Page 2033 of 4801
![NISSAN TEANA 2014 Service Manual
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-35
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
4. Install the exhaust manifold cover (lower front) and bolts. Then
tighten the bo NISSAN TEANA 2014 Service Manual
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-35
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
4. Install the exhaust manifold cover (lower front) and bolts. Then
tighten the bo](/manual-img/5/57390/w960_57390-2032.png)
EXHAUST MANIFOLD AND THREE WAY CATALYST
EM-35
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
4. Install the exhaust manifold cover (lower front) and bolts. Then
tighten the bolts to specification in the numerical order shown.
CAUTION:
Do not reuse bolts.
5. Install the air fuel ratio (A/F) sensor 1 (1) using Tools (A) and tighten to specification.
CAUTION:
• Be careful not to damage air fuel ratio (A/F) sensor.
• Discard any air fuel ratio (A/F) sensor which has been
dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; replace with a new
one.
• Do not over-tighten the air fuel ratio (A/F) sensor 1. Doing so may cause damage to the air fuel
ratio (A/F) sensor 1, r esulting in a malfunction and the MIL coming on.
6. Install the exhaust manifold cover (upper). Then tighten the bolts to specification in the numerical order shown.
CAUTION:
Do not reuse bolts.
7. Installation of the remaining components is in the reverse order of removal.
ALBIA0889GB
Tool numbers : KV991J0050 (J-44626) : KV10117100 (J-36471-A)
ALBIA0919GB
ALBIA0888GB
Revision: November 20132014 Altima NAM
Page 2034 of 4801
EM-36
< REMOVAL AND INSTALLATION >[QR25DE]
OIL PAN AND OIL STRAINER
OIL PAN AND OIL STRAINER
Exploded ViewINFOID:0000000009460484
Removal and InstallationINFOID:0000000009460485
REMOVAL
WARNING:
To avoid the danger of being scalded, never dr ain the engine oil when the engine is hot.
1. Drain engine oil. Refer to LU-10, "Changing Engine Oil"
.
2. Remove the oil filter. Refer to LU-11, "Removal and Installation"
.
1. Oil pan, upper 2. Oil filter 3. Front cover
4. O-ring 5. Oil strainer 6. Oil pan, lower
7. Washer 8. Drain plug 9. O-ring
10. Oil level gauge guide 11. Oil level gauge 12. Rear cover plate
A. To Oil pan, lower
AWBIA1622ZZ
Revision: November 20132014 Altima NAM
Page 2035 of 4801
![NISSAN TEANA 2014 Service Manual
OIL PAN AND OIL STRAINEREM-37
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
3. Remove the front exhaust tube and gaskets. Refer to
EX-5, "Exploded View".
4. Remove the fende NISSAN TEANA 2014 Service Manual
OIL PAN AND OIL STRAINEREM-37
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
3. Remove the front exhaust tube and gaskets. Refer to
EX-5, "Exploded View".
4. Remove the fende](/manual-img/5/57390/w960_57390-2034.png)
OIL PAN AND OIL STRAINEREM-37
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
3. Remove the front exhaust tube and gaskets. Refer to
EX-5, "Exploded View".
4. Remove the fender protector side cover (RH). Refer to EXT-26, "FENDER PROTECTOR : Removal and
Installation".
5. Remove oil level gauge (1), oil level gauge guide (2), and O-ring (3).
CAUTION:
Do not reuse O-ring.
6. Disconnect the air fuel ratio sensor 1 electrical harness connector.
7. Remove the front driveshaft (LH) and front driveshaft (RH). Refer to FAX-10, "Removal and Installation
(LH)" and FAX-12, "Removal and Installation (RH)".
8. Remove the connecting rod (LH) and the connecting rod (RH). Refer to FSU-19, "Exploded View"
.
9. Remove the tie rod end from the steering knuckle ( RH) and the tie rod end from the steering knuckle (LH).
Refer to ST-36, "Exploded View"
.
10. Remove the power steering gear bolts and support the power steering gear. Refer to ST-36, "Removal
and Installation".
11. Remove the rear engine mount torque rod bracket. Refer to EM-84, "Removal and Installation"
.
12. Remove the front suspension member for clearance to remove the oil pan. Refer to FSU-20, "Removal
and Installation".
13. Disconnect the A/C compressor electrical harness connector.
14. Remove the drive belt. Refer to EM-19, "Removal and Installation"
.
15. Remove the A/C compressor bolts, position the A/C compressor aside and support. Refer to HA-30,
"COMPRESSOR : Removal and Installation".
