If the clearance and the surface height are out of specific ation, adjust them according to the adjustment proce-
dures.
Unit: mm (in)
LONGITUDINAL CLEARANCE
Trunk Lid Removed From Hinge
1. Loosen the trunk lid to hinge bolts.
2. Move the trunk lid so that the clearance m easurements are within specifications provided.
3. Tighten the trunk lid to hinge bolts.
Trunk Lid Hinge Removed From Vehicle
1. Remove the rear parcel shelf trim. Refer to INT-26, "Removal and Installation".
2. Loosen the hinge to parcel shelf bolts.
3. Move the trunk lid so that the clearance m easurements are within specifications provided.
4. Tighten the hinge to parcel shelf bolts.
5. Install the rear parcel shelf trim. Refer to INT-26, "Removal and Installation"
.
SURFACE HEIGHT ADJUSTMENT
1. Loosen the bumper rubber.
2. Loosen the striker bolts.
3. Lift up the trunk lid approx. 100 - 150 mm (3.94 - 5.91 in) height then close it lightly. Make sure it engages
firmly with the trunk lid closed.
4. Tighten the trunk lid striker.
TRUNK LID HINGE
TRUNK LID HINGE : Remo val and InstallationINFOID:0000000009461956
REMOVAL
1. Remove trunk lid assembly. Refer to DLK-206, "TRUNK LID ASSEMBLY : Removal and Installation".
2. Remove torsion bar. Refer to DLK-210, "TORSION BAR : Removal and Installation"
.
3. Remove rear parcel shelf finisher. Refer to INT-26, "Removal and Installation"
.
4. Release rear washer tube clips (RH only) (if equipped).
5. Remove trunk lid hinge bolts (body side) and then trunk lid hinge.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Check trunk lid open/close, lock/un lock operation after installation.
• After installation, perform the trunk li d assembly adjustment procedure. Refer to DLK-208, "TRUNK
LID ASSEMBLY : Adjustment".
Section Item Measurement Standard Parallelism (MAX) Right/Left
Difference (MAX)
A – A E Clearance 3.5
± 1.0 (0.14 ± 0.04) 1.4 (0.06) 1.4 (0.06)
F Surface height 0.0 ± 1.0 (0.00 ± 0.04) 1.4 (0.06) 1.4 (0.06)
B – B G Clearance 3.5
± 1.0 (0.14 ± 0.04) 1.4 (0.06) 1.4 (0.06)
H Surface height 0.0 ± 1.0 (0.00 ± 0.04) 1.4 (0.06) 1.4 (0.06)
C – C J Clearance 4.0 ± 1.5 (0.16 ± 0.06) — 2.0 (0.08)
D – D K Clearance 6.0 ± 2.0 (0.24 ± 0.08) 2.0 (0.08) —
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 978 of 4801
DLK-210
< REMOVAL AND INSTALLATION >
TRUNK LID
• Check trunk lid hinge rotating point for poor lubrication. If
necessary, apply a suitable multi-purpose grease.
: Grease
TORSION BAR
TORSION BAR : Remova l and InstallationINFOID:0000000009461957
REMOVAL
1. Remove torsion bar clips.
2. Support the trunk lid assembly using a suitable tool. WARNING:
Bodily injury may occur if hood assembly is not supported properly when removing hood assem-
bly.
3. Lift torsion bar (1) using a suitable tool (A) as shown to remove.
NOTE:
The suitable tool specifications are as shown.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation check the trunk li d open/close, lock/unlock operation.
TRUNK LAMP SWITCH AND TRUNK RELEASE SOLENOID
TRUNK LAMP SWITCH AND TRUNK RELEASE SOLENOID : Removal and Installa-
tion
INFOID:0000000009461958
REMOVAL
JMKIA8127ZZ
JMKIA8128ZZ
PIIB3774J
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 979 of 4801

