COMBINATION METER
REMOVAL AND INSTALLATION
COMBINATION METER
Removal and InstallationINFOID:0000000009461757
REMOVAL
1. Disconnect the negative battery terminal. Refer to PG-73, "Removal and Installation (Battery)".
2. Remove cluster lid A. Refer to IP-19, "Removal and Installation"
.
3. Remove the combination meter screws (A).
4. Pull out the combination meter (1).
5. Disconnect the harness connector from the combination meter (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALNIA1388ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3338 of 4801
MWI
AMBIENT SENSORMWI-83
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
K L
M B
A
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000009461758
REMOVAL
1. Remove the core support cover clips (A), then remove the core support cover (1).
2. Disconnect the harness connector from the ambient sensor.
3. Release the ambient sensor clip, then remove the ambient sen- sor (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2602ZZ
ALIIA0314ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3339 of 4801

PB-1
BRAKES
C
D E
G H
I
J
K L
M
SECTION PB
A
B
PB
N
O P
CONTENTS
PARKING BRAKE SYSTEM
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Commercial Service Tool .................................... ......3
BASIC INSPECTION ....................................4
PARKING BRAKE SYSTEM .......................... .....4
Inspection ............................................................ ......4
Adjustment ................................................................4
PARKING BRAKE SHOE ...................................6
Inspection ............................................................ ......6
Break-in Procedure .............................................. .....6
REMOVAL AND INSTALLATION ................7
PARKING BRAKE CONTROL ...........................7
Exploded View ..................................................... .....7
Removal and Installation ..........................................7
PARKING BRAKE SHOE ..................................9
Exploded View ..........................................................9
Removal and Installation ..........................................9
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .............................................
11
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
11
Parking Drum Brake ............................................ ....11
Parking Brake Control .............................................11
Revision: November 20132014 Altima NAM
Page 3340 of 4801

PB-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951710
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: November 20132014 Altima NAM
Page 3341 of 4801
PREPARATIONPB-3
< PREPARATION >
C
D E
G H
I
J
K L
M A
B
PB
N
O P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000009462911
Tool name Description
Brake drum clearance gauge Measuring rear rotor drum inner diameter
Power tool Loosening nuts, screws and bolts
WFIA0167E
PIIB1407E
Revision: November 20132014 Altima NAM
Page 3342 of 4801

PB-4
< BASIC INSPECTION >
PARKING BRAKE SYSTEM
BASIC INSPECTION
PARKING BRAKE SYSTEM
InspectionINFOID:0000000009462912
PEDAL STROKE
1. Operate parking brake pedal with a force of 196 N (20.0 kg-f, 44.1 lb-f), make sure pedal stroke is within
the specified number of notches. (Check it by listening and counting ratchet clicks.)
2. When brake warning lamp turns ON, check that the pedal stroke is within the specified number of notches. (Check it by listening to the clicks of the ratchet.)
INSPECT COMPONENTS
• Make sure that the mounting conditions (loosenes s, backlash, etc.) of each component are normal.
• Check the following:
- Device assembly for bend, damage and cracks. Replace if necessary.
- Cables and equalizer for wear and damage. Replace if necessary.
- Parking brake switch. Replace if necessary.
AdjustmentINFOID:0000000009462913
ADJUSTMENT
1. Remove rear wheel and tire using power tool. Refer to WT-55, "Adjustment".
2. Insert a deep socket wrench onto adjusting nut. Rotate adjusting nut to fully loosen cable, and then release parking brake pedal.
3. Secure both disc rotors to hubs using wheel nuts so as not to tilt the disc rotors.
4. Remove both adjuster hole plugs installed on the disc rotors. Turn the adjusters in direction (A) using a suitable tool or a flat-
bladed screwdriver as shown, until disc rotors are locked. Turn
the adjusters in the opposite direction by 5 or 6 notches after
locking.
5. Rotate the disc rotors to make sure that there is no drag. Install the adjuster hole plugs.
6. Adjust parking brake cable with the following procedure.
a. Rotate the adjusting nut to adjust parking brake pedal operating force to 490 N (50.0 kg-f, 110.2 lb-f) just before a full pedal
stroke of 201.65 mm (7.94 in).
CAUTION:
Do not reuse adjusting nut after removing it.
b. When replacing parking brake cable, operate parking brake pedal 10 or more times with a full stroke of 201.65 mm (7.94 in).
c. Release the parking brake pedal and rotate the disc rotors to make sure there is no drag. Pedal stroke number of notches : Refer to
PB-11, "Parking Brake Control"
.
Standard
Number of notches : Refer to PB-11, "Parking Brake Control"
.
SFIA2961E
PFIA0295E
Revision: November 20132014 Altima NAM
Page 3343 of 4801

