2014 NISSAN TEANA Service Manual

coolant capacity TPMS reset change key battery fuse box set clock wheel bolts

Load previous 8 pages

Page 105 of 4801

NISSAN TEANA 2014 Service Manual
BRAKE MASTER CYLINDERBR-9
< BASIC INSPECTION >
C
D E
G H
I
J
K L
M A
B
BR
N
O P
BRAKE MASTER CYLINDER
InspectionINFOID:0000000009463684
Check for brake fluid leakage at the following areas:
• Ma

Page 106 of 4801

NISSAN TEANA 2014 Service Manual
BR-10
< BASIC INSPECTION >
BRAKE BOOSTER
BRAKE BOOSTER
InspectionINFOID:0000000009463686
OPERATION
Depress the brake pedal several times at five second intervals with
the engine stopped. Start the e

Page 107 of 4801

NISSAN TEANA 2014 Service Manual
FRONT DISC BRAKEBR-11
< BASIC INSPECTION >
C
D E
G H
I
J
K L
M A
B
BR
N
O P
FRONT DISC BRAKE
BRAKE PAD
BRAKE PAD : InspectionINFOID:0000000009463687
PA D W E A R
Check brake pad thickness from an

Page 108 of 4801

NISSAN TEANA 2014 Service Manual
BR-12
< BASIC INSPECTION >
REAR DISC BRAKE
REAR DISC BRAKE
BRAKE PAD
BRAKE PAD : InspectionINFOID:0000000009463689
PA D W E A R
Check pad thickness from an inspection hole on caliper body. Check
us

Page 109 of 4801

NISSAN TEANA 2014 Service Manual
BRAKE PEDALBR-13
< PERIODIC MAINTENANCE >
C
D E
G H
I
J
K L
M A
B
BR
N
O P
PERIODIC MAINTENANCE
BRAKE PEDAL
Inspection and AdjustmentINFOID:0000000009463691
ADJUSTMENT
1. Loosen the stop lamp switc

Page 110 of 4801

NISSAN TEANA 2014 Service Manual
BR-14
< PERIODIC MAINTENANCE >
BRAKE FLUID
BRAKE FLUID
Drain and RefillINFOID:0000000009463692
CAUTION:
• Do not spill or splash brake fluid on painted surf aces. Brake fluid may damage paint. If

BR-14
< PERIODIC MAINTENANCE >
BRAKE FLUID
BRAKE FLUID
Drain and RefillINFOID:0000000009463692
CAUTION:
• Do not spill or splash brake fluid on painted surf aces. Brake fluid may damage paint. If brake fluid is
splashed on painted areas, wash it away with water immediately.
• Prior to repair, turn the ignition switch OFF, disconnect the ABS actuator and electric unit (control
unit) connector or negative battery terminal. Refer to PG-73, "Removal and Installation (Battery)"
.
• Refill brake system with new brake fluid. Refer to MA-11, "FOR USA AND CANADA : Fluids and
Lubricants".
• Do not reuse drained brake fluid.
DRAINING
1. Turn ignition switch OFF and disconnect ABS actuat or and electric unit (control unit) connector or nega-
tive battery terminal. Refer to PG-73, "Removal and Installation (Battery)"
.
2. Connect a vinyl tube to bleeder valve.
3. Depress brake pedal, loosen bleeder valve, and gradually remove brake fluid.
REFILLING
1. Make sure no foreign material is in the reservoir, and refill withnew brake fluid.
CAUTION:
Do not reuse drained brake fluid.
2. Refill the brake system as follows: • Depress the brake pedal.
• Loosen bleeder valve.
• Slowly depress brake pedal to 2/3 of the brake pedal full
stroke.
• Tighten bleeder valve.
• Release brake pedal.
Repeat this operation at intervals of two or three seconds until
all old brake fluid is discharged. Add new brake flui d to master cylinder reservoir sub tank frequently.
CAUTION:
Do not allow master cylinder reservoir to empt y as this may cause damage to master cylinder
internal components.
3. Bleed the air out of the brake hydraulic system. Refer to BR-14, "Bleeding Brake System"
.
Bleeding Brake SystemINFOID:0000000009463693
BLEEDING BRAKE SYSTEM
CAUTION:
• While bleeding, pay attention to master cylinder fluid level.
• Prior to repair, turn the ignition switch OFF, disconnect the ABS actuator and electric unit (control
unit) connector or negative battery terminal. Refer to PG-73, "Removal and Installation (Battery)"
.
1. Connect a vinyl tube to rear right brake caliper bleeder valve.
2. Fully depress brake pedal ten times.
3. With brake pedal depressed, loosen bleeder valve to bleed air in brake line, and then tighten it immedi-
ately.
BRA0007D
ALFIA0274ZZ
Revision: November 20132014 Altima NAM

Page 111 of 4801

NISSAN TEANA 2014 Service Manual
BRAKE FLUIDBR-15
< PERIODIC MAINTENANCE >
C
D E
G H
I
J
K L
M A
B
BR
N
O P
4. Repeat steps 2 and 3 until all of the air is out of the brake line.
5. Tighten the bleeder valve to the specified torq

Page 112 of 4801

NISSAN TEANA 2014 Service Manual
BR-16
< PERIODIC MAINTENANCE >
FRONT DISC BRAKE
FRONT DISC BRAKE
Brake BurnishingINFOID:0000000009463694
CAUTION:
• Burnish contact surfaces between brake pads and disc brake rotor according to t
