Page 3601 of 4801

NISSAN TEANA 2014 Service Manual
PWC-94
< BASIC INSPECTION >[LH & RH FRONT ANTI-PINCH]
INSPECTION AND ADJUSTMENT
1. Disconnect battery minus terminal or power window ma
in switch connector. Reconnect it after a minute or
more.
2. T

Page 3602 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-95
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
DTC/CIRCUIT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosi

Page 3603 of 4801

NISSAN TEANA 2014 Service Manual
PWC-96
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
POWER WINDOW MAIN SWITCH : Component Function Check
INFOID:0000000009460914
Main Power Window And Door Lock/

Page 3604 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-97
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
1. Turn ignition switch OFF.
2. Disconnect main power window and door l

POWER SUPPLY AND GROUND CIRCUITPWC-97
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unlock switch.
3. Check continuity between main power window and door lock/unlock switch connector D7 and ground.
Is the inspection result normal?
YES >> Check main power window and door lock/unlock switch output signal (rear power window switch
LH) GO TO 5.
YES >> Check main power window and door lock/unlock switch output signal (rear power window switch
RH) GO TO 6.
YES >> Check main power window and door lock/unlock s witch output signal (front power window switch
LH) GO TO 7.
NO >> Repair or replace the harness and connectors.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M21 and ground.
Is the measurement value within the specification?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
5. CHECK MAIN POWER WINDOW AND DOOR LOCK /UNLOCK SWITCH OUTPUT SIGNAL (REAR POW-
ER WINDOW SWITCH LH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch connector D7 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace main power window and door lock/unlock switch. Refer to PWC-142, "Removal and
Installation". After that, refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACING CON-
TROL UNIT : Special Repair Requirement".
6. CHECK MAIN POWER WINDOW AND DOOR LOCK /UNLOCK SWITCH OUTPUT SIGNAL (REAR POW-
ER WINDOW SWITCH RH)
1. Connect main power window and door lock/unlock switch.
2. Turn ignition switch ON.
3. Check voltage between main power window and door lock/unlock switch connector D7 and ground.
Main power window and door lock/unlock switch connec-
tor Te r m i n a l
GroundContinuity
D7 1 Yes
Te r m i n a l s Vo l ta g e
(Approx.)
(+)
(–)
BCM connector Terminal
M21 140
Ground Battery voltage
141
Te r m i n a l
Window switch
position (rear LH) Vo l ta g e
(Approx.)
(+)
(–)
Main power window and door
lock/unlock switch connector Te r m i n a l
D7 8
Ground UP Battery voltage
DOWN 0
9 UP 0
DOWN Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3605 of 4801

NISSAN TEANA 2014 Service Manual
PWC-98
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident

Page 3606 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-99
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
3. Check continuity between main power window and door lock/unlock swit

Page 3607 of 4801

NISSAN TEANA 2014 Service Manual
PWC-100
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
FRONT POWER WINDOW SWITCH : Component Function Check
INFOID:0000000009460919
Power Window And Door Lock/un

PWC-100
< DTC/CIRCUIT DIAGNOSIS >[LH & RH FRONT ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
FRONT POWER WINDOW SWITCH : Component Function Check
INFOID:0000000009460919
Power Window And Door Lock/unlock Switch RH
1. CHECK FRONT POWER WINDOW MOTOR RH FUNCTION
Check front power window motor RH operation wit h power window and door lock/unlock switch RH.
Is the inspection result normal?
YES >> Power window and door lock/unlock switch RH power supply and ground circuit are OK.
NO >> Refer to PWC-100, "FRONT POWER WINDOW SWITCH : Diagnosis Procedure"
.
FRONT POWER WINDOW SWITCH : Diagnosis ProcedureINFOID:0000000009460920
Regarding Wiring Diagram information, refer to PWC-83, "Wiring Diagram - With Left And Right Front Power
Window Anti-Pinch".
Power Window And Door Lock/unlock Switch RH Power Supply Circuit Check
1. CHECK POWER SUPPLY CIRCUIT
Check voltage between power window and door lock/unlock switch RH connector D105 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and power window and door lock/unlock switch RH.
3. Check continuity between BCM connector M21 and power window and door lock/unlock switch RH con-
nector D105.
4. Check continuity between BCM connector M21 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between power window and door lock/unlock switch RH connector D105 and ground.
Is the inspection result normal?
Te r m i n a l Voltag e
(Approx.)
(+)
(–)
Power window and door lock/unlock
switch RH connector Te r m i n a l
D105 8 Ground Battery voltage
BCM connector Terminal Power window and door lock/un-
lock switch RH connector Terminal Continuity
M21 141 D105 8 Yes
BCM connector Terminal GroundContinuity
M21 141 No
Power window and door lock/unlock switch RH Terminal GroundContinuity
D105 7 Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3608 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-101
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Inci

POWER SUPPLY AND GROUND CIRCUITPWC-101
< DTC/CIRCUIT DIAGNOSIS > [LH & RH FRONT ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace the harness or connectors.
4. CHECK BCM OUTPUT SIGNAL
1. Connect BCM.
2. Turn ignition switch ON.
3. Check voltage between BCM connector M21 and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
FRONT POWER WINDOW SWITCH : Special Repair RequirementINFOID:0000000009460921
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-93, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection end.
NO >> Refer to PWC-100, "FRONT POWER WINDOW SW ITCH : Component Function Check"
.
REAR POWER WINDOW SWITCH
REAR POWER WINDOW SWITCH : DescriptionINFOID:0000000009460922
• BCM supplies power.
• Rear power window motor will be operated if rear power window switch is operated. Rear power window
switch.
REAR POWER WINDOW SWITCH : Component Function CheckINFOID:0000000009460923
Rear Power Window Switch
1. CHECK REAR POWER WINDOW MOTOR FUNCTION
Check rear power window motor operation with rear power window switch.
Is the inspection result normal?
YES >> Rear power window switch power supply and ground circuit are OK.
NO >> Refer to PWC-101, "REAR POWER WINDOW SWITCH : Diagnosis Procedure"
.
REAR POWER WINDOW SWITCH : Diagnosis ProcedureINFOID:0000000009460924
Regarding Wiring Diagram information, refer to PWC-83, "Wiring Diagram - With Left And Right Front Power
Window Anti-Pinch".
Te r m i n a l s
Vol tag e
(Approx.)
(+)
(-)
BCM connector Terminal
M21 141 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
