Page 3713 of 4801
RF-48
< REMOVAL AND INSTALLATION >
SUNSHADE
SUNSHADE
Removal and InstallationINFOID:0000000009461329
REMOVAL
1. Remove moonroof unit assembly. Refer to RF-46, "Removal and Installation".
2. Remove the sunshade stoppers (1) (LH/RH) from the moonroof unit assembly side rails (2).
: Front
3. Remove sunshade from rear end of moonroof unit assembly.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2347E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3714 of 4801
WIND DEFLECTORRF-49
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
WIND DEFLECTOR
Removal and InstallationINFOID:0000000009461330
REMOVAL
1. Open the glass lid.
2. Remove the wind deflector.
a. Remove the wind deflector screws (one from each side).
b. Remove the wind deflector from the moonroof unit assembly.
INSTALLATION
Installation is in the reverse order of removal.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3715 of 4801
RF-50
< REMOVAL AND INSTALLATION >
MOONROOF SWITCH
MOONROOF SWITCH
Removal and InstallationINFOID:0000000009461331
REMOVAL
1. Remove front room/map lamp assembly. Refer to INL-63, "Removal and Installation".
2. Disconnect the harness connector (A) from front the room/map
lamp assembly.
3. Remove the screws (B) from front room/map lamp assembly,
using a suitable tool and remove map lamp bar (1).
4. Release the pawls and remove the moonroof switch finisher (1).
5. Release the pawls and remove the moonroof switch (2) from the front room/map lamp assembly.
: Pawl
INSTALLATION
Installation is in the reverse order of removal.
ALKIA2753ZZ
ALKIA2754ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3716 of 4801
MOONROOF UNIT ASSEMBLYRF-51
< UNIT DISASSEMBLY AND ASSEMBLY >
C
D E
F
G H
I
J
L
M A
B
RF
N
O P
UNIT DISASSEMBLY AND ASSEMBLY
MOONROOF UNIT ASSEMBLY
Exploded ViewINFOID:0000000009461332
Disassembly and AssemblyINFOID:0000000009461333
DISASSEMBLY
1. Remove the moonroof unit assembly. Refer to RF-46, "Removal and Installation".
2. Remove the sunshade stoppers (LH/RH) from the moonroof unit assembly side rails.
3. Remove sunshade from the rear end of moonroof unit assembly.
4. Remove glass lid bolts on each side.
5. Remove glass lid from moonroof unit assembly.
6. Remove the wind deflector screws (one from each side).
1. Glass lid 2. Weatherstrip 3. Sunshade
4. Moonroof motor assembly 5. Wind deflector 6. Moonroof side bracket front
7. Moonroof side bracket rear 8. Drain hose connector 9. Sunshade stoppers
7. Moonroof side bracket rear Front
AWKIA2042ZZ
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3717 of 4801
RF-52
< UNIT DISASSEMBLY AND ASSEMBLY >
MOONROOF UNIT ASSEMBLY
7. Remove the wind deflector from the moonroof unit assembly.
8. Remove moonroof motor assembly screws.
9. Remove moonroof motor assembly from moonroof unit assembly front end rail.
ASSEMBLY
Assemble in the reverse order of disassembly.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 3718 of 4801

RSU-1
SUSPENSION
C
D
F
G H
I
J
K L
M
SECTION RSU
A
B
RSU
N
O PCONTENTS
REAR SUSPENSION
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
General Precautions .................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Commercial Service Tool .................................... ......3
SYMPTOM DIAGNOSIS ...............................4
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ .....
4
NVH Troubleshooting Chart ................................ ......4
PERIODIC MAINTENANCE ..........................5
REAR SUSPENSION ASSEMBLY ................ .....5
On-vehicle Service .............................................. ......5
Inspection ..................................................................5
Inspection and Adjustment ........................................5
UNIT REMOVAL AND INSTALLATION .......8
REAR SUSPENSION ASSEMBLY ................ .....8
Exploded View .................................................... ......8
Removal and Installation ..................................... .....8
REMOVAL AND INSTALLATION ...............12
REAR LOWER LINK & COIL SPRING .............12
Removal and Installation ..................................... ....12
SHOCK ABSORBER ........................................13
Exploded View .........................................................13
Removal and Installation .........................................13
Disassembly and Assembly .....................................14
Disposal ...................................................................14
REAR STABILIZER ..........................................15
Exploded View .........................................................15
Removal and Installation .........................................15
SUSPENSION ARM ..........................................16
Exploded View .........................................................16
Removal and Installation .........................................16
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .............................................
17
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
17
General Specification (Rear) ............................... ....17
Wheel Alignment (Unladen*) ...................................17
Wheelarch Height (Unladen*1) ................................17
Revision: November 20132014 Altima NAM
Page 3719 of 4801

RSU-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000009951707
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
General PrecautionsINFOID:0000000009464451
• When installing rubber bushings, the final tightening mu st be carried out under unladen conditions with tires
on ground. Oil might shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
- Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
• After servicing suspension parts, be sure to check wheel alignment.
• Self-lock nuts are not reusable. Always use new ones when installing. Since new self-lock nuts are pre-oiled,
tighten as they are.
Revision: November 20132014 Altima NAM
Page 3720 of 4801
PREPARATIONRSU-3
< PREPARATION >
C
D
F
G H
I
J
K L
M A
B
RSU
N
O P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000009464453
Tool name Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
