Page 985 of 4801

KEY CYLINDERDLK-217
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY CYLINDER
GLOVE BOX LID KEY CYLINDER
GLOVE BOX LID KEY CYLINDER : Removal and InstallationINFOID:0000000009461965
REMOVAL
1. Remove glove box assembly (2) to access glove box lid key cyl-
inder (1). Refer to IP-22, "Removal and Installation"
.
2. Insert key (1) into glove box lid lock cylinder (2).
3. Pull upward on glove box lid release handle (3).
4. Rotate key (1) and turn glove box lid key cylinder (2) to the lock position.
5. Press tumbler stopper (1) into glove box lid lock cylinder (2) using a suitable tool (A), and then remove key (3) and glove box
lid lock cylinder together from glove box lid release handle (4).
NOTE:
When removing glove box lid lock cylinder (2) note the position
of cylinder to glove box lid release handle (4).
6. Remove sleeve (3) from glove box lid release handle and then install sleeve to glove box lid lock cylinder.
NOTE:
When removing sleeve note the position of sleeve to glove box
lid release handle.
CAUTION:
Do not pull out key (1) from glove box lid lock cylinder (2)
while sleeve (3) is removed. Othe rwise, tumblers (4) may be
lost from glove box lid lock cylinder.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, check glove box assem bly open/close, lock/unlock operation.
ALKIA2719ZZ
JMKIA5490ZZ
JMKIA5491ZZ
JMKIA5819ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 986 of 4801
DLK-218
< REMOVAL AND INSTALLATION >
KEY CYLINDER
SEATBACK LOCK KEY CYLINDER
SEATBACK LOCK KEY CYLINDER : Removal and InstallationINFOID:0000000009461966
REMOVAL
1. Remove rear parcel shelf finisher. Refer to INT-26, "Removal and Installation".
2. Remove bolts (A) and the setback lock key cylinder (1).
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
After installation, rear seatback assembl y open/close, lock/unlock operation.
ALKIA2738ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 987 of 4801
DOOR SWITCHDLK-219
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR SWITCH
Removal and InstallationINFOID:0000000009461967
REMOVAL
1. Remove the door switch bolt (A).
2. Disconnect the harness connector from the door switch (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2509ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 988 of 4801
DLK-220
< REMOVAL AND INSTALLATION >
INSIDE KEY ANTENNA
INSIDE KEY ANTENNA
CONSOLE
CONSOLE : Removal and InstallationINFOID:0000000009461968
REMOVAL
1. Remove the center console rear finisher (1). Refer to IP-18,
"Removal and Installation".
2. Remove the inside key antenna (console) screws (A) and inside key antenna (console) (2).
INSTALLATION
Installation is in the reverse order of removal.
LUGGAGE ROOM
LUGGAGE ROOM : Removal and InstallationINFOID:0000000009461969
REMOVAL
1. Disconnect the harness connector (A) from the inside keyantenna (luggage room) (1).
2. Remove the inside key antenna (luggage room) clips (B), and then remove inside key antenna (luggage room) (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2720ZZ
ALKIA2721ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 989 of 4801

OUTSIDE KEY ANTENNADLK-221
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
OUTSIDE KEY ANTENNA
DRIVER SIDE
DRIVER SIDE : Removal and InstallationINFOID:0000000009461970
REMOVAL
The driver side outside key antenna and driver side outside handle are serviced as an assembly. Refer to
DLK-198, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"
.
INSTALLATION
Installation is in the reverse order of removal.
PASSENGER SIDE
PASSENGER SIDE : Removal and InstallationINFOID:0000000009461971
REMOVAL
The passenger side outside key antenna and passenger side outside handle are serviced as an assembly.
Refer to DLK-198, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"
.
INSTALLATION
Installation is in the reverse order of removal.
REAR BUMPER
REAR BUMPER : Remo val and InstallationINFOID:0000000009461972
REMOVAL
1. Remove rear bumper fascia. Refer to EXT-21, "Removal and Installation".
2. Disconnect the harness connector (B) from the rear bumper key
antenna (1).
3. Remove the nuts (A) that retain the rear bumper key antenna (1) to the body.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2723ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 990 of 4801
DLK-222
< REMOVAL AND INSTALLATION >
DOOR REQUEST SWITCH
DOOR REQUEST SWITCH
DRIVER SIDE
DRIVER SIDE : Removal and InstallationINFOID:0000000009461973
REMOVAL
The driver side door request switch and driver side outside handle are serviced as an assembly. Refer to DLK-
198, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle".
INSTALLATION
Installation is in the reverse order of removal.
PASSENGER SIDE
PASSENGER SIDE : Removal and InstallationINFOID:0000000009461974
REMOVAL
The passenger side door request switch and passenger side outside handle are serviced as an assembly.
Refer to DLK-198, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"
.
INSTALLATION
Installation is in the reverse order of removal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 991 of 4801
INTELLIGENT KEY WARNING BUZZERDLK-223
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY WARNING BUZZER
Removal and InstallationINFOID:0000000009461975
REMOVAL
NOTE:
The Intelligent Key warning buzzer is located in the left front area of the engine compartment.
1. Remove the Intelligent Key warning buzzer harness clip.
2. Remove the nut (B) that retains the Intelligent Key warning buzzer (1) to the body.
3. Disconnect the harness connector (A) from the Intelligent Key warning buzzer (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2728ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 992 of 4801
DLK-224
< REMOVAL AND INSTALLATION >
REMOTE KEYLESS ENTRY RECEIVER
REMOTE KEYLESS ENTRY RECEIVER
Removal and InstallationINFOID:0000000009461976
REMOVAL
1. Remove glove box assembly. Refer to IP-22, "Removal and Installation".
2. Disconnect the harness connector (A) from the remote keyless entry receiver (1).
3. Remove the screw (B) and remote keyless entry receiver (1).
INSTALLATION
Installation is in the reverse order or removal.
ALKIA2725ZZ
