EVAP LEAK CHECKEC-537
< PERIODIC MAINTENANCE > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
EVAP LEAK CHECK
InspectionINFOID:0000000009462466
CAUTION:
• Do not use compressed air or a high pressure p

Page 1538 of 4801

NISSAN TEANA 2014 Service Manual
EC-538
< PERIODIC MAINTENANCE >[QR25DE]
EVAP LEAK CHECK
2. Apply battery voltage between the terminals of EVAP
canister vent control valve to make a closed EVAP
system.
3. To locate the leak, delive

Page 1539 of 4801

NISSAN TEANA 2014 Service Manual
POSITIVE CRANKCASE VENTILATIONEC-539
< PERIODIC MAINTENANCE > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
POSITIVE CRANKCASE VENTILATION
InspectionINFOID:0000000009462467
1.CHECK PCV VALVE
With engine

Page 1540 of 4801

NISSAN TEANA 2014 Service Manual
EC-540
< REMOVAL AND INSTALLATION >[QR25DE]
ECM
REMOVAL AND INSTALLATION
ECM
Removal and InstallationINFOID:0000000009462468
EXPLODED VIEW
REMOVAL
CAUTION:
Perform ADDITIONAL SERVICE WHEN REPLACIN

Page 1541 of 4801

NISSAN TEANA 2014 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)EC-541
< SERVICE DATA AND SPECIFICATIONS (SDS) [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (S

Page 1542 of 4801

NISSAN TEANA 2014 Service Manual
EC-542
< PRECAUTION >[VQ35DE]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009976114
The Supplemental

EC-542
< PRECAUTION >[VQ35DE]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009976114
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
On Board Diagnosti c (OBD) System of Engine and CVTINFOID:0000000009462476
The ECM has an on board diagnostic system. It will illuminate the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
• Always to turn the ignition swit ch OFF and disconnect the negative battery cable before any repair
or inspection work. The open/short circuit of re lated switches, sensors, solenoid valves, etc. will
cause the MIL to illuminate.
• Always to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to illuminate due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
• Certain systems and components, especially those related to OBD, may use a new style slide-lock-
ing type harness connector. For descrip tion and how to disconnect, refer to PG-65, "Description"
.
• Always route and secure the harnesses properly afte r work. The interference of the harness with a
bracket, etc. may cause the MIL to illu minate due to the short circuit.
• Always to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to illuminate due to the malfuncti on of the EVAP system or fuel injection system,
etc.
• Always to erase the unnecessary malfunction informati on (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1543 of 4801

NISSAN TEANA 2014 Service Manual
PRECAUTIONSEC-543
< PRECAUTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
General PrecautionsINFOID:0000000009462477
•
Always use a 12 volt battery as power source.
• Never attempt to disconnect

PRECAUTIONSEC-543
< PRECAUTION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
General PrecautionsINFOID:0000000009462477
•
Always use a 12 volt battery as power source.
• Never attempt to disconnect ba ttery cables while engine is
running.
• Before connecting or disc onnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect negative bat-
tery cable. Failure to do so may damage the ECM because
battery voltage is applied to ECM even if ignition switch is
turned OFF.
• Before removing parts, turn ig nition switch OFF and then dis-
connect battery ground cable.
• Never disassemble ECM.
• If a battery cable is disconnected, the memory will return to the ECM value.
The ECM will now start to self-control at its initia l value. Thus, engine operation can vary slightly in
this case. However, this is not an indication of a malfunction. Never replace parts because of a slight
variation.
• If the battery is disconnected, the following emi ssion-related diagnostic information will be lost
within 24 hours.
- Diagnostic trouble codes
- 1st trip diagnostic trouble codes
- Freeze frame data
- 1st trip freeze frame data
- System readiness test (SRT) codes
- Test values
• When connecting ECM harness connector, fasten (B) it
securely with a lever (1) as far as it will go as shown in the fig-
ure.
- ECM (2)
- Loosen (A)
• When connecting or disconnect ing pin connectors into or
from ECM, never damage pin terminals (bends or break).
Check that there are not any bends or breaks on ECM pin ter-
minal, when connect ing pin connectors.
• Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge) volt-
age to develop in coil and cond enser, thus resulting in dam-
age to ICs.
• Keep engine control system harness at least 10 cm (4 in) away
from adjacent harness, to prevent engine control system mal-
functions due to receiving externa l noise, degraded operation
of ICs, etc.
• Keep engine control system parts and harness dry.
SEF289H
PBIB2947E
PBIB0090E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1544 of 4801

NISSAN TEANA 2014 Service Manual
EC-544
< PRECAUTION >[VQ35DE]
PRECAUTIONS
•
Before replacing ECM, perform ECM Terminals and Reference
Value inspection and check ECM functions properly. Refer to
EC-613, "Reference Value"
.
• H
