PCS-60
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2614 ACC RELAY CIRCUIT
B2614 ACC RELAY CIRCUIT
DTC LogicINFOID:0000000009461638
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. PERFORM SELF DIAGNOSTIC RESULT
1. Turn the power supply position to ACC under the following conditions, and wait for at least 1 second.
- CVT selector lever is in the P (park) or N (neutral) position.
- Release the brake pedal.
2. Perform self diagnostic result.
Is DTC B2614 detected?
YES >> Refer to PCS-60, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009461639
Regarding Wiring Diagram information, refer to PCS-44, "Wiring Diagram".
1. CHECK ACCESSORY RELAY-1 AND ACCESSORY RELAY-2 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect accessory relay-1 and accessory relay-2.
3. Disconnect BCM connector M20.
4. Check continuity between accessory relay-1 c onnector J-3 terminal 2 and BCM connector M20 terminal
113.
5. Check continuity between accessory relay-2 connector M25 terminal 1 and BCM connector M20 terminal 113.
6. Check continuity between BCM connector M20 terminal 113 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connectors.
CONSULT Display DTC detectin g condition Possible cause
ACC RELAY CIRCUIT
[B2614] An immediate operation of accessory relay-1 and ac-
cessory relay-2 is requested by BCM, but there is no
response for more than 1 second. • Harness or connectors
• Accessory relay-1
• Accessory relay-2
• Fuse block J/B
•BCM
Accessory relay-1 BCM Continuity
Connector Terminal Connector Terminal
J-3 2 M20 113 Yes
Accessory relay-2 BCM Continuity
Connector Terminal Connector Terminal
M251M20113Yes
BCM Ground Continuity
Connector Terminal
M20 113 — No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3410 of 4801
![NISSAN TEANA 2014 Service Manual
PCS
B2614 ACC RELAY CIRCUITPCS-61
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
2. CHECK ACCESSORY RELAY-1 AND
ACCESSORY RELAY-2 GROUND CIRCUIT
1. Turn igniti NISSAN TEANA 2014 Service Manual
PCS
B2614 ACC RELAY CIRCUITPCS-61
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
2. CHECK ACCESSORY RELAY-1 AND
ACCESSORY RELAY-2 GROUND CIRCUIT
1. Turn igniti](/manual-img/5/57390/w960_57390-3409.png)
PCS
B2614 ACC RELAY CIRCUITPCS-61
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
2. CHECK ACCESSORY RELAY-1 AND
ACCESSORY RELAY-2 GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between accessory relay-1 connector J-3 terminal 1 and ground.
3. Check continuity between accessory relay-2 connector M25 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK ACCESSORY RELAYS
Perform the relay component inspection. Refer to PCS-61, "Component Inspection (Relay)"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace relay.
4. CHECK ACCESSORY RELAY-1 AND ACCE SSORY RELAY-2 POWER SUPPLY (BCM)
Check voltage between BCM connector M20 terminal 113 and ground.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
Component Inspection (Relay)INFOID:0000000009461640
1. CHECK RELAY
1. Remove relay.
2. Check the continuity between relay terminals under the following conditions.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace relay.
Accessory relay-1 Ground Continuity
Connector Terminal
J-3 1 — Yes
Accessory relay-2 Ground Continuity
Connector Terminal
M25 2 — Yes
BCM Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
M20 113 — Ignition: OFF 0V
Ignition: ACC Battery voltage
Relay terminals Condition Continuity
3 and 5 Battery voltage applied to terminal 1 and
ground to terminal 2. Ye s
Voltage and ground removed. No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3411 of 4801
![NISSAN TEANA 2014 Service Manual
PCS-62
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2615 BLOWER RELAY CIRCUIT
B2615 BLOWER RELAY CIRCUIT
DTC LogicINFOID:0000000009461641
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. P NISSAN TEANA 2014 Service Manual
PCS-62
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2615 BLOWER RELAY CIRCUIT
B2615 BLOWER RELAY CIRCUIT
DTC LogicINFOID:0000000009461641
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. P](/manual-img/5/57390/w960_57390-3410.png)
PCS-62
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2615 BLOWER RELAY CIRCUIT
B2615 BLOWER RELAY CIRCUIT
DTC LogicINFOID:0000000009461641
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. PERFORM SELF DIAGNOSTIC RESULT
1. Turn ignition switch ON under the following conditions, and wait for at least 1 second.
- CVT selector lever is in the P (park) or N (neutral) position.
