REMOTE KEYLESS ENTRY RECEIVER
REMOVAL AND INSTALLATION
REMOTE KEYLESS ENTRY RECEIVER
Removal and InstallationINFOID:0000000009464521
The Tire Pressure Receiver is a

Page 4730 of 4801

NISSAN TEANA 2014 Service Manual
ROAD WHEEL TIRE ASSEMBLYWT-55
< REMOVAL AND INSTALLATION >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
ROAD WHEEL TIRE ASSEMBLY
AdjustmentINFOID:0000000009464522
BALANCING WHEELS (ADH ESIVE WEIGHT TYPE)
Prepa

ROAD WHEEL TIRE ASSEMBLYWT-55
< REMOVAL AND INSTALLATION >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
ROAD WHEEL TIRE ASSEMBLY
AdjustmentINFOID:0000000009464522
BALANCING WHEELS (ADH ESIVE WEIGHT TYPE)
Preparation Before Adjustment
Remove inner and outer balance weights from the r oad wheel. Using releasing agent, remove double-faced
adhesive tape from the road wheel.
CAUTION:
• Be careful not scratch the road wheel during removal.
• After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road
wheel.
Wheel Balance Adjustment
• If a balancer machine has an adhesive weight mode setting, select the adhesive weight mode setting and skip Step 2. below. If a balancer machine only has the clip-on (rim flange) weight mode setting, follow Step 2.
to calculate the correct size adhesive weight.
1. Set road wheel on balancer machine using the cent er hole as a guide. Start the balancer machine.
2. For balancer machines that only have a clip-on (rim fl ange) weight mode setting, follow this step to calcu-
late the correct size adhesive weight to use. W hen inner and outer imbalance values are shown on the
balancer machine indicator, multiply outer imbalance value by 5/3 (1.67) to determine balance weight that
should be used. Select the outer balance weight with a value closest to the calculated value above and
install in to the designated outer position of, or at the designated angle in relation to the road wheel.
a. Indicated imbalance value × 5/3 (1.67) = balance weight to be
installed
Calculation example:
23 g (0.81 oz) × 5/3 (1.67) = 38.33 g (1.35 oz) ⇒ 40 g (1.41 oz)
balance weight (closer to calculated balance weight value)
NOTE:
Note that balance weight value must be closer to the calculated
balance weight value.
Example:
37.4 ⇒ 35 g (1.23 oz)
37.5 ⇒ 40 g (1.41 oz)
3. Install balance weight in the position shown. CAUTION:
• Do not install the inner bala nce weight before installing
the outer balance weight.
• Before installing the balance weight, be sure to clean the mating surface of the road wheel.
• When installing balance weight (1) to road wheel, set it into the
grooved area (A) on the inner wall of the road wheel as shown
so that the balance weight cent er (B) is aligned with the bal-
ancer machine indication position (angle) (C).
CAUTION:
• Always use Genuine NISSAN adhesive balance weights.
• Balance weights are non-re usable; always replace with
new ones.
• Do not install more than th ree sheets of balance weight.
SMA054D
JPEIC0040ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4731 of 4801

NISSAN TEANA 2014 Service Manual
WT-56
< REMOVAL AND INSTALLATION >
ROAD WHEEL TIRE ASSEMBLY
4. If calculated balance weight value exceeds 50 g (1.76 oz), installtwo balance weight sheets in line with each other as shown.
CAUTION:

Page 4732 of 4801

NISSAN TEANA 2014 Service Manual
TIRE PRESSURE SENSORWT-57
< UNIT REMOVAL AND INSTALLATION >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
UNIT REMOVAL AND INSTALLATION
TIRE PRESSURE SENSOR
Exploded ViewINFOID:0000000009464523
Removal and Inst

Page 4733 of 4801

NISSAN TEANA 2014 Service Manual
WT-58
< UNIT REMOVAL AND INSTALLATION >
TIRE PRESSURE SENSOR
CAUTION:
• Do not use silicone lubricant. Use of silicone lubricant will deteriorate the tire and wheel.
• Be sure not to damage the

Page 4734 of 4801

NISSAN TEANA 2014 Service Manual
TIRE PRESSURE SENSORWT-59
< UNIT REMOVAL AND INSTALLATION >
C
D
F
G H
I
J
K L
M A
B
WT
N
O P
5. Install transmitter (1) to road wheel while pressing at position (A).
CAUTION:
• Check that O-rin

Page 4735 of 4801

NISSAN TEANA 2014 Service Manual
WT-60
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Road WheelINFOID:0000000009464525
Tire

Page 4736 of 4801

NISSAN TEANA 2014 Service Manual
WW-1
DRIVER CONTROLS
C
D E
F
G H
I
J
K
M
SECTION WW
A
B
WW
N
O P
CONTENTS
WIPER & WASHER
PRECAUTION ................ ...............................3
PRECAUTIONS ...................................

WW-1
DRIVER CONTROLS
C
D E
F
G H
I
J
K
M
SECTION WW
A
B
WW
N
O P
CONTENTS
WIPER & WASHER
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution for Procedure without Cowl Top Cover ......3
SYSTEM DESCRIPTION ..............................4
FRONT WIPER AND WASHER SYSTEM ..... .....4
Component Parts Location .................................. ......4
Component Description ............................................5
SYSTEM ..............................................................6
System Diagram .................................................. ......6
System Description ...................................................6
Fail-Safe ....................................................................9
DIAGNOSIS SYSTEM (BCM) ............................10
COMMON ITEM ..................................................... ....10
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) ................................................. ....
10
WIPER ................................................................... ....11
WIPER : CONSULT Function (BCM - WIPER) .......11
DIAGNOSIS SYSTEM (IPDM E/R) .....................12
Diagnosis Description ......................................... ....12
CONSULT Function (IPDM E/R) .............................13
ECU DIAGNOSIS INFORMATION ..............16
BCM, IPDM E/R .............................................. ....16
List of ECU Reference ........................................ ....16
WIRING DIAGRAM ......................................17
FRONT WIPER AND WASHER SYSTEM ..... ....17
Wiring Diagram - Without Rear View Camera
Washer Control System ...................................... ....
17
Wiring Diagram - With Rear View Camera Washer
Control System .................................................... ....
23
BASIC INSPECTION ...................................31
DIAGNOSIS AND REPAIR WORKFLOW ........31
Work Flow ............................................................ ....31
DTC/CIRCUIT DIAGNOSIS .........................33
WIPER AND WASHER FUSE ...........................33
Description ........................................................... ....33
Diagnosis Procedure ...............................................33
FRONT WIPER MOTOR LO CIRCUIT ..............34
Component Function Check ....................................34
Diagnosis Procedure ...............................................34
FRONT WIPER MOTOR HI CIRCUIT ...............36
Component Function Check ....................................36
Diagnosis Procedure ...............................................36
FRONT WIPER AUTO STOP SIGNAL CIR-
CUIT ..................................................................
38
Component Function Check ................................ ....38
Diagnosis Procedure ...............................................38
FRONT WIPER MOTOR GROUND CIRCUIT ...39
Diagnosis Procedure ...............................................39
WASHER MOTOR CIRCUIT .............................40
Diagnosis Procedure ...............................................40
WASHER SWITCH ............................................44
Description ...............................................................44
Component Inspection .............................................44
SYMPTOM DIAGNOSIS ..............................45
WIPER AND WASHER SYSTEM SYMPTOMS
...
45
Symptom Table ................................................... ....45
