NISSAN TEANA 2014 Service Manual TIMING CHAINEM-187 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O 4. After confirming the mating marks are aligned, tighten the cam- shaft sprocket bolts. • Secure the cams

Page 2186 of 4801

NISSAN TEANA 2014 Service Manual EM-188 < REMOVAL AND INSTALLATION >[VQ35DE] TIMING CHAIN 8. Install the internal chain guide and slack guide. CAUTION: • Do not overtighten the slack guid e bolts. It is normal for a gap to exist

Page 2187 of 4801

NISSAN TEANA 2014 Service Manual REAR TIMING CHAIN CASEEM-189 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O REAR TIMING CHAIN CASE Exploded ViewINFOID:0000000009460566 Removal and InstallationINFOID:00000000

Page 2188 of 4801

NISSAN TEANA 2014 Service Manual EM-190 < REMOVAL AND INSTALLATION >[VQ35DE] REAR TIMING CHAIN CASE • Before removing the upper oil pan, re move the crankshaft position sensor (POS). • Be careful not to damage sensor edges. •

Page 2189 of 4801

NISSAN TEANA 2014 Service Manual REAR TIMING CHAIN CASEEM-191 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O 6. Remove O-rings (1) to timing chain case and cylinder block. CAUTION: Do not reuse O-rings. 7. U

Page 2190 of 4801

NISSAN TEANA 2014 Service Manual EM-192 < REMOVAL AND INSTALLATION >[VQ35DE] REAR TIMING CHAIN CASE 3. Align the rear timing chain case and water pump as sembly with the dowel pins (RH and LH) on the cylin- der block and install the

Page 2191 of 4801

NISSAN TEANA 2014 Service Manual REAR TIMING CHAIN CASEEM-193 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O a. Tighten the bolts in the numerical order as shown. There are two bolt lengths used. Follow the

Page 2192 of 4801

NISSAN TEANA 2014 Service Manual EM-194 < REMOVAL AND INSTALLATION >[VQ35DE] CAMSHAFT CAMSHAFT Exploded ViewINFOID:0000000009460568 Removal and InstallationINFOID:0000000009460569 CAUTION: Apply new engine oil to parts marked in i
