2014 NISSAN TEANA Service Manual

brake sensor deactivate passenger airbag maintenance climate settings tire pressure wiring diagram

Page 4337 of 4801

NISSAN TEANA 2014 Service Manual
TM-122
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0743 TORQUE CONVERTER
P0743 TORQUE CONVERTER
DTC LogicINFOID:0000000009464061
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of t

Page 4338 of 4801

NISSAN TEANA 2014 Service Manual
P0743 TORQUE CONVERTERTM-123
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Diagnosis ProcedureINFOID:0000000009464062
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ign

P0743 TORQUE CONVERTERTM-123
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Diagnosis ProcedureINFOID:0000000009464062
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 3.
3.CHECK CIRCUIT BETW EEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-186, "Exploded View"
.
2. Check continuity between CVT unit harness connecto r terminal and control valve harness connector ter-
minal.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace terminal code assembly. Refer to TM-186, "Exploded View"
.
4.CHECK CIRCUIT BETWEEN CONTROL VALVE AND GROUND
Check resistance between control valve harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> There is malfunction of torque converter clutch solenoid valve. Replace transaxle assembly. Refer
to TM-206, "Removal and Installation"
.
TCM
—Continuity
Connector Terminal
F16 38 Ground Not existed
CVT unit — Condition Resistance
Connector Terminal
F209 2 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
CVT unit Control valve
Continuity
Connector Terminal Connector Terminal
F2092F2073Existed
Control valve — Condition Resistance
Te r m i n a l
3Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4339 of 4801

NISSAN TEANA 2014 Service Manual
TM-124
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0744 TORQUE CONVERTER
P0744 TORQUE CONVERTER
DTC LogicINFOID:0000000009464063
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of t

TM-124
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0744 TORQUE CONVERTER
P0744 TORQUE CONVERTER
DTC LogicINFOID:0000000009464063
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PREPARATION BEFORE OPERATION
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Confirm that the CVT fluid temper ature is in the following range.
With GST
1. Start the engine.
2. Set the CVT fluid to 20 °C (68 °F) or more.
NOTE:
When the ambient temperature is 20 °C (68 °F), the CVT fluid usually increases to 50 to 80 °C (122 to
176 °F) with driving in an urban area for approximately 10 minutes.
Is the CVT fluid 20
°C (68°F) or more?
YES >> GO TO 3.
NO >> 1. Warm the transaxle. 2. GO TO 3.
3.CHECK DTC DETECTION
1. Drive the vehicle.
2. Maintain the following conditions for 10 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0744” detected?
YES >> Go to TM-125, "Diagnosis Procedure".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0744 TORQUE CONVERTER
(Torque converter clutch cir-
cuit intermittent) When all of the following conditions are satis-
fied and this state is maintained for 30 sec-
onds:
• TCM power supply voltage: More than 11 V
• P0717 is not detected.
• CAN communication is normal
• Torque converter slip speed: (40+vihicle
speed/2) rpm
• LU pressure: More than 0.2 MPa • Torque converter clutch solenoid valve
• Control valve assembly
• Torque converter
FLUID TEMP : 20 °C (68 °F) or more
Selector lever : “D” position
Accelerator pedal position : 0.5/8 or more
Vehicle speed : 40 km/h (25 MPH) or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4340 of 4801

NISSAN TEANA 2014 Service Manual
P0744 TORQUE CONVERTERTM-125
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464064
1.CHECK INTERMITTENT INCIDNT
Ref

Page 4341 of 4801

NISSAN TEANA 2014 Service Manual
TM-126
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0746 PRESSURE CONTROL SOLENOID A
P0746 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000009464065
DTC DETECTION LOGIC
NOTE:
DC stands for "DRIVING C

