DAS-192
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464841
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication
line

DAS-192
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009464841
CAN COMMUNICATION
CAN (Controller Area Network) is a serial communication
line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control units , and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H, CAN-L) allowing a hi gh rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads the required data only.
CAN communication signal chart. Refer to LAN-32, "CAN COMMUNICATION SYSTEM : CAN Communica-
tion Signal Chart".
ITS COMMUNICATION
• ITS communication is a multiplex communication system . This enables the system to transmit and receive
large quantities of data at high speed by connecting control units with 2 communication lines.
• ITS communication lines adopt twisted-pair line st yle (two lines twisted) for noise immunity.
DTC LogicINFOID:0000000009464842
DTC DETECTION LOGIC
NOTE:
If “U1000” is detected, first di agnose the CAN communication system.
Diagnosis ProcedureINFOID:0000000009464843
1.PERFORM THE SELF-DIAGNOSIS
1. Turn the ignition switch ON.
2. Turn the MAIN switch of ITS system ON, and then wait for 30 seconds or more.
3. Perform “All DTC Reading” with CONSULT.
4. Check if the “U1000” is detected as the current malfunction in “Self Diagnostic Result” of “AVM”.
Is
“U1000” detected as the current malfunction?
YES >> Refer to DAS-192, "Description".
NO >> Refer to GI-43, "Intermittent Incident"
.
DTC Trouble diagnosis name DTC detecting condition Possible causes
U1000 CAN COMM CIRCUIT If ITS control unit is not transmitting or receiving
CAN communication signal or ITS communica-
tion signal for 2 seconds or more • CAN communication system
• ITS communication system
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 626 of 4801

NISSAN TEANA 2014 Service Manual
DAS
U1010 CONTROL UNIT (CAN)DAS-193
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000009464844
CAN controller controls the communicati

Page 627 of 4801

NISSAN TEANA 2014 Service Manual
DAS-194
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U111A REAR CAMERA IMAGE SIGNAL CIRCUIT
U111A REAR CAMERA IMAGE SIGNAL CIRCUIT
DTC LogicINFOID:0000000009464847
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:000

Page 628 of 4801

NISSAN TEANA 2014 Service Manual
DAS
U111A REAR CAMERA IMAGE SIGNAL CIRCUITDAS-195
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
3.CHECK CONTINUITY REAR CA MERA IMAGE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2.

Page 629 of 4801

NISSAN TEANA 2014 Service Manual
DAS-196
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1232 STEERING ANGLE SENSOR
U1232 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464849
Diagnosis ProcedureINFOID:0000000009464850
1.REGISTER THE NEUTRAL POSIT

Page 630 of 4801

NISSAN TEANA 2014 Service Manual
DAS
U1305 CAMERA IMAGE CALIBDAS-197
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U1305 CAMERA IMAGE CALIB
DTC LogicINFOID:0000000009464851
DTC DETECTION LOGIC
Diagnosis ProcedureIN

Page 631 of 4801

NISSAN TEANA 2014 Service Manual
DAS-198
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U1308 CAMERA CONFIG
U1308 CAMERA CONFIG
DTC LogicINFOID:0000000009464853
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000009464854
1.CHECK SELF-DIAGNOSIS R

Page 632 of 4801

NISSAN TEANA 2014 Service Manual
DAS
U1309 PUMP UNIT CURRENTDAS-199
< DTC/CIRCUIT DIAGNOSIS > [BSW]
C
D E
F
G H
I
J
K L
M B
N P
A
U1309 PUMP UNIT CURRENT
DTC LogicINFOID:0000000009464855
DTC DETECTION LOGIC
DTC CONFIRMATION PROCE
