C1602 NO TUNING SET
C1602 NO TUNING SET
DTC LogicINFOID:0000000009460360
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“C1602” detected?
YES >> Proceed to diagnosis procedure. Refer to STC-26, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009460361
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Erase self-diagnostic results for “EPS”.
3. Turn the ignition switch OFF and wait for at least 10 seconds.
4. Perform self-diagnosis for “EPS”.
Is DTC
“C1602” detected?
YES >> Power steering motor is malfunctioning. Replace power steering oil pump assembly. Refer to ST-
38, "Removal and Installation".
NO >> Check pin terminal and connection of each harness connector for malfunctioning conditions.
DTC Display item Malfunction detected condition Possible cause
C1602 NO TUNING SET Configration is not finished. • Harness or connector
• Power steering control mod-
ule
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4178 of 4801

C1606 EPS MOTORSTC-27
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
C1606 EPS MOTOR
DTC LogicINFOID:0000000009460362
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“C1606” detected?
YES >> Proceed to diagnosis procedure. Refer to STC-27, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009460363
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Erase self-diagnostic results for “EPS”.
3. Turn the ignition switch OFF and wait for at least 10 seconds.
4. Perform self-diagnosis for “EPS”.
Is DTC
“C1606” detected?
YES >> Power steering motor is malfunctioning. Replace power steering oil pump assembly. Refer to ST-
38, "Removal and Installation".
NO >> Check pin terminal and connection of each harness connector for malfunctioning conditions.
DTC Display item Malfunction detected condition Possible cause
C1606 EPS MOTOR When the motor driver malfunction of power steer-
ing control module or power steering control mod-
ule motor driver malfunction is detected. • Harness or connector
• Power steering control motor
• Power steering control mod- ule
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4179 of 4801

STC-28
< DTC/CIRCUIT DIAGNOSIS >
C1607, C1608 POWER STEERING CONTROL MODULE
C1607, C1608 POWER STEERING CONTROL MODULE
DTC LogicINFOID:0000000009460364
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“C1607” or “C1608” detected?
YES >> Proceed to diagnosis procedure. Refer to STC-28, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009460365
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Erase self-diagnostic results for “EPS”.
3. Turn the ignition switch OFF and wait for at least 10 seconds.
4. Perform self-diagnosis for “EPS”.
Is DTC
“C1607” or “C1608” detected?
YES >> Power steering control module is malfunctioni ng. Replace power steering oil pump assembly.
Refer to ST-38, "Removal and Installation"
.
NO >> Check pin terminal and connection of each harness connector for malfunctioning conditions.
DTC Display item Malfunction detected condition Possible cause
C1607 EEPROM When the memo
ry (EEPROM) system malfunction is
detected in power steering control module. Power steering control module
C1608 CONTROL UNIT When the internal malfunction is detected in power
steering control module.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4180 of 4801

C160A HEAT PROTECTIONSTC-29
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
C160A HEAT PROTECTION
DTC LogicINFOID:0000000009460366
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“C160A” detected?
YES >> Go to STC-19, "Work Flow".
NO >> Inspection End.
DTC Display item Malfunction detected condition Possible cause
C160A HEAT PROTECTION When the steering wheel is operated excessively
and the interior temperature of the power steering
system reaches 118 °C (244.4 °F) or more. (Protec-
tion function)
NOTE:
Although the hydraulic pump electric power steering
system warning lamp turns ON, this is not a system
malfunction. The state returns to normal after stop-
ping steering operation and waiting until the system
interior temperature drops to 90 °C (194 °F) or less. The protection of the hydraulic
pump electric power steering sys-
tem
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4181 of 4801

