TM-330
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0776 PRESSURE CONTROL SOLENOID B
P0776 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464284
DTC DETECTION LOGIC
DTCCONSULT screen terms
(Troubl

TM-330
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0776 PRESSURE CONTROL SOLENOID B
P0776 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464284
DTC DETECTION LOGIC
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible cause
P0776 PC SOLENOID B
(Pressure Control Solenoid
“B” Performance/Stuck Off) When any of 1 or 2 is satisfied and this state
is maintained for 10 seconds:
1. When all of the following conditions are satisfied:
- DTC other than the applicable DTC is not detected.
- Engine speed: More than 625 rpm
- Selector lever: Other than P/N position
- CVT fluid temperature: More than - 20°C (-4 °F)
- TCM power supply: More than 11 V
- The difference between instruction pressure of secondary pressure and
10-msec-ago instruction secondary
pressure is 0 MPa or more
- Instruction pressure of secondary
pressure: 0 MPa or more
- Instruction pressure of secondary pressure - secondary pressure: More
than 1.2 MPa
- When all of the following conditions are satisfied and this state is maintained
for 5.5 seconds:
• DTC other than the applicable DTC is not detected.
• CVT fluid temperature: More than -
20°C (-4 °F)
• Selector lever: Other than P/N position
• Secondary pressure - instruction pres-
sure of secondary pressure: 1.2 MPa
or more
2. When all of the following conditions are
satisfied:
- DTC other than the applicable DTC is not detected.
- CVT fluid temperature: More than - 20°C (-4 °F)
- Selector lever: Other than P/N position
- TCM power supply: More than 11 V
- When all of the following conditions are satisfied and this state is maintained
for 5.5 seconds:
• DTC other than the applicable DTC is not detected.
• CVT fluid temperature: More than - 20°C (-4 °F)
• Selector lever: Other than P/N position
• Secondary pressure - instruction pres- sure of secondary pressure: 1.2 MPa
or more
- The difference between instruction pressure of secondary pressure and
10-msec-ago instruction secondary
pressure is 0 MPa or more
- Secondary pressure - instruction pres- sure of secondary pressure: More than
1.2 MPa Secondary pressure solenoid valve
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4546 of 4801

NISSAN TEANA 2014 Service Manual
P0776 PRESSURE CONTROL SOLENOID BTM-331
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PREPARAT

Page 4547 of 4801

NISSAN TEANA 2014 Service Manual
TM-332
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0778 PRESSURE CONTROL SOLENOID B
P0778 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464286
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAU

TM-332
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0778 PRESSURE CONTROL SOLENOID B
P0778 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464286
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine and wait for 5 seconds or more.
2. Check the first trip DTC.
Is
“P0778” detected?
YES >> Go to TM-332, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464287
1.CHECK CIRCUIT BETWEEN TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermitt ent incident. Refer to GI-43, "Intermittent Incident".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible cause
P0778 PC SOLENOID B
(Pressure Control Solenoid
“B” Electrical) When all of the following conditions are satisfied
and this state is maintained for 0.48 seconds:
• TCM power supply voltage: More than 11 V
• TCM judges that solenoid valve circuit is short-
ed to ground. • Harness or connectors
(Secondary pressure solenoid valve
circuit is shorted to ground.)
• Secondary pressure solenoid valve
TCM —Continuity
Connector Terminal
F16 39 Ground Not existed
CVT unit — Condition Resistance
Connector Terminal
F209 12 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4548 of 4801

NISSAN TEANA 2014 Service Manual
P0778 PRESSURE CONTROL SOLENOID BTM-333
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
NO >> GO TO 3.
3.CHECK CIRCUIT BETW EEN CVT UNIT AND CONTROL VALVE
1. Disconnect cont

Page 4549 of 4801

NISSAN TEANA 2014 Service Manual
TM-334
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0779 PRESSURE CONTROL SOLENOID B
P0779 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464288
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.P

