WATER PUMPCO-45
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
4. Remove cowl top extension. Refer to
EXT-24, "Removal and Installation".
5. Remove the front road wheel and tire (RH). Refer to WT-55, "Adjustment"
.
6. Remove the fender protector (RH). Refer to EXT-26, "FENDER PROTECTOR : Removal and Installation"
.
7. Drain coolant from the radiator. Refer to CO-36, "Changing Engine Coolant"
.
CAUTION:
Perform when the engine is cold.
8. Disconnect coolant reservoir hose and remove coolant reservoir tank. Refer to CO-40, "Exploded View"
.
9. Drain the power steering fluid reservoir. Refer to ST-30, "Draining and Refilling"
.
10. Remove the power steering oil pump. Refer to ST-38, "Removal and Installation"
.
11. Support engine and remove the RH engine insulator and bracket. Refer to EM-220, "Exploded View"
.
12. Set No. 1 cylinder at TDC on its compression stroke. • Align pointer with TDC mark on crankshaft pulley.
13. Remove drive belt. Refer to EM-134, "Removal and Installation"
.
14. Remove the drive belt auto-tensioner assembly. Refer to EM-135, "Removal and Installation of Drive Belt
Auto-tensioner".
15. Remove water drain plug (A) and copper sealing washer (B) to drain coolant from engine.
CAUTION:
Do not reuse copper sealing washers.
16. Disconnect RH valve timing control connectors and remo ve valve timing control cover (bank 1). Refer to
EM-182, "Exploded View"
.
17. Remove water pump cover. Refer to CO-44, "Exploded View"
.
18. Remove the timing chain tensioner (primary) as follows:
a. Pull the lever (C) down to release the plunger stopper tab (B).
b. Insert the stopper pin A into the tensioner body hole to hold the lever (C) and keep the plunger stopper tab (B) released.
NOTE:
An allen wrench [(1.2 mm (0.047 in)] is used for a stopper pin A
as an example.
c. Compress the plunger (D) into the tensioner body (1) by press- ing the slack guide (2).
d. Keep the slack guide (2) pressed and lock the plunger (D) in by pushing the stopper pin A through the lever (C) and into the
chain tensioner body hole.
e. Remove timing chain tensioner bolts and then remove the timing chain tensioner. CAUTION:
Be careful not to drop timing chain te nsioner bolts inside timing chain case.
19. Remove the three water pump bolts (A). Make a gap between water pump sprocket (1) and timing chain, by carefully turning
crankshaft pulley (2) counterclockwise until timing chain loosens
on water pump sprocket (1).
: Front
AWBIA1202GB
AWBIA0903ZZ
AWBIA0904ZZ
Revision: November 20132014 Altima NAM
Page 426 of 4801
![NISSAN TEANA 2014 Service Manual
CO-46
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
20. Remove water pump:
a. Screw M8 bolts approximately 50 mm (1.97 in) into water pump upper and lower bolt holes until they reach the timing ch NISSAN TEANA 2014 Service Manual
CO-46
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
20. Remove water pump:
a. Screw M8 bolts approximately 50 mm (1.97 in) into water pump upper and lower bolt holes until they reach the timing ch](/manual-img/5/57390/w960_57390-425.png)
CO-46
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
20. Remove water pump:
a. Screw M8 bolts approximately 50 mm (1.97 in) into water pump upper and lower bolt holes until they reach the timing chain case
[M8 bolt pitch 1.25 mm (0.49 in) length].
CAUTION:
• Place a suitable shop cloth below the water pump hous-
ing to prevent any co olant from dripping into the timing
chain case.
• Pull water pump straight out while preventing vane from
contacting socket in installation area.
• Remove water pump without causing sprocket to contact
timing chain.
b. Remove M8 bolts and O-rings from water pump. CAUTION:
Do not reuse O-rings.
INSPECTION AFTER REMOVAL
• Visually check for significant dirt or rust on the water pump body and vane.
• Check that the vane shaft turns smoothly by hand and is not
excessively loose.
• Replace the water pump assembly if the water pump does not per- form properly.
INSTALLATION
1. Install new O-rings on water pump (1).
CAUTION:
Do not reuse O-rings.
a. Apply engine oil to the O-rings (2,3) as shown.
b. Locate the O-ring (2) with white paint mark (A) to engine front side.
2. Hold timing chain to the side ( ) and install the water pump ().
CAUTION:
Do not allow the O-rings to be damaged by the cylinder
block when installing the water pump.
• Check that timing chain and water pump sprocket are
engaged.
• Tighten water pump bolts alternately and evenly to specifica- tion.
3. Remove dust and foreign material completely from installation area of timing chain tensioner and rear tim- ing chain case.
JLC357B
SLC943A
AWBIA1290GB
SLC031B
Revision: November 20132014 Altima NAM
Page 427 of 4801
![NISSAN TEANA 2014 Service Manual
WATER PUMPCO-47
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
4. Turn the crankshaft pulley approximately 20
° clockwise so that
the timing chain on the timing chain tension NISSAN TEANA 2014 Service Manual
WATER PUMPCO-47
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
4. Turn the crankshaft pulley approximately 20
° clockwise so that
the timing chain on the timing chain tension](/manual-img/5/57390/w960_57390-426.png)
WATER PUMPCO-47
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
4. Turn the crankshaft pulley approximately 20
° clockwise so that
the timing chain on the timing chain tensioner side is loose.
