Page 4361 of 4801

NISSAN TEANA 2014 Service Manual
TM-146
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0962 PRESSURE CONTROL SOLENOID A
3.CHECK CIRCUIT BETWEEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-187, "Removal a

Page 4362 of 4801

NISSAN TEANA 2014 Service Manual
P0963 PRESSURE CONTROL SOLENOID ATM-147
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0963 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000009464089
DTC DETECTION LOGI

P0963 PRESSURE CONTROL SOLENOID ATM-147
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0963 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000009464089
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine and wait for 5 seconds or more.
2. Check the first trip DTC.
Is
“P0963” detected?
YES >> Go to TM-147, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464090
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0963 PC SOLENOID A
(Pressure Control Solenoid A
Control Circuit High) When all of the following conditions are satis-
fied and this state is maintained for 0.2 sec-
onds:
• TCM power supply voltage: More than 11 V
• P0962 is not detected
• TCM judges that solenoid valve circuit is open. • Harness or connector
(Line pressure solenoid valve circuit is
open or shorted to power supply)
• Line pressure solenoid valve
TCM CVT unit Continuity
Connector Terminal Connector Terminal
F1630F4620Existed
CVT unit — Condition Resistance
Connector Terminal
F209 20 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4363 of 4801

NISSAN TEANA 2014 Service Manual
TM-148
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0963 PRESSURE CONTROL SOLENOID A
NO >> GO TO 3.
3.CHECK CIRCUIT BETWEEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-

Page 4364 of 4801

NISSAN TEANA 2014 Service Manual
P0965 PRESSURE CONTROL SOLENOID BTM-149
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0965 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464091
DTC DETECTION LOGI

P0965 PRESSURE CONTROL SOLENOID BTM-149
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0965 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464091
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0965 PC SOLENOID B
(Pressure Control Solenoid B
Control Circuit Range Perfor-
mance) When any of 1 or 2 is satisfied and this state is
maintained for 10 seconds:
1. When all of the following conditions are satisfied:
- DTC other than the applicable DTC is not detected.
- Engine speed: More than 625 rpm
- Selector lever: Other than P/N position
- CVT fluid temperature: More than -20 °C
(-4 °F)
- TCM power supply: More than 11 V
- The difference between instruction pres- sure of primary pressure and 10-msec-
ago instruction primary pressure is 0
MPa or more
- Instruction pressure of primary pressure:
0.86 MPa or more
- Instruction pressure of primary pressure - primary pressure: More than 1.2 MPa
- When all of the following conditions are
satisfied and this state is maintained for
1 second:
• DTC other than the applicable DTC is not
detected.
• CVT fluid temperature: More than -20 °C
(-4 °F)
• Selector lever: Other than P/N position
• Engine speed: More than 625 rpm
• Instruction pressure of primary pressure:
More than 2 MPa
• Primary pressure: 0.4 MPa or less
2. When all of the following conditions are
satisfied:
- DTC other than the applicable DTC is not detected.
- CVT fluid temperature: More than -20 °C
(-4 °F)
- Selector lever: Other than P/N position
- TCM power supply: More than 11 V
- When all of the following conditions are satisfied and this state is maintained for
5.5 seconds:
• DTC other than the applicable DTC is not detected.
• CVT fluid temperature: More than -20 °C
(-4 °F)
• Selector lever: Other than P/N position
• Primary pressure - instruction pressure
of primary pressure: 1.2 MPa or more
- The difference between instruction pres-
sure of primary pressure and 10-msec-
ago instruction primary pressure is 0
MPa or more
- Primary pressure - instruction pressure
of primary pressure: More than 1.2 MPa • Harness or connector
(Primary pressure solenoid valvecircuit
is open or shorted.)
• Primary pressure solenoid valve
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4365 of 4801

NISSAN TEANA 2014 Service Manual
TM-150
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0965 PRESSURE CONTROL SOLENOID B
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wa

Page 4366 of 4801

NISSAN TEANA 2014 Service Manual
P0966 PRESSURE CONTROL SOLENOID BTM-151
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0966 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464093
DTC DETECTION LOGI

P0966 PRESSURE CONTROL SOLENOID BTM-151
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0966 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464093
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine and wait for 5 seconds or more.
2. Check the first trip DTC.
Is
“P0966” detected?
YES >> Go to TM-151, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464094
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> GO TO 3.
DTC CONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0966 PC SOLENOID B
(Pressure Control Solenoid B
Control Circuit Low) When all of the following conditions are satis-
fied and this state is maintained for 0.48 sec-
onds:
• TCM power supply voltage: More than 11 V
• TCM judges that solenoid valve circuit is shorted to ground. • Harness or connector
(Primary pressure solenoid valve cir-
cuit shorted to ground)
• Primary pressure solenoid valve
TCM
—Continuity
Connector Terminal
F16 40 Ground Not existed
CVT unit — Condition Resistance
Connector Terminal
F209 13 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 4367 of 4801

NISSAN TEANA 2014 Service Manual
TM-152
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F10D]
P0966 PRESSURE CONTROL SOLENOID B
3.CHECK CIRCUIT BETWEEN CVT UNIT AND CONTROL VALVE
1. Disconnect control valve connector. Refer to TM-187, "Removal a

Page 4368 of 4801

NISSAN TEANA 2014 Service Manual
P0967 PRESSURE CONTROL SOLENOID BTM-153
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0967 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464095
DTC DETECTION LOGI

P0967 PRESSURE CONTROL SOLENOID BTM-153
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F10D]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0967 PRESSURE CONTROL SOLENOID B
DTC LogicINFOID:0000000009464095
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
1. Start the engine and wait for 5 seconds or more.
2. Check the first trip DTC.
Is
“P0967” detected?
YES >> Go to TM-153, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009464096
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK CIRCUIT BETWEEN CVT UNIT AND GROUND
Check continuity between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
DTCCONSULT screen terms
(Trouble diagnosis content) DTC detection condition Possible causes
P0967 PC SOLENOID B
(Pressure Control Solenoid B
Control Circuit High) When all of the following conditions are satis-
fied and this state is maintained for 0.2 sec-
onds:
• TCM power supply voltage: More than 11 V
• P0966 is not detected
• TCM judges that solenoid valve circuit is open. • Harness or connector
(Primary pressure solenoid valve cir-
cuit open or shorted to power supply)
• Primary pressure solenoid valve
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F1640F4613Existed
CVT unit — Condition Resistance
Connector Terminal
F209 13 Ground CVT fluid temperature: 20
°C (68 °F) 5.5 – 7.0 Ω
CVT fluid temperature: 50 °C (122 °F) 6.0 – 8.0 Ω
CVT fluid temperature: 80 °C (176 °F) 6.5 – 8.5 Ω
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