- Release brake pedal.
2. Perform self diagnostic result.
Is DTC B2615 detected?
YES >> Refer to PCS-62, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009461642
Regarding Wiring Diagram information, refer to PCS-44, "Wiring Diagram".
1. CHECK FRONT BLOWER MOTOR RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front blower motor relay.
3. Disconnect BCM connector M19.
4. Check continuity between front blower motor relay connector J-4 terminal 2 and BCM connector M18 ter- minal 66.
5. Check continuity between front blower motor relay connector J-4 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connectors.
2. CHECK FRONT BLOWER MOTOR RELAY GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between front blower motor relay connector J-4 terminal 1 and ground.
CONSULT Display DTC Detectio n Condition Possible Cause
BLOWER RELAY CIRCUIT
[B2615] An immediate operation of front blower motor relay
is requested by BCM, but there is no response for
more than 1 second. • Harness or connectors.
• Front blower motor relay.
• Fuse block J/B.
•BCM.
Front blower motor relay BCM Continuity
Connector Terminal Connector Terminal
J-4 2 M18 66 Yes
Front blower motor relay Ground Continuity
Connector Terminal
J-4 2 — No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3412 of 4801
![NISSAN TEANA 2014 Service Manual
PCS
B2615 BLOWER RELAY CIRCUITPCS-63
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace ha NISSAN TEANA 2014 Service Manual
PCS
B2615 BLOWER RELAY CIRCUITPCS-63
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace ha](/manual-img/5/57390/w960_57390-3411.png)
PCS
B2615 BLOWER RELAY CIRCUITPCS-63
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK FRONT BLOWER MOTOR RELAY
Perform the relay component inspection. Refer to PCS-63, "Component Inspection (Relay)"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front blower motor relay.
4. CHECK FRONT BLOWER MOTOR RELAY POWER SUPPLY (BCM)
Check voltage between BCM connector M19 terminal 66 and ground.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
Component Inspection (Relay)INFOID:0000000009461643
1. CHECK RELAY
1. Remove relay.
2. Check the continuity between relay terminals under the following conditions.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace relay.
Front blower motor relay Ground Continuity
Connector Terminal
J-4 1 — Yes
BCM Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
M19 66 — Ignition: OFF 0V
Ignition: ON Battery voltage
Relay terminals Condition Continuity
3 and 5 Battery voltage applied to terminal 1 and
ground to terminal 2. Ye s
Voltage and ground removed. No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3413 of 4801
![NISSAN TEANA 2014 Service Manual
PCS-64
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2616 IGNITION RELAY CIRCUIT
B2616 IGNITION RELAY CIRCUIT
DTC LogicINFOID:0000000009461644
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NISSAN TEANA 2014 Service Manual
PCS-64
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2616 IGNITION RELAY CIRCUIT
B2616 IGNITION RELAY CIRCUIT
DTC LogicINFOID:0000000009461644
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE](/manual-img/5/57390/w960_57390-3412.png)
PCS-64
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2616 IGNITION RELAY CIRCUIT
B2616 IGNITION RELAY CIRCUIT
DTC LogicINFOID:0000000009461644
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1. PERFORM SELF DIAGNOSTIC RESULT
1. Turn ignition switch ON under the following conditions, and wait for at least 1 second.
- CVT selector lever is in the P (park) or N (neutral) position.
- Release brake pedal
2. Perform self diagnostic result.
Is DTC B2616 detected?
YES >> Refer to PCS-64, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009461645
Regarding Wiring Diagram information, refer to PCS-44, "Wiring Diagram".
1. CHECK IGNITION RELAY-2 POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector M19.
3. Check continuity between igniti on relay-2 connector J-1 terminal 1 and BCM connector M18 terminal 67.
4. Check continuity between ignition re lay-2 connector J-1 terminal 1 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connectors.
2. CHECK IGNITION RELAY-2 GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between ignition re lay-2 connector J-1 terminal 2 and ground.
Is the inspection result normal?
CONSULT Display DTC Detectio n Condition Possible Cause
IGNITION RELAY CIRCUIT
[B2616] An immediate operation of ignition relay-2 is re-
quested by BCM, but there is no response for more
than 1 second. • Harness or connectors.