5. Apply engine oil to the oil feed hole and timing chain tensioner and install the timing chain tensioner.
6. Remove the stopper pin (A).
7. Install valve timing control cover (bank 1) and water pump cover.
a. Before installing, remove all traces of liquid gasket from mating surface of water pump cover and IVT cover using a scraper.
Also remove traces of liquid gasket from the mating surface of the front cover.
b. Apply a continuous bead of liquid gasket to mating surface of IVT cover and water pump cover. Use Gen-
uine RTV Silicone Sealant or equivalent. Refer to GI-21, "Recommended Chemical Products and
Sealants".
CAUTION:
• Installation should be done within 5 minutes afte r applying liquid gasket.
• Do not fill the engine with oil for at least 30 minutes after the co mponents are installed to allow
the sealant to cure.
8. Install water drain plug (A) and copper sealing washer (B). CAUTION:
Do not reuse copper sealing washers.
9. Installation of remaining components is in the reverse order of removal. • After installation, refill coolant and check for leaks. Refer to CO-36, "Changing Engine Coolant"
and CO-
35, "System Inspection".
CAUTION:
Do not spill coolant in en gine compartment. Use a sh op cloth to absorb coolant.
• After starting engine, let idle for three minutes, then rev engine up to 3,000 rpm under no load to purge air from the high-pressure chamber of the chai n tensioner. The engine may produce a rattling noise.
This indicates that air still remains in the chamber and is not a matter of concern.
INSPECTION AFTER INSTALLATION
• Before starting engine, check oil/fluid levels incl uding engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-11, "FOR USA AND CANADA : Fluids and Lubricants"
.
PBIC0848E
AWBIA0905ZZ
: Front
Water drain plug (A) : Refer to EM-224, "Disas-
sembly and Assembly".
AWBIA1202GB
Revision: November 20132014 Altima NAM
Page 428 of 4801
![NISSAN TEANA 2014 Service Manual
CO-48
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, NISSAN TEANA 2014 Service Manual
CO-48
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping,](/manual-img/5/57390/w960_57390-427.png)
CO-48
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER PUMP
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak- age at connection points.
• Start engine. With engine speed increased, che ck again for fuel leakage at connection points.
• Run engine to check for unusual noise and vibration. NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal and installation, slack in the guide
may generate a pounding noise during and just after engine start. However, this is normal. Noise will stop
after hydraulic pressure rises.
• Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids including engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec-
ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc. Item Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Transmission/
transaxle fluid CVT Models Leakage Level/Leakage Leakage
Other oils and fluids* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gas — Leakage —
Revision: November 20132014 Altima NAM
Page 429 of 4801
![NISSAN TEANA 2014 Service Manual
THERMOSTAT AND THERMOSTAT HOUSINGCO-49
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
THERMOSTAT AND THERMOSTAT HOUSING
Exploded ViewINFOID:0000000009460422
WARNING:
Do not r NISSAN TEANA 2014 Service Manual
THERMOSTAT AND THERMOSTAT HOUSINGCO-49
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
THERMOSTAT AND THERMOSTAT HOUSING
Exploded ViewINFOID:0000000009460422
WARNING:
Do not r](/manual-img/5/57390/w960_57390-428.png)
THERMOSTAT AND THERMOSTAT HOUSINGCO-49
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
THERMOSTAT AND THERMOSTAT HOUSING
Exploded ViewINFOID:0000000009460422
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly push down and
turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down
and turning it all the way.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
Removal and InstallationINFOID:0000000009460423
REMOVAL
1. Drain engine coolant from the radiator. Refer to CO-36, "Changing Engine Coolant".
CAUTION:
Perform when engine is cool.
2. Remove the core support cover clips (A), then remove the core support cover (1).
3. Remove front air duct. Refer to EM-144, "Removal and Installation"
.
4. Disconnect radiator hose (lower).
5. Remove coolant reservoir hose.
6. Remove coolant reservoir tank. Refer to CO-41, "Removal and Installation"
.
7. Disconnect IVT control valve connector.
AWBIA1106GB
1. Gasket 2. Thermostat assembly
ALKIA2602ZZ
Revision: November 20132014 Altima NAM
Page 430 of 4801
![NISSAN TEANA 2014 Service Manual
CO-50
< REMOVAL AND INSTALLATION >[VQ35DE]
THERMOSTAT AND THERMOSTAT HOUSING
8. Remove engine coolant inlet, thermostat assembly and gasket.
•Do not disassemble engine cool ant inlet and thermostat NISSAN TEANA 2014 Service Manual
CO-50
< REMOVAL AND INSTALLATION >[VQ35DE]
THERMOSTAT AND THERMOSTAT HOUSING
8. Remove engine coolant inlet, thermostat assembly and gasket.
•Do not disassemble engine cool ant inlet and thermostat](/manual-img/5/57390/w960_57390-429.png)
CO-50
< REMOVAL AND INSTALLATION >[VQ35DE]
THERMOSTAT AND THERMOSTAT HOUSING
8. Remove engine coolant inlet, thermostat assembly and gasket.
•Do not disassemble engine cool ant inlet and thermostat.