Page 4550 of 4801

NISSAN TEANA 2014 Service Manual
P0779 PRESSURE CONTROL SOLENOID BTM-335
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43

Page 4551 of 4801

NISSAN TEANA 2014 Service Manual
TM-336
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0841 TRANSMISSION FLUID
PRESSURE SEN/SW A
P0841 TRANSMISSION FLUID PRESSURE SEN/SW A
DTC LogicINFOID:0000000009464290
DTC DETECTION LOGIC
DTC CONFIRM

TM-336
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10E]
P0841 TRANSMISSION FLUID
PRESSURE SEN/SW A
P0841 TRANSMISSION FLUID PRESSURE SEN/SW A
DTC LogicINFOID:0000000009464290
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PREPARATION BEFORE WORK
If another “DTC CONFIRMATION PROCEDURE” occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine.
2. Drive the vehicle.
3. Maintain the following condition for 10 seconds or more.
CAUTION:
Also keep the accelerator pedal position constant.
4. Stop the vehicle.
5. Check the first trip DTC.
Is
“P0841” detected?
YES >> Go to TM-336, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464291
1.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
Is the inspection result normal?
YES >> Replace the transaxle assembly. Refer to TM-407, "Removal and Installation".
NO >> Repair or replace damaged parts.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible cause
P0841 FLUID PRESS SEN/SW A
(Transmission Fluid Pres-
sure Sensor/Switch “A” Cir-
cuit Range/Performance) When all of the following conditions are sat-
isfied and this state is maintained for 5 sec-
onds:
• TCM power supply voltage: More than 11
V
• DTC other than the applicable DTC is not detected.
• Primary pulley speed: 300 rpm or more
• Secondary pulley speed: 250 rpm or more
• Target speed for shifting: Less than 0.1
seconds
• Primary pulley pressure is outside the specified value. • Harness or connectors
(Secondary pressure sensor circuit is
open or shorted.)
• Harness or connectors
(Primary pressure sens or circuit is open
or shorted.)
• Secondary pressure sensor
Selector lever : “D” position
Vehicle speed : Constant speed of 40 km/h (25 MPH)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4552 of 4801

NISSAN TEANA 2014 Service Manual
P0847 TRANSMISSION FLUID PRESSURE SEN/SW BTM-337
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0847 TRANSMISSION FLUI D PRESSURE SEN/SW B
DTC LogicINFOID:0000000009464292

P0847 TRANSMISSION FLUID PRESSURE SEN/SW BTM-337
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10E]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0847 TRANSMISSION FLUI D PRESSURE SEN/SW B
DTC LogicINFOID:0000000009464292
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “FLUID TEMP”.
4. Maintain the following conditions for 10 seconds or more.
5. Check the first trip DTC. With GST
1. Start the engine and wait for at least 10 seconds. CAUTION:
When the ambient temperature is less than −20 °C ( −4 °F) and the engine is cold, warm up the
engine for approximately 5 minutes.
2. Check the first trip DTC.
Is
“P0847”detected?
YES >> Go to TM-337, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464293
1.CHECK TCM INPUT SIGNALS
1. Turn ignition switch OFF.
2. Start the engine.
3. Check voltage between TCM harness connector terminals.
Is the inspection result normal?
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0847 FLUID PRESS SEN/SW B
(Transmission Fluid Pressure
Sensor/Switch B Circuit Low) When all of the following conditions are satis-
fied and this state is maintained for 5 seconds:
• CVT fluid temperature: More than −20 °C ( −
4 °F)
• TCM power supply voltage: 11 V or more
• Secondary pressure sensor voltage: 0.09 V or less • Harness or connector
(Secondary pressure sensor circuit is
open or shorted to ground)
• Secondary pressure sensor
• Control valve assembly
FLUID TEMP : −20 °C ( −4°F)
+
−Condition Voltage
TCM
Connector Terminal
F16 16 Ground • Selector lever:
“N” position
• At idle 1.67 – 1.69 V
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