16. Remove the lower oil pan bolts in the reverse order as shown, using power tool.
17. Remove the lower oil pan using Tool (A). CAUTION:
Be careful not to damage the mating surfaces.
NOTE:
In areas where the cutter is difficult to use, use a plastic hammer
to lightly tap (1) the cutter where the liquid gasket is applied. Use
a plastic hammer to slide (2) the cutter by tapping on the side.
ALBIA0910GB
ALBIA0830GB
Tool number : KV10111100 (J-37228)
AWBIA1249GB
Revision: November 20132014 Altima NAM
Page 2036 of 4801
![NISSAN TEANA 2014 Service Manual
EM-38
< REMOVAL AND INSTALLATION >[QR25DE]
OIL PAN AND OIL STRAINER
18. Remove the oil strainer bolts in the reverse order as shown then
remove the oil strainer.
19. Remove rear cover plate, and four NISSAN TEANA 2014 Service Manual
EM-38
< REMOVAL AND INSTALLATION >[QR25DE]
OIL PAN AND OIL STRAINER
18. Remove the oil strainer bolts in the reverse order as shown then
remove the oil strainer.
19. Remove rear cover plate, and four](/manual-img/5/57390/w960_57390-2035.png)
EM-38
< REMOVAL AND INSTALLATION >[QR25DE]
OIL PAN AND OIL STRAINER
18. Remove the oil strainer bolts in the reverse order as shown then
remove the oil strainer.
19. Remove rear cover plate, and four engine-to transaxle bolts, using power tool.
20. Loosen the upper oil pan bolts in the order shown using power tool.
21. Remove upper oil pan using Tool (A). • Remove the three O-rings from the upper oil pan and front
cover.
CAUTION:
Be careful not to damage the mating surfaces.
NOTE:
In areas where the cutter is difficult to use, use a plastic hammer
to lightly tap (1) the cutter where the liquid gasket is applied. Use
a plastic hammer to slide (2) the cutter by tapping on the side.
INSPECTION AFTER REMOVAL
Clean the oil strainer screen to remove any foreign material.
INSTALLATION
1. Apply Genuine Silicone RTV Sealant or equivalent to the upper oil pan at the specified sealant bead diameter (A) as shown.
Refer to GI-21, "Recommended Chemical Products and Seal-
ants".
CAUTION:
• Install two new O-rings in the upper oil pan and a new O- ring in the front cover.
• Do not reuse O-rings.
• Installation should be done within 5 minutes after apply- ing liquid gasket.
• Do not fill the engine with oil for at least 30 minutes after the co mponents are installed to allow
the liquid gasket to cure.
AWBIA1382ZZ
ALBIA0832GB
Tool number : KV10111100 (J-37228)AWBIA1249GB
Sealant bead
diameter (A) : 4.0 - 5.0 mm (0.157 - 0.197 in)
AWBIA1371ZZ
Revision: November 20132014 Altima NAM
Page 2037 of 4801
![NISSAN TEANA 2014 Service Manual
OIL PAN AND OIL STRAINEREM-39
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
2. Install the upper oil pan to the block and tighten the upper oil pan
bolts to specification in NISSAN TEANA 2014 Service Manual
OIL PAN AND OIL STRAINEREM-39
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
2. Install the upper oil pan to the block and tighten the upper oil pan
bolts to specification in](/manual-img/5/57390/w960_57390-2036.png)
OIL PAN AND OIL STRAINEREM-39
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
2. Install the upper oil pan to the block and tighten the upper oil pan
bolts to specification in the order shown.
3. Apply Genuine Silicone RTV Sealant or equivalent to the lower oil pan at the specified sealant bead diameter (A) as shown.
Refer to GI-21, "Recommended Chemical Products and Seal-
ants".
CAUTION:
• Installation should be done within 5 minutes after apply-
ing liquid gasket.
• Do not fill the engine with oi l for at least 30 minutes after
the components are installed to allow the liquid gasket to
cure.
4. Install the lower oil pan to the upper oil pan and tighten the lower oil pan bolts to specification in the numerical order shown.
5. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
Check for engine oil leaks with the engine at operating temperature and running at idle.
