"
.
8. Remove the exhaust manifold cover (lower front).
1. Cylinder head 2. Exhaust manifold gasket 3. Exhaust manifold cover (upper)
4. Exhaust manifold and three way cat- alyst assembly 5. Exhaust manifold cover (lower
front) 6. Exhaust manifold cover (lower rear)
7. Air fuel ratio (A/F) sensor 1
AWBIA1314GB
Tool numbers : KV991J0050 (J-44626) : KV10117100 (J-36471-A)
ALBIA0919GB
Revision: November 20132014 Altima NAM
Page 2032 of 4801
![NISSAN TEANA 2014 Service Manual
EM-34
< REMOVAL AND INSTALLATION >[QR25DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
9. Loosen the exhaust manifold and three way catalyst nuts in the
reverse order as shown.
10. Remove the exhaust man NISSAN TEANA 2014 Service Manual
EM-34
< REMOVAL AND INSTALLATION >[QR25DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
9. Loosen the exhaust manifold and three way catalyst nuts in the
reverse order as shown.
10. Remove the exhaust man](/manual-img/5/57390/w960_57390-2031.png)
EM-34
< REMOVAL AND INSTALLATION >[QR25DE]
EXHAUST MANIFOLD AND THREE WAY CATALYST
9. Loosen the exhaust manifold and three way catalyst nuts in the
reverse order as shown.
10. Remove the exhaust manifold and three way catalyst assembly and gasket. Discard the gasket.
11. Remove the exhaust manifold cover (lower rear).
INSPECTION AFTER REMOVAL
Surface Distortion
• Use a reliable straightedge (A) and feeler gauge (B) to check the flatness of exhaust manifold mating surface.
NOTE:
Place the straightedge (A) diagonally and measure in several loca-
tions.
INSTALLATION
Exhaust Manifold
1. Install studs in cylinder head and exhaust manifold (if removed). Then tighten to specification.
CAUTION:
Do not reuse cylinder head or exhaust manifold studs.
2. Install exhaust manifold cover (lower rear) (if removed) and bolts. Then tighten the bolts to specification in the numerical
order shown.
CAUTION:
Do not reuse bolts.
3. Install the exhaust manifold and gasket. Then tighten the nuts to specification in the numerical order shown.
CAUTION:
Do not reuse gasket. : Engine front
AWBIA0559ZZ
Limit : 0.3 mm (0.012 in)
ALBIA0828GB
ALBIA0887GB
: Engine front
AWBIA0560ZZ
Revision: November 20132014 Altima NAM