TM-126
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0746 PRESSURE CONTROL SOLENOID A
P0746 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000009464065
DTC DETECTION LOGIC
NOTE:
DC stands for "DRIVING CYCLE" and indicates a seri es of driving cycle of "Ignition switch OFF → ON → driv-
ing → OFF".
DTC CONFIRMATION PROCEDURE
CAUTION:
Be careful of the driving speed.
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following conditions for 10 seconds or more.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0746”detected?
YES >> Go to TM-127, "Diagnosis Procedure".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0746 PC SOLENOID A
(Pressure Contro l Solenoid A
Performance/Stuck Off) The detecting condition A or detection condi-
tion B is detected twice or more (1 second or
more later after detection of the first) in the
same DC under the following diagnosis condi-
tions:
• Diagnosis conditions
- Engine speed: More than 600 rpm
- Primary pulley speed: More than 450 rpm
- Idle is not being detected.
- Acceleration/deceleration speed: −0.49 m/
s
2 ( −0.05 G) or more
- The primary pulley speed experienced 300
rpm or more and the secondary pulley
speed experienced 250 rpm or more at least
once.
- Secondary pulley speed: More than 150
rpm
- TCM power supply voltage: More than 11 V
• Detection condition A
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio exceed-
ing 2.981 is 0.2 sec or more continuously.
• Detection condition B
- Status with the shifting ratio of the primary pulley speed/secondary pulley ratio exceed-
ing 3.781 is 0.1 sec or more continuously. • Line pressure solenoid valve
• Control valve assembly
Selector lever : “D” position
Accelerator pedal position : 0.5/8 or more
Vehicle speed : 40 km/h (25 MPH) or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4342 of 4801

NISSAN TEANA 2014 Service Manual
P0746 PRESSURE CONTROL SOLENOID ATM-127
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464066
1.CHECK INTERMITTENT

Page 4343 of 4801

NISSAN TEANA 2014 Service Manual
TM-128
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0776 PRESSURE CONTROL SOLENOID B
P0776 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464067
DTC DETECTION LOGIC
DTCCONSULT screen terms
(Troubl

TM-128
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0776 PRESSURE CONTROL SOLENOID B
P0776 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464067
DTC DETECTION LOGIC
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible cause
P0776 PC SOLENOID B
(Pressure Control Solenoid
“B” Performance/Stuck Off) When any of 1 or 2 is satisfied and this state
is maintained for 10 seconds:
1. When all of the following conditions are satisfied:
- DTC other than the applicable DTC is not detected.
- Engine speed: More than 625 rpm
- Selector lever: Other than P/N position
- CVT fluid temperature: More than - 20°C (-4 °F)
- TCM power supply: More than 11 V
- The difference between instruction pressure of secondary pressure and
10-msec-ago instruction secondary
pressure is 0 MPa or more
- Instruction pressure of secondary
pressure: 0 MPa or more
- Instruction pressure of secondary pressure - secondary pressure: More
than 1.2 MPa
- When all of the following conditions are satisfied and this state is maintained
for 5.5 seconds:
• DTC other than the applicable DTC is not detected.
• CVT fluid temperature: More than -
20°C (-4 °F)
• Selector lever: Other than P/N position
• Secondary pressure - instruction pres-
sure of secondary pressure: 1.2 MPa
or more
2. When all of the following conditions are
satisfied:
- DTC other than the applicable DTC is not detected.
- CVT fluid temperature: More than - 20°C (-4 °F)
- Selector lever: Other than P/N position
- TCM power supply: More than 11 V
- When all of the following conditions are satisfied and this state is maintained
for 5.5 seconds:
• DTC other than the applicable DTC is not detected.
• CVT fluid temperature: More than - 20°C (-4 °F)
• Selector lever: Other than P/N position
• Secondary pressure - instruction pres- sure of secondary pressure: 1.2 MPa
or more
- The difference between instruction pressure of secondary pressure and
10-msec-ago instruction secondary
pressure is 0 MPa or more
- Secondary pressure - instruction pres- sure of secondary pressure: More than
1.2 MPa Secondary pressure solenoid valve
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4344 of 4801

NISSAN TEANA 2014 Service Manual
P0776 PRESSURE CONTROL SOLENOID BTM-129
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PREPARAT
