RF-24
< DTC/CIRCUIT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> Refer to RF-24, "MOONROOF MOTOR ASSEMBLY : Component Inspection".
NO >> Repair or replace the harness or connectors.
8. CHECK COMBINATION METER SIGNAL
1. Check signal between moonroof motor assembly connector R5 and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace moonroof motor assembly. Refer to RF-46, "Removal and Installation". After that, refer to
RF-20, "ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Require-
ment".
NO >> GO TO 9.
9.CHECK COMBINATION METER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter.
3. Check continuity between combination meter c onnector M24 and moonroof motor assembly connector
R5.
4. Check continuity between combination meter connector M24 and ground.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-82, "Removal and Installation".
NO >> Repair or replace the harness or connectors.
MOONROOF MOTOR ASSEMBLY : Component InspectionINFOID:0000000009461307
MOONROOF SWITCH
1. CHECK MOONROOF SWITCH
1. Turn ignition switch OFF.
2. Disconnect moonroof switch.
3. Check continuity between moonroof switch terminals.
Moonroof switch connector Terminal GroundContinuity
R6 1 Yes
Te r m i n a l s
Condition Signal
(Reference value)
(+) (-)
Moonroof motor assembly con-
nector Te r m i n a l
Ground
R5 8 Speed meter operat-
ed [When vehicle
speed is ap-
prox.40km/h (25MPH)]
ELF1080D
Combination meter connector Terminal Moonroof motor
assembly con-
nector Terminal Continuity
M24 33 R5 8 Yes
Combination meter connector Terminal GroundContinuity
M24 33 No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3690 of 4801

POWER SUPPLY AND GROUND CIRCUITRF-25
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
Is the inspection result normal?
YES >> Moonroof switch is OK.
NO >> Replace moonroof switch (map lamp assembly). Refer to INL-63, "Removal and Installation"
.
MOONROOF MOTOR ASSEMBLY : Special Repair RequirementINFOID:0000000009461308
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
>> GO TO 2.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check fitting adjustment. Refer to RF-43, "Inspection"
.
Terminals Condition Continuity
3 1Moonroof switch is operated
TILT DOWN or SLIDE OPEN Ye s
Other than above No
4 Moonroof switch is operated
TILT UP or SLIDE CLOSE Ye s
Other than above No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3691 of 4801

RF-26
< DTC/CIRCUIT DIAGNOSIS >
MOONROOF SWITCH
MOONROOF SWITCH
DescriptionINFOID:0000000009461309
Transmits switch operation signal to moonroof motor assembly.
Diagnosis ProcedureINFOID:0000000009461310
Regarding Wiring Diagram information, refer to RF-12, "Wiring Diagram".
1.CHECK MOONROOF SWITCH INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between moonroof motor assembly harness connector R5 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 2.
2.CHECK MOONROOF SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect moonroof motor assembly connector and moonroof switch connector.
3. Check continuity between moonroof motor assemb ly harness connector R5 and moonroof switch harness
connector R6.
4. Check continuity between moonroof moto r assembly harness connector R5 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the harness or connectors.
3.CHECK MOONROOF SWITCH GROUND CIRCUIT
Check continuity between moonroof switch harness connector R6 and ground.
(+)
(–) Condition Voltag e
(Approx.)
Moonroof motor assembly
Connector Terminals
R5 5
GroundMoonroof switch is operated
TILT DOWN or SLIDE
OPEN 0
Other than above Battery voltage
10 Moonroof switch is operated
TILT UP or SLIDE CLOSE 0
Other than above Battery voltage
Moonroof motor assembly Moonroof switch Continuity
Connector Terminal Connector Terminal
R5 5
R6 3
Ye s
10 4
Moonroof motor assembly GroundContinuity
Connector Terminal
R5 5
No
10
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3692 of 4801

MOONROOF SWITCHRF-27
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the harness or connectors.
4.CHECK MOONROOF SWITCH
Check moonroof switch.
Refer to RF-27, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace moonroof switch. Refer to INL-63, "Removal and Installation"
.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461311
MOONROOF SWITCH
1. CHECK MOONROOF SWITCH
1. Turn ignition switch OFF.
2. Disconnect moonroof switch.
3. Check continuity between moonroof switch terminals.
Is the inspection result normal?
YES >> Moonroof switch is OK.
NO >> Replace moonroof switch. Refer to INL-63, "Removal and Installation"
.
Moonroof switch
GroundContinuity
Connector Terminal
R6 1 Yes
Terminals Condition Continuity
3 1Moonroof switch is operated TILT DOWN or SLIDE OPEN
OPEN Ye s
Other than above No
4 Moonroof switch is operated TILT UP or SLIDE CLOSE
CLOSE Ye s
Other than above No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3693 of 4801

RF-28
< DTC/CIRCUIT DIAGNOSIS >
DOOR SWITCH
DOOR SWITCH
DescriptionINFOID:0000000009461312
Detects door open/close condition.
Component Function CheckINFOID:0000000009461313
1.CHECK FUNCTION
With CONSULT
Check door switches DOOR SW-DR, DOOR SW-AS in Data Monitor mode with CONSULT.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to RF-28, "Diagnosis Procedure"
.
Diagnosis ProcedureINFOID:0000000009461314
Regarding Wiring Diagram information, refer to DLK-51, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4
NO >> GO TO 2
Monitor item Condition
DOOR SW-DR CLOSE → OPEN: OFF → ON
DOOR SW-AS
Te r m i n a l s
Door condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M19 96
GroundFront door switch
LH OPEN 0
CLOSE
94 Front door switch
RH OPEN 0
CLOSE
JPMIA0011GB
JPMIA0011GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3694 of 4801

DOOR SWITCHRF-29
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM connector and door switch connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Refer to RF-29, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace malfunctioning door switch.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-43, "Intermittent Incident"
.
>> Inspection End.
Component InspectionINFOID:0000000009461315
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect door switch connector.
3. Check door switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning door switch.
BCM connector Terminal Door switch
connector Terminal Continuity
M19 96 Front door switch LH Ground
part of
door
switch Ye s
94 Front door switch RH
BCM connector Terminal GroundContinuity
M19 96
No
94
Te r m i n a l Door switch condition Continuity
Door switch
3 Ground part of
door switch Pressed No
Released Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3695 of 4801
RF-30
< SYMPTOM DIAGNOSIS >
MOONROOF DOES NOT OPERATE PROPERLY
SYMPTOM DIAGNOSIS
MOONROOF DOES NOT OPERATE PROPERLY
Diagnosis ProcedureINFOID:0000000009461316
1. CHECK BCM POWER SUPPLY AND GROUND CIRCUIT
Check BCM power supply and ground circuit.
Refer to BCS-74, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2. CHECK MOONROOF MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT
Check moonroof motor assembly power supply and ground circuit.
Refer to RF-22, "MOONROOF MOTOR ASSEM BLY : Component Function Check"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3696 of 4801
AUTO OPERATION DOES NOT OPERATERF-31
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
AUTO OPERATION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000009461317
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to RF-20, "ADDITIONAL SERVICE WHEN REPLACIN G CONTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> Inspection End.
NO >> Perform basic inspection. Refer to RF-18, "Work Flow"
.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