TRUNK LIDDLK-211
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Remove the trunk lid finisher (if equipped). Refer to INT-33, "TRUNK LID FINISHER : Removal and Instal-
lation".
2. Remove the trunk lamp switch and trunk release solenoid bolts (A).
3. Disconnect the harness connector (B) and emergency release handle (2) from the trunk lamp switch and trunk release solenoid
(1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, perform the trunk lid assembly adjustment procedure. Refer to DLK-208, "TRUNK
LID ASSEMBLY : Adjustment".
EMERGENCY LEVER
EMERGENCY LEVER : Removal and InstallationINFOID:0000000009461959
Removal
1. Remove the trunk lid finisher. Refer to INT-33, "TRUNK LID FINISHER : Removal and Installation".
2. Using a suitable tool release the pawls and remove emergency release handle (1) from trunk lid assembly.
: Pawl
3. Disconnect emergency release handle cable (2) from trunk lamp switch and trunk release solenoid (3).
TRUNK LID STRIKER
TRUNK LID STRIKER : Re moval and InstallationINFOID:0000000009461960
REMOVAL
1. Remove the trunk kicking plate. Refer to INT-35, "TRUNK REAR FINISHER : Removal and Installation".
2. Remove bolts (A), and striker (1).
ALKIA2736ZZ
ALKIA2310ZZ
ALKIA2737ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 980 of 4801
DLK-212
< REMOVAL AND INSTALLATION >
TRUNK LID
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, perform the trunk lid assembly adjustment procedure. Refer to DLK-208, "TRUNK
LID ASSEMBLY : Adjustment".
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 981 of 4801
FUEL FILLER LID OPENERDLK-213
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
FUEL FILLER LID OPENER
Exploded ViewINFOID:0000000009461961
FUEL FILLER LID
FUEL FILLER LID : Re moval and InstallationINFOID:0000000009461962
REMOVAL
1. Fully open fuel filler lid.
2. Remove fuel cap pin (1).
1. Fuel filler lid opener cable 2. Spring 3. Fuel filler lid
4. Bumper rubber 5. Fuel filler lid lock A. Clip
B. Cable protector
ALKIA2730ZZ
JMKIA8137ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 982 of 4801

DLK-214
< REMOVAL AND INSTALLATION >
FUEL FILLER LID OPENER
3. Remove fuel filler lid screws (A) and fuel filler lid (1).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, check fuel filler li d assembly open/close, lock/unlock operation.
NOTE:
• The following table shows the specifications for a correctly installed fuel filler lid.
• Fitting adjustment cannot be performed.
Unit: mm (in)
FUEL FILLER OP ENER CABLE
FUEL FILLER OPENER CABLE : Removal and InstallationINFOID:0000000009461963
REMOVAL
1. Remove hood and fuel filler handle assembly bolts (A).
2. Disengage fuel filler lid opener cable (2) by pulling downward and then sliding cable end to the side to remove from hood and
fuel filler handle assembly (1).
3. Remove dash side finisher (LH). Refer to INT-20, "DASH SIDE FINISHER : Removal and Installation"
.
4. Remove center pillar lower finisher (LH). Refer to INT-23, "CENTER PILLAR LOWER FINISHER :
Removal and Installation".
5. Remove rear seat bolster (LH). Refer to SE-38, "Removal and Installation - Rear Seat Bolster"
.
ALKIA2732ZZ
Portion Measurement Standard
Fuel filler lid – Body side outer Clearance 3.5 ± 1.0 (0.14 ± 0.04)
Fuel filler lid – Body side outer Surface height 0.0 ± 1.0 (0.0 ± 0.04)
JMKIA7998ZZ
JMKIA7999ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 983 of 4801

FUEL FILLER LID OPENERDLK-215
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
6. Remove trunk side finisher (LH). Refer to INT-34, "TRUNK SIDE FINISHER : Removal and Installation".
7. Remove fuel filler lid opener cable from fuel filler lid lock assembly. Refer to DLK-215, "FUEL FILLER LID
LOCK : Removal and Installation".
8. Disengage each harness protector (1), and then remove fuel filler lid opener cable (2).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, check fuel filler li d assembly open/close, lock/unlock operation.
FUEL FILLER LID LOCK
FUEL FILLER LID LOCK : Removal and InstallationINFOID:0000000009461964
REMOVAL
1. Fully open fuel filler lid.
2. Insert a suitable tool (A) as shown into bottom of fuel filler lock assembly(1).
3. Release lower pawls (A) using a suitable tool and remove fuel filler lid lock assembly (1) from opening.
CAUTION:
Be careful not to damage gasket (2) when removing.
JMKIA5720ZZ
ALKIA2731ZZ
JMKIA8138ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 984 of 4801
DLK-216
< REMOVAL AND INSTALLATION >
FUEL FILLER LID OPENER
4. Disconnect fuel filler lid opener cable (1) by pulling downwardand then sliding cable end to the side to remove from fuel filler
lid lock assembly (2).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, check fuel filler li d assembly open/close, lock/unlock operation.
JMKIA8139ZZ
