2014 NISSAN TEANA Service Manual

turn signal bulb clock ESP climate control brake set clock

Page 4585 of 4801

NISSAN TEANA 2014 Service Manual
TM-370
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
SHIFT LOCK SYSTEM
4.CHECK GROUND CIRCUIT
(STOP LAMP RELAY)
1. Remove the stop lamp relay.
2. Check continuity between stop lamp relay connector E57 te

Page 4586 of 4801

NISSAN TEANA 2014 Service Manual
SHIFT LOCK SYSTEMTM-371
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NO >> Repair or replace damaged parts.
9.CHECK GROUND CIRCUIT (CVT SHIFT SELECTOR)
Check continuity b

SHIFT LOCK SYSTEMTM-371
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NO >> Repair or replace damaged parts.
9.CHECK GROUND CIRCUIT (CVT SHIFT SELECTOR)
Check continuity between CVT shift selector connector M23 terminal 4 and ground.
Is the inspection result normal?
YES >> Replace CVT shift selector. Refer to TM-378, "Removal and Installation".
NO >> Repair or replace damaged parts.
Component Inspection (Shift Lock Solenoid)INFOID:0000000009464327
1.CHECK SHIFT LOCK SOLENOID
Apply voltage to terminals of shift lock solenoid and park position switch (shift selector) connector and check
that shift lock solenoid is activated.
CAUTION:
• Connect the fuse between the termi nals when applying the voltage.
• Never cause shorting between terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace CVT shift selector. Refer to TM-378, "Removal and Installation"
.
Component Inspection (Park Position Switch)INFOID:0000000009464328
1.CHECK PARK POSITION SWITCH (SHIFT SELECTOR)
Apply voltage to terminals of shift lock solenoid and park position switch (shift selector) connector and check
that shift lock solenoid is activated.
CAUTION:
• Connect the fuse between the termi nals when applying the voltage.
• Never cause shorting between terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace CVT shift selector. Refer to TM-378, "Removal and Installation"
.
CVT shift selector
GroundContinuity
Connector Terminal
M23 4 Yes
+ (fuse) - Condition Status
Shift lock solenoid
Te r m i n a l
34 Apply 12 V between termi-
nals 3 and 4 with the park
position switch (shift selec-
tor) in the "P" (park) posi-
tion. Shift lock solenoid operates
+ (fuse) -
Condition Status
Shift lock solenoid
Te r m i n a l
34 Apply 12 V between termi-
nals 3 and 4 with the park
position switch (shift selec-
tor) in the "P" (park) posi-
tion. Shift lock solenoid operates
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4587 of 4801

NISSAN TEANA 2014 Service Manual
TM-372
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
SHIFT LOCK SYSTEM
Component Inspection (Stop Lamp Switch)
INFOID:0000000009464329
1.CHECK STOP LAMP SWITCH
Check the continuity between the stop lamp s

Page 4588 of 4801

NISSAN TEANA 2014 Service Manual
CVT CONTROL SYSTEMTM-373
< SYMPTOM DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SYMPTOM DIAGNOSIS
CVT CONTROL SYSTEM
Symptom TableINFOID:0000000009464330
• The diagnosis item number

Page 4589 of 4801

NISSAN TEANA 2014 Service Manual
TM-374
< SYMPTOM DIAGNOSIS >[CVT: RE0F10E]
CVT CONTROL SYSTEM
OtherNo creep at all. 243789101112 5613141
Vehicle cannot run in any position. 8 256791011 3412131
With selector lever in D position,

Page 4590 of 4801

NISSAN TEANA 2014 Service Manual
CVT CONTROL SYSTEMTM-375
< SYMPTOM DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Symptom Table 2
Symptom
Torque converter
Transmission range switch
Oil pump
Forward clutch
Reverse br

Page 4591 of 4801

NISSAN TEANA 2014 Service Manual
TM-376
< SYMPTOM DIAGNOSIS >[CVT: RE0F10E]
CVT CONTROL SYSTEM
OtherNo creep at all. 1 6 2 4 5 3
Vehicle cannot run in all posi-
tions. 1 2453 6
With selector lever in D position,
driving is not p

Page 4592 of 4801

NISSAN TEANA 2014 Service Manual
CVT FLUIDTM-377
< PERIODIC MAINTENANCE > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PERIODIC MAINTENANCE
CVT FLUID
InspectionINFOID:0000000009464331
FLUID LEAKAGE
• Check transaxle surrounding
