Page 3745 of 4801
SB-10
< REMOVAL AND INSTALLATION >
FRONT SEAT BELT
2. For driver side, disconnect the harness connector from seat belt buckle.
3. Remove the seat belt buckle anchor bolt, then remove the seat belt buckle.
Installation
Installation is in the reverse order of removal.
• During installation, make sure the seat belt buckle anchor bolt (A) is inserted through the components in the following order:
1. Wave washer
2. Seat belt buckle
3. Spacer
4. Star washer
ALHIA0234GB
Revision: November 20132014 Altima NAM
Page 3746 of 4801
REAR SEAT BELTSB-11
< REMOVAL AND INSTALLATION >
C
D E
F
G
I
J
K L
M A
B
SB
N
O P
REAR SEAT BELT
Exploded ViewINFOID:0000000009462963
Removal and InstallationINFOID:0000000009462964
SEAT BELT RETRACTOR
Removal
1. Remove the rear seat cushion assembly, then fold down seatback assembly. Refer to SE-36, "Removal
and Installation - Seat Assembly".
2. Remove the seat belt lower anchor bolt.
3. Remove the rear parcel shelf finisher. Refer to INT-26, "Removal and Installation"
.
4. Remove the seat belt retractor upper anchor bolt, then remove the seat belt retractor.
Installation is in the reverse order of removal.
• Always perform an inspection after repair to be sure t he system in functioning within specifications. Refer to
SB-5, "Inspection"
.
1. Seat belt retractor (LH) 2. Seat belt re tractor (RH) 3. Seat belt retractor (center)
4. Seat belt buckle (RH) 5. Seat belt buckle (center) 6. Seat belt buckle (LH)
ALHIA0280ZZ
Revision: November 20132014 Altima NAM
Page 3747 of 4801
SB-12
< REMOVAL AND INSTALLATION >
REAR SEAT BELT
SEAT BELT BUCKLE
Removal
1. Remove the rear seat cushion assembly. Refer to SE-36, "Removal and Installation - Seat Assembly".
2. Remove seat belt buckle anchor bolt, then remove the seat belt buckle.
Installation
Installation is in the reverse order of removal.
Refer to SB-11, "Exploded View"
for proper torque specification.
Revision: November 20132014 Altima NAM
Page 3748 of 4801
LATCH SYSTEM FOR CHILDRENSB-13
< REMOVAL AND INSTALLATION >
C
D E
F
G
I
J
K L
M A
B
SB
N
O P
LATCH SYSTEM FOR CHILDREN
Removal and InstallationINFOID:0000000009462965
The LATCH (Lower Anchors and Tether for Children) system compo-
nents (1) are part of the vehicle structure, and are not serviceable.
: Front
ALHIA0282ZZ
Revision: November 20132014 Altima NAM
Page 3749 of 4801
SB-14
< REMOVAL AND INSTALLATION >
TOP TETHER STRAP CHILD RESTRAINT
TOP TETHER STRAP CHILD RESTRAINT
Removal and InstallationINFOID:0000000009462966
The top tether strap child restraint system components (1) are part of
the vehicle structure, and are not serviceable.
ALHIA0283ZZ
Revision: November 20132014 Altima NAM
Page 3750 of 4801

SE-1
BODY INTERIOR
C
D E
F
G H
I
K L
M
SECTION SE
A
B
SE
N
O P
CONTENTS
SEAT
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution for Work ..................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tools .......................................... ......3
Commercial Service Tool ..........................................3
CLIP LIST ............................................................4
Descriptions for Clips .......................................... ......4
WIRING DIAGRAM .......................................8
POWER SEAT FOR DRIVER SIDE ............... .....8
Wiring Diagram ................................................... ......8
HEATED SEAT ...................................................12
Wiring Diagram ................................................... ....12
SYMPTOM DIAGNOSIS ..............................17
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ........................................................... ....
17
Work Flow ........................................................... ....17
Generic Squeak and Rattle Troubleshooting ..........18
Diagnostic Worksheet .............................................21
REMOVAL AND INSTALLATION ...............23
FRONT SEAT ................................................. ....23
DRIVER SIDE ........................................................ ....23
DRIVER SIDE : Exploded View ..............................23
DRIVER SIDE : Removal and Installation - Seat
Assembly ............................................................. ....
26
DRIVER SIDE : Removal and Installation - Seat-
back Board .......................................................... ....
27
DRIVER SIDE : Removal and Installation - Lum-
bar Support Assembly ......................................... ....
27
PASSENGER SIDE ....................................................28
PASSENGER SIDE : Explode d View ......................29
PASSENGER SIDE : Removal and Installation -
Seat Assembly ..................................................... ....
30
PASSENGER SIDE : Removal and Installation -
Seatback Board ................................................... ....
31
HEATED SEAT SWITCH ....................................... ....31
HEATED SEAT SWITCH : Removal and Installa-
tion ....................................................................... ....
31
REAR SEAT ......................................................33
Exploded View .........................................................33
Removal and Installation - Seat Cushion Assem-
bly ........................................................................ ....
36
Removal and Installation - Seat Assembly ..............36
Removal and Installation - Seatback Hinge .............37
Removal and Installation - Seatback Latch As-
sembly ................................................................. ....
37
Removal and Installation - Armrest Assembly .........38
Removal and Installation - Rear Seat Bolster ..........38
UNIT DISASSEMBLY AND ASSEMBLY ....39
FRONT SEAT ....................................................39
DRIVER SIDE ......................................................... ....39
DRIVER SIDE : Exploded View ...............................39
DRIVER SIDE : Disassembly and Assembly ...........42
DRIVER SIDE : Side air bag module .......................50
PASSENGER SIDE ....................................................53
PASSENGER SIDE : Explode d View ......................54
PASSENGER SIDE : Disassembly and Assembly ....55
PASSENGER SIDE : Side air bag module ..............62
REAR SEAT ......................................................66
Exploded View .........................................................66
Disassembly and Assembly .....................................69
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3751 of 4801

SE-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951559
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000009462924
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a s hop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3752 of 4801
PREPARATIONSE-3
< PREPARATION >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000009895314
The actual shapes of the tools may differ from those illustrated here.
Commercial Service ToolINFOID:0000000009462926
Tool number
(TechMate No.)
Tool name Description
—
(J-39570)
Chassis Ear Locating the noise
—
(J-46534)
Trim Tool Set Removing trim components
—
(J-50397)
NISSAN Squeak and Rattle
Kit Repairing the cause of noise
SIIA0993E
AWJIA0483ZZ
ALJIA1232ZZ
(TechMate No.)
Tool name Description
(J-39565)
Engine Ear Locating the noise
SIIA0995E
