Page 2177 of 4801

NISSAN TEANA 2014 Service Manual FRONT TIMING CHAIN CASEEM-179 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O 3. Install new O-rings (1) on rear timing chain case. CAUTION: Do not reuse O-rings. 4. Apply Sil

Page 2178 of 4801

NISSAN TEANA 2014 Service Manual EM-180 < REMOVAL AND INSTALLATION >[VQ35DE] FRONT TIMING CHAIN CASE 8. Install upper oil pan bolts (1) and (2) as shown. Refer to EM-157, "Removal and Installation (Upper Oil Pan)". 9. Install lower

Page 2179 of 4801

NISSAN TEANA 2014 Service Manual FRONT TIMING CHAIN CASEEM-181 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O • Before starting engine, check oil/fluid levels incl uding engine coolant and engine oil. If le

Page 2180 of 4801

NISSAN TEANA 2014 Service Manual EM-182 < REMOVAL AND INSTALLATION >[VQ35DE] TIMING CHAIN TIMING CHAIN Exploded ViewINFOID:0000000009460564 Removal and InstallationINFOID:0000000009460565 CAUTION: • After removing timing chain, d

Page 2181 of 4801

NISSAN TEANA 2014 Service Manual TIMING CHAINEM-183 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O 2. Remove the intake manifold collector. Refer to EM-146, "Removal and Installation". 3. Place paint marks o

Page 2182 of 4801

NISSAN TEANA 2014 Service Manual EM-184 < REMOVAL AND INSTALLATION >[VQ35DE] TIMING CHAIN a. Attach a suitable stopper pin (B) to the bank 1 (A) and bank 2 (C) timing chain tensioners (secondary) (1). NOTE: • Use approximately 0

Page 2183 of 4801

NISSAN TEANA 2014 Service Manual TIMING CHAINEM-185 < REMOVAL AND INSTALLATION > [VQ35DE] C D E F G H I J K L M A EM NP O 9. Remove the chain tension guide. INSPECTION Check for cracks and any excessive wear of the timing chain. R

Page 2184 of 4801

NISSAN TEANA 2014 Service Manual EM-186 < REMOVAL AND INSTALLATION >[VQ35DE] TIMING CHAIN 3. Install the secondary timing chains and camshaft sprockets. CAUTION: Matching marks between the timing chain and sprockets slip easily. C