STC-30
< DTC/CIRCUIT DIAGNOSIS >
U1000 CAN COMM CIRCUIT
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000009460367
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication s peed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CA N communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit communicate data but selectively reads required data only.
DTC LogicINFOID:0000000009460368
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“U1000” detected?
YES >> Go to STC-30, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009460369
Proceed to LAN-32, "CAN COMMUNICATION SYSTEM : CAN Communication Signal Chart".
DTC Display item Malfunction detected condition Possible cause
U1000 CAN COMM CIRCUIT Power steering control module is not transmitting/re-
ceiving CAN communication signal for 2 seconds or
more. CAN communication error
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4182 of 4801

HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP
STC-31
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
HYDRAULIC PUMP ELECTRIC PO WER STEERING WARNING LAMP
Component Function CheckINFOID:0000000009460370
1.CHECK THE ILLUMINATION OF THE HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING
LAMP
Check that the hydraulic pump electric power steering warning lamp turns ON when ignition switch turns ON.
Then, hydraulic pump electric power steering warn ing lamp turns OFF after the engine is started.
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform trouble diagnosis. Refer to STC-31, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009460371
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is any DTC detected?
YES >> Check the DTC. Refer to STC-13, "DTC Index".
NO >> GO TO 2.
2.CHECK HYDRAULIC PUMP ELECTRIC PO WER STEERING WARNING LAMP SIGNAL
With CONSULT
1. Turn the ignition switch ON.
2. Select “WARNING LAMP” in “DATA MONITOR” of “EPS”.
3. Check that the item in “DATA MONITOR” is “On”. CAUTION:
The engine should not be running for step 3.
4. Start the engine. CAUTION:
Never drive the vehicle during the test.
5. Check that the item in “DATA MONITOR” is “Off”.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for combinat ion meter power supply circuit. Refer to MWI-58,
"COMBINATION METER : Diagnosis Procedure".
NO >> GO TO 3.
3.CHECK TERMINALS AND HARNESS CONNECTORS
Check the power steering control module pin terminal s for damage or loose connection with harness connec-
tor.
Is the inspection result normal?
YES >> Power steering control module is malfuncti oning. Replace power steering oil pump assembly.
Refer to ST-38, "Removal and Installation"
.
NO >> Repair or replace the malfunctioning component.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4183 of 4801
STC-32
< SYMPTOM DIAGNOSIS >
HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP DOES NOT TURN ON
SYMPTOM DIAGNOSIS
HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP
DOES NOT TURN ON
DescriptionINFOID:0000000009460372
The hydraulic pump electric power steering warning lamp does not illuminate when the ignition switch is
turned ON (lamp check).
Diagnosis ProcedureINFOID:0000000009460373
1.CHECK THE HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP
Perform trouble diagnosis for the hydraulic pump electric power steering warning lamp system. Refer to STC-
31, "Diagnosis Procedure".
Is the inspection result normal?
YES >> Check that the pin terminals and t he connection of each connector are normal.
NO >> Repair or replace the malfunctioning components.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 4184 of 4801

HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP DOES
NOT TURN OFF
STC-33
< SYMPTOM DIAGNOSIS >
C
D E
F
H I
J
K L
M A
B
STC
N
O P
HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP
DOES NOT TURN OFF
DescriptionINFOID:0000000009460374
Hydraulic pump electric power steering warning lamp does not turn OFF several seconds after engine started
Diagnosis ProcedureINFOID:0000000009460375
1.PERFORM SELF-DIAGNOSIS
With CONSULT
Perform “EPS” self-diagnosis.
Is any DTC detected?
YES >> Check the DTC. Refer to STC-13, "DTC Index".
NO >> GO TO 2.
2.CHECK HYDRAULIC PUMP ELECTRIC POWER STEERING WARNING LAMP
Perform the trouble diagnosis of hydraulic pump el ectric power steering warning lamp. Refer to STC-31,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning components.
3.POWER STEERING CONT ROL MODULE POWER SUPPLY AND GROUND CIRCUIT
Perform the trouble diagnosis of power steering control module power supply and ground. Refer to STC-23,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> Check that the pin terminals and t he connection of each connector are normal.
NO >> Repair or replace the malfunctioning components.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