All bolts except 18 and 19 : 21.6 N·m (2.2 kg-m, 16.0 ft-
lb)
Bolts 18 and 19 : 8.8 N·m (0.90 kg-m, 78.0 in- lb)
ALBIA0832GB
Sealant bead
diameter (A) : 4.0 - 5.0 mm (0.157 - 0.197 in)ALBIA0834GB
ALBIA0830GB
Revision: November 20132014 Altima NAM
Page 2038 of 4801
EM-40
< REMOVAL AND INSTALLATION >[QR25DE]
IGNITION COIL
IGNITION COIL
Exploded ViewINFOID:0000000009460486
Removal and InstallationINFOID:0000000009460487
REMOVAL
1. Remove the engine room cover. Refer to
EM-28, "Removal and Installation".
2. Disconnect the harness connector from the ignition coil.
3. Remove the ignition coil. CAUTION:
Do not drop or shock it.
INSTALLATION
Installation is in the reverse order of removal.
1. Ignition coil 2. Spark plug 3. Rocker cover
AWBIA1302GB
Revision: November 20132014 Altima NAM
Page 2039 of 4801
FUEL INJECTOR AND FUEL TUBEEM-41
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
FUEL INJECTOR AND FUEL TUBE
Exploded ViewINFOID:0000000009460488
Removal and InstallationINFOID:0000000009460489
CAUTION:
• Apply new engine oil before inst alling the parts, as shown above.
• Do not remove or disassemble part s unless instructed as shown.
REMOVAL
1. Remove engine room cover. Refer to EM-28, "Removal and Installation".
2. Release the fuel pressure. Refer to EC-182, "Work Procedure"
.
3. Disconnect the battery negative terminal. Refer to PG-73, "Removal and Installation (Battery)"
.
4. Remove the air duct hose and resonator. Refer to EM-29, "Exploded View"
.
1. Rocker cover 2. Cylinder head 3. Fuel tube
4. Clip 5. O-ring (green) 6. Fuel injector
7. O-ring (black) Front
AWBIA1378ZZ
Revision: November 20132014 Altima NAM
Page 2040 of 4801
![NISSAN TEANA 2014 Service Manual
EM-42
< REMOVAL AND INSTALLATION >[QR25DE]
FUEL INJECTOR AND FUEL TUBE
5. Remove quick connector cap (1) from the fuel feed side (B) and
the fuel tube side (A).
6. Disconnect the fuel hose quick conn NISSAN TEANA 2014 Service Manual
EM-42
< REMOVAL AND INSTALLATION >[QR25DE]
FUEL INJECTOR AND FUEL TUBE
5. Remove quick connector cap (1) from the fuel feed side (B) and
the fuel tube side (A).
6. Disconnect the fuel hose quick conn](/manual-img/5/57390/w960_57390-2039.png)
EM-42
< REMOVAL AND INSTALLATION >[QR25DE]
FUEL INJECTOR AND FUEL TUBE
5. Remove quick connector cap (1) from the fuel feed side (B) and
the fuel tube side (A).
6. Disconnect the fuel hose quick connector at the fuel tube side using Tool (D).
CAUTION:
• Do not pull with lateral force applied. O-ring inside quick connector may be damaged.
• Prepare container and cloth beforehand as fuel will leak out.
• Avoid fire and sparks.
• Be sure to cover openings of disconnected pipes with
plug or plastic bag to avoid fuel leaks and entry of foreign
materials.
• Do not reuse O-ring.
a. With the sleeve (E) side of Tool (D) facing quick connector, install Tool onto fuel tube.
b. Insert Tool into quick connector until sleeve contacts and goes no further (A). Hold the Tool on that posi-
tion.
CAUTION:
Inserting the Tool hard will not disconnect quick connector. Hold Tool where it contacts and goes
no further.
c. Hold the fuel tube in the location (B) and pull the quick connector straight out in direction (C) from the fuel
tube.
7. Disconnect the EVAP canister purge volume control solenoid.
8. Remove the PCV hose from the rocker cover.
9. Disconnect sub-harness for injectors at engine front side, and remove it from bracket.
10. Disconnect the fuel injector harness connectors.
11. Loosen the bolts in the reverse order shown, then remove fuel tube and fuel injectors as an assembly.
12. Remove the fuel injectors from the fuel tube, (if necessary).
a. Release the clip.
b. Pull fuel injector straight out of the fuel tube. CAUTION:
• Be careful not to damage the nozzle.
• Avoid any impact, such as dropping the fuel injector.
• Do not disassemble or adjust the fuel injector.
INSTALLATION
1. Install new O-rings on the fuel injector.
CAUTION:
• Do not reuse O-rings.
• Upper and lower O-rings are different. Be careful not to confuse them.
ALBIA0890GB
Tool number : 16441 6N210 (J-45488)
ALBIA0891GB
AWBIA1261GB
Revision: November 20132014 Altima NAM