Replace them as a unit, if necessary.
• Do not reuse gasket.
INSPECTION AFTER REMOVAL
• Place a thread so that it is caught in the valves of the thermostat.
Immerse fully in a container filled with water. Heat while stirring.
• The valve opening temperature is the temperature at which the
valve opens and the thermostat falls from the thread.
• Continue heating. Check the full-open lift amount. NOTE:
The full-open lift amount standard temperature for the thermostat is
the reference value.
• After checking the full-open lift amount, lower the water tempera-
ture and check the valve closing temperature.
• If valve setting at measured values are out of standard range, replace thermostat.
INSTALLATION
Installation is in the reverse order of removal.
• Install thermostat with jiggle valve facing upward.
• After installation refill engine coolant and check for leaks. Refer to
CO-36, "Changing Engine Coolant"
and CO-35, "System Inspec-
tion".
CAUTION:
• Do not spill coolant in engi ne compartment. Use a shop
cloth to absorb coolant.
• Do not reuse gasket.
SLC962AA
SLC949A
Thermostat Standard Values
Valve opening temperature Refer to CO-53, "Thermostat"
Full-open lift amount Refer to CO-53, "Thermostat"
Valve closing temperature Refer to CO-53, "Thermostat"
SLC948A
Revision: November 20132014 Altima NAM
Page 431 of 4801
![NISSAN TEANA 2014 Service Manual
WATER OUTLET AND WATER PIPINGCO-51
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
WATER OUTLET AND WATER PIPING
Exploded ViewINFOID:0000000009460424
WARNING:
Do not remove th NISSAN TEANA 2014 Service Manual
WATER OUTLET AND WATER PIPINGCO-51
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
WATER OUTLET AND WATER PIPING
Exploded ViewINFOID:0000000009460424
WARNING:
Do not remove th](/manual-img/5/57390/w960_57390-430.png)
WATER OUTLET AND WATER PIPINGCO-51
< REMOVAL AND INSTALLATION > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
CO
NP
O
WATER OUTLET AND WATER PIPING
Exploded ViewINFOID:0000000009460424
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly push down and
turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down
and turning it all the way.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
Removal and InstallationINFOID:0000000009460425
REMOVAL
1. Remove engine room cover. Refer to EM-28, "Removal and Installation".
CAUTION:
Perform when the engine is cold.
1. Heater hose 2. Clamp 3. Water hose
4. Clamp 5. Water outlet 6. Gasket
7. Gasket 8. Water connector 9. O-ring
10. Water bypass pipe 11. Clamp 12. Water hose
13. Heater pipe 14. Water hose 15. Heater hose
16. Engine coolant temperature sensor 17. Clamp 18. Radiator hose (upper)
A. To heater core B. To electric throttle control actuator C. To oil cooler
D. To radiator
AWBIA1107GB
Revision: November 20132014 Altima NAM
Page 432 of 4801
![NISSAN TEANA 2014 Service Manual
CO-52
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER OUTLET AND WATER PIPING
2. Partially drain engine coolant from radiator. Refer to
CO-36, "Changing Engine Coolant".
3. Remove the core support cover NISSAN TEANA 2014 Service Manual
CO-52
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER OUTLET AND WATER PIPING
2. Partially drain engine coolant from radiator. Refer to
CO-36, "Changing Engine Coolant".
3. Remove the core support cover](/manual-img/5/57390/w960_57390-431.png)
CO-52
< REMOVAL AND INSTALLATION >[VQ35DE]
WATER OUTLET AND WATER PIPING
2. Partially drain engine coolant from radiator. Refer to
CO-36, "Changing Engine Coolant".
3. Remove the core support cover clips (A), then remove the core support cover (1).
4. Remove front air duct. Refer to EM-84, "Removal and Installation"
.
5. Remove air duct and air cleaner case assembly. Refer to EM-144, "Removal and Installation"
.
6. Remove engine side under cover (RH). Refer to EXT-28, "Removal and Installation"
.
7. Disconnect hoses from electric throttle control actuator.
8. Remove radiator upper hose and heater hoses.
9. Remove connector(s) from heater pipe.
10. Disconnect engine coolant temperature sens or electrical connector on water outlet.
11. Remove water outlet, heater pipe, water connector, and water bypass pipe nuts and bolts.
12. Remove engine coolant temperature sensor, if necessary.
INSTALLATION
Installation is in the reverse order of removal.
• Securely insert each hose, and install a clamp at a pos ition where it does not interfere with the pipe bulge.
• When inserting heater pipe and water bypass pipe into water connector, apply mild soap to new O-rings.
CAUTION:
Do not reuse O-ring.
• After installation refill engine coolant and check for leaks. Refer to CO-36, "Changing Engine Coolant"
and
CO-35, "System Inspection"
.
ALKIA2602ZZ
Revision: November 20132014 Altima NAM