PARKING BRAKE SYSTEMPB-5
< BASIC INSPECTION >
C
D E
G H
I
J
K L
M A
B
PB
N
O P
d. Rotate the adjusting nut to adjust the parking brak e pedal force to 196 N (20.0 kg-f, 44.1 lb-f) when the
parking brake pedal stroke is within the specified number of notches. (check it by listening and counting
the ratchet clicks).
e. After adjustment, check that there is no drag with the parking brake pedal is being released. If drag exists,
perform the following:
• Remove the rear disc rotors, refer to BR-36, "BRAKE CALI-
PER ASSEMBLY : Removal and Installation". Verify the toggle
pedals return to the stoppers when the parking brake lever is
released.
• If a toggle lever does not return to a stopper, loosen adjusting nut.
• Install the rear disc rotor and adjust the shoe clearance. Refer to BR-40, "BRAKE CALIPER ASSEMBLY
: Removal and Installation".
7. Install rear wheel and tire. Refer to WT-55, "Adjustment"
.
Pedal stroke number of notches : Refer to
PB-11, "Parking Brake Control"
LFIA0095E
Revision: November 20132014 Altima NAM
Page 3344 of 4801

PB-6
< BASIC INSPECTION >
PARKING BRAKE SHOE
PARKING BRAKE SHOE
InspectionINFOID:0000000009462914
LINING THICKNESS INSPECTION
• Check thickness of lining.
DRUM INNER DIAMETER INSPECTION
• Check inner diameter of drum in rear disc rotor using a suitabletool.
OTHER INSPECTIONS
• Check the following:
- Lining for excessive wear, damage, and peeling.
- Shoe sliding surface for excessive wear and damage.
- Anti-rattle pin for excessive wear and corrosion.
- Return spring for sagging.
• Make sure that adjuster moves smoothly.
• Visually check the inside of drum for excessive wear, cracks, and damage.
• Replace with new parts as necessary.
Break-in ProcedureINFOID:0000000009462915
1. Perform parking brake break-in (drag run) operation by driving vehicle under the following conditions: • Drive the vehicle forward.
• Maintain vehicle speed at approximately 40 km/h (25 MPH) keeping it constant in forward direction.
• Apply the parking brake at the constant operating force specified. Approximately 200+49.0 Nm (20.4+5
kg-f, 45+11 lb-f).
• Release the parking brake after approximately 5+5/-0 seconds.
CAUTION:
To prevent lining from getting t oo hot, allow a cool off period of approximately 5 minutes after
every break-in operation.
2. Check parking brake control device assembly stroke. CAUTION:
Readjust as necessary if it is outside the standard specifications. Refer to PB-4, "Inspection"
.
Standard thickness (new) (A) : Refer to
PB-11, "Park-
ing Drum Brake".
Wear limit thickness (A) : Refer to PB-11, "Park-
ing Drum Brake".
SBR021A
Standard inner diameter (new) : Refer to PB-11, "Park-
ing Drum Brake".
Wear limit of inner diameter : Refer to PB-11, "Park-
ing Drum Brake".
SBR768A
Revision: November 20132014 Altima NAM