• Ignition relay-2.
• Fuse block J/B.
•BCM.
Ignition relay-2 BCM Continuity
Connector Terminal Connector Terminal
J-1 1 M18 67 Yes
Ignition relay-2 Ground Continuity
Connector Terminal
J-1 1 — No
Ignition relay-2 Ground Continuity
Connector Terminal
J-1 2 — Yes
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3414 of 4801
![NISSAN TEANA 2014 Service Manual
PCS
B2616 IGNITION RELAY CIRCUITPCS-65
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK I NISSAN TEANA 2014 Service Manual
PCS
B2616 IGNITION RELAY CIRCUITPCS-65
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK I](/manual-img/5/57390/w960_57390-3413.png)
PCS
B2616 IGNITION RELAY CIRCUITPCS-65
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. CHECK IGNITION RELAY-2
Perform the relay component inspection. Refer to PCS-65, "Component Inspection (Relay)"
.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace ignition relay-2.
4. CHECK IGNITION RELAY-2 POWER SUPPLY (BCM)
Check voltage between BCM connector M18 terminal 67 and ground.
Is the inspection result normal?
YES >> Refer to GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
Component Inspection (Relay)INFOID:0000000009461646
1. CHECK RELAY
1. Remove relay.
2. Check the continuity between relay terminals under the following conditions.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace relay.
BCM Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
M18 67 — Ignition: OFF 0V
Ignition: ON Battery voltage
Relay terminals Condition Continuity
3 and 5 Battery voltage applied to terminal 1 and
ground to terminal 2. Ye s
Voltage and ground removed. No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3415 of 4801
![NISSAN TEANA 2014 Service Manual
PCS-66
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2618 BCM
B2618 BCM
DTC LogicINFOID:0000000009461647
DTC DETECTION LOGIC
NOTE:
• If DTC B2618 is displayed with DTC U1000, first perform NISSAN TEANA 2014 Service Manual
PCS-66
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2618 BCM
B2618 BCM
DTC LogicINFOID:0000000009461647
DTC DETECTION LOGIC
NOTE:
• If DTC B2618 is displayed with DTC U1000, first perform](/manual-img/5/57390/w960_57390-3414.png)
PCS-66
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B2618 BCM
B2618 BCM
DTC LogicINFOID:0000000009461647
DTC DETECTION LOGIC
NOTE:
• If DTC B2618 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
PCS-56, "DTC Logic"
.
• If DTC B2618 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to PCS-57, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1. PERFORM SELF DIAGNOSTIC RESULT
1. Turn ignition switch ON under the following conditions, and wait for at least 1 second.
- CVT selector lever is in the P (park) or N (neutral) position.
- Release brake pedal
2. Perform self diagnostic result.
Is DTC B2618 detected?
YES >> Refer to PCS-66, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009461648
Regarding Wiring Diagram information, refer to PCS-44, "Wiring Diagram".
1. CHECK SELF DIAGNOSTIC RESULT FOR IPDM E/R
Perform self diagnostic result for IPDM E/R.
Are any DTCs detected?
YES >> Refer to PCS-20, "DTC Index".
NO >> GO TO 2
2. CHECK IGNITION RELAY-1 POWER SUPPLY (IPDM E/R)
Check voltage between IPDM E/R connector E63 terminal 43 and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-32, "Removal and Installation".
NO >> GO TO 3.
3. CHECK IGNITION RELAY-1 POWER SUPPLY (BCM)
Check voltage between BCM connector M18 terminal 70 and ground.
CONSULT Display DTC Detectio n Condition Possible Cause
BCM
[B2618] An immediate operation of ignition relay-1 is request-
ed by BCM, but there is no response for more than 1
second •BCM
IPDM E/R
Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
E63 43 — Ignition: OFF 0V
Ignition: ON Battery voltage
BCM Ground Condition Vo l ta g e
(Approx.)
Connector Terminal
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3416 of 4801
PCS
B2618 BCMPCS-67
< DTC/CIRCUIT DIAGNOSIS > [POWER DISTRIBUTION SYSTEM]
C
D E
F
G H
I
J
K L
B
A
O P
N
Is the inspection result normal?
YES >> Refer to
GI-43, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-80, "Removal and Installation"
.
M18 70 — Ignition: OFF 0V
Ignition: ON Battery voltage
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
