DOOR LOCK AND UNLOCK SWITCHDLK-105
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch connector.
3. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3.CHECK POWER WINDOW SWITCH
Check continuity between main power wi ndow and door lock/unlock switch terminals.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation".
4.CHECK POWER WINDOW SWITCH CIRCUITS
1. Disconnect BCM connector.
2. Check continuity between BCM connector and main power window and door lock/unlock switch connec-
tor.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair or replace harness.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000009461834
Transmits door lock/unlock operation to BCM.
Main power window and door lock/unlock switch connector Terminal Continuity
D12 1 Ground Yes
Main power window and door lock/unlock switch state Terminals Continuity Lock 1 - 3 Ye s
Unlock 1 - 15
Neutral/Lock 1 - 15 No
Neutral/Unlock 1 - 3
BCM connector Terminal Main power window and
door lock/unlock switch connector Terminal Continuity
M17 34
D12 15
Ye s
19 3
BCM connector Terminal Continuity
M17 34
Ground No
19
