NISSAN TEANA 2014 Service Manual REPLACEMENT OPERATIONSBRM-51 < REMOVAL AND INSTALLATION > C D E F G H I J L M A B BRM N O P Rear Floor RearINFOID:0000000009464983 • Work after rear panel assembly has been removed. Change parts

Page 330 of 4801

NISSAN TEANA 2014 Service Manual BRM-52 < REMOVAL AND INSTALLATION > REPLACEMENT OPERATIONS Rear Side Member Extension INFOID:0000000009464984 • Work after rear panel assembly and rear floor rear have been removed. Change parts �z

Page 331 of 4801

NISSAN TEANA 2014 Service Manual BODY ALIGNMENTBRM-53 < SERVICE DATA AND SPECIFICATIONS (SDS) C D E F G H I J L M A B BRM N O P SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Body Center MarksINFOID:0000000009464985 A mark

Page 332 of 4801

NISSAN TEANA 2014 Service Manual BRM-54 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Description INFOID:0000000009464986 • All dimensions indicated in the figures are actual. • When using a tracking gauge, adjust bot

Page 333 of 4801

NISSAN TEANA 2014 Service Manual BODY ALIGNMENTBRM-55 < SERVICE DATA AND SPECIFICATIONS (SDS) C D E F G H I J L M A B BRM N O P Unit: mm (in) Figures marked with an (*) indicate symmetrically identical dimensions on both the RH a

Page 334 of 4801

NISSAN TEANA 2014 Service Manual BRM-56 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Unit: mm (in) UnderbodyINFOID:0000000009464988 Measurement Front Position Description Measurement A - a. Hood hinge hole 11 (0.43) B -

Page 335 of 4801

NISSAN TEANA 2014 Service Manual BODY ALIGNMENTBRM-57 < SERVICE DATA AND SPECIFICATIONS (SDS) C D E F G H I J L M A B BRM N O P NOTE: Figures marked with an (*) indicate symmetrically i dentical dimensions on both the RH and LH

Page 336 of 4801

NISSAN TEANA 2014 Service Manual BRM-58 < SERVICE DATA AND SPECIFICATIONS (SDS) BODY ALIGNMENT Unit: mm (in) Passenger CompartmentINFOID:0000000009464989 MEASUREMENTS Unit: mm (in) Position DescriptionG, g Front suspension member f
