C1116 STOP LAMP SWITCHBRC-79
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace as necessary.
4.CHECK STOP LAMP RELAY CIRCUIT FOR SHORT
Check continuity between ABS actuator and electric unit (control unit) connector E54 terminal 30 and ground.
Is the inspection result normal?
YES >> Refer to EXL-86, "Work Flow".
NO >> Repair harness or connectors.
ABS actuator and electric unit (control unit) Stop lamp relay
Continuity
Connector Terminal Connector Terminal
E54 30 E57 3 Yes
ABS actuator and electric unit (control unit)
Ground Continuity
Connector Terminal
E54 30 — No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 226 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-80
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1120, C1122, C1124, C112
6 ABS IN VALVE SYSTEM
C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
DTC LogicINFOID:0000000009463786
DTC DETECTION LOGIC
DTC NISSAN TEANA 2014 Service Manual
BRC-80
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1120, C1122, C1124, C112
6 ABS IN VALVE SYSTEM
C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
DTC LogicINFOID:0000000009463786
DTC DETECTION LOGIC
DTC](/manual-img/5/57390/w960_57390-225.png)
BRC-80
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1120, C1122, C1124, C112
6 ABS IN VALVE SYSTEM
C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
DTC LogicINFOID:0000000009463786
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch ON.
2. Perform self diagnostic result.
Is DTC C1120, C1122, C1124 or C1126 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-80, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463787
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check connector and terminals for defo rmation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 25 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C1120 FR LH IN ABS SOL When a malfunction is detected in front LH ABS IN
valve.
• Harness or connector
• ABS actuator and electric unit
(control unit)
• Fusible link
• Battery power supply system
C1122 FR RH IN ABS SOL
When a malfunction is detected in front RH ABS IN
valve.
C1124 RR LH IN ABS SOL When a malfunction is de
tected in rear LH ABS IN
valve.
C1126 RR RH IN ABS SOL When a malfunction is de
tected in rear RH ABS IN
valve.
ABS actuator and electric unit (control unit) —Vo l ta g e
(Approx.)
Connector Terminal
E54 25 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 227 of 4801
C1120, C1122, C1124, C1126 ABS IN VALVE SYSTEM
BRC-81
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 228 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-82
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1121, C1123, C
1125, C1127 ABS OUT VALVE SYSTEM
C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
DTC LogicINFOID:0000000009463788
DTC DETECTION LOGIC
DT NISSAN TEANA 2014 Service Manual
BRC-82
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1121, C1123, C
1125, C1127 ABS OUT VALVE SYSTEM
C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
DTC LogicINFOID:0000000009463788
DTC DETECTION LOGIC
DT](/manual-img/5/57390/w960_57390-227.png)
BRC-82
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1121, C1123, C
1125, C1127 ABS OUT VALVE SYSTEM
C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
DTC LogicINFOID:0000000009463788
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch ON.
2. Perform self diagnostic result.
Is DTC C1121, C1123, C1125 or C1127 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-82, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463789
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check connector and terminals for defo rmation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 25 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C1121 FR LH OUT ABS SOL When a malfunction is dete
cted in front LH ABS OUT
valve.
• Harness or connector
• ABS actuator and electric unit
(control unit)
• Fusible link
• Battery power supply system
C1123 FR RH OUT ABS SOL
When a malfunction is detected in front RH ABS OUT
valve.
C1125 RR LH OUT ABS SOL When a malfunction is detected in rear LH ABS OUT
valve.
C1127 RR RH OUT ABS SOL When a malfunction is detected in rear RH ABS OUT
valve.
ABS actuator and electric unit (control unit) —Vo l ta g e
(Approx.)
Connector Terminal
E54 25 Ground Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 229 of 4801
C1121, C1123, C1125, C1127 ABS OUT VALVE SYSTEM
BRC-83
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 230 of 4801
![NISSAN TEANA 2014 Service Manual
BRC-84
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1130 ENGINE SIGNAL
C1130 ENGINE SIGNAL
DTC LogicINFOID:0000000009463790
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
W NISSAN TEANA 2014 Service Manual
BRC-84
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1130 ENGINE SIGNAL
C1130 ENGINE SIGNAL
DTC LogicINFOID:0000000009463790
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
W](/manual-img/5/57390/w960_57390-229.png)
BRC-84
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1130 ENGINE SIGNAL
C1130 ENGINE SIGNAL
DTC LogicINFOID:0000000009463790
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch ON.
2. Perform self diagnostic result.
Is DTC C1130 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-84, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463791
1.CHECK SELF DIAGNOSTIC RESULT FOR ENGINE SYSTEM
With CONSULT.
Perform self diagnostic result. Refer to EC-77, "CONSULT Function"
(QR25DE) or EC-601, "CONSULT Func-
tion" (VQ35DE).
Are any ECM DTCs detected?
YES >> Refer to EC-105, "DTC Index" (QR25DE) or EC-630, "DTC Index" (VQ35DE).
NO >> GO TO 2.
2.CHECK SELF DIAGNOSTIC RESU LT FOR ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
With CONSULT.
1. Perform self diagnostic result and erase DTCs.
2. Turn ignition switch OFF.
3. Start engine and drive vehicle for a short period of time.
4. Check that malfunction indicator lamp (MIL) turns OFF.
5. Stop vehicle and perform self diagnostic result.
Is DTC C1130 detected?
YES >> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Check pin terminals and connection of connectors for abnormal conditions. Repair or replace mal- functioning components.
DTC Display Item Malfunction detected condition Possible causes
C1130 ENGINE SIGNAL 1 When a malfunction is detected in ECM system. •ECM
• ABS actuator and electric unit
(control unit)
• CAN communication line
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 231 of 4801
![NISSAN TEANA 2014 Service Manual
C1140 ACTUATOR RELAY SYSTEMBRC-85
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1140 ACTUATOR RELAY SYSTEM
DTC LogicINFOID:0000000009463792
DTC DETECTION LOGIC
DTC CON NISSAN TEANA 2014 Service Manual
C1140 ACTUATOR RELAY SYSTEMBRC-85
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1140 ACTUATOR RELAY SYSTEM
DTC LogicINFOID:0000000009463792
DTC DETECTION LOGIC
DTC CON](/manual-img/5/57390/w960_57390-230.png)
C1140 ACTUATOR RELAY SYSTEMBRC-85
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1140 ACTUATOR RELAY SYSTEM
DTC LogicINFOID:0000000009463792
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn ignition switch ON.
2. Perform self diagnostic result.
Is DTC C1140 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-85, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463793
Regarding Wiring Diagram information, refer to BRC-47, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check connector and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) BATTERY POWER SUPPLY
Check voltage between ABS actuator and electric uni t (control unit) connector E54 terminal 25 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning components.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (contro l unit) connector E54 terminals 13, 38 and
ground.
DTC Display Item Malfunction detected condition Possible causes
C1140 ACTUATOR RLY When a malfunction is detected in actuator relay. • Harness or connector
• ABS actuator and electric unit
(control unit)
• Fusible link
• Battery power supply system
ABS actuator and electric unit (control unit)
—Vol tag e
(Approx.)
Connector Terminal
E54 25 Ground Battery voltage
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E54 13
Ground Yes
38
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 232 of 4801
BRC-86
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1140 ACTUATOR RELAY SYSTEM
Is the inspection result normal?
YES >> Replace ABS actuator and electr
ic unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
