2014 NISSAN TEANA Service Manual

spark plugs roof automatic transmission fluid immobilizer air condition differential

Load previous 8 pages

Page 233 of 4801

NISSAN TEANA 2014 Service Manual
C1142 PRESS SENSORBRC-87
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1142 PRESS SENSOR
DTC LogicINFOID:0000000009463794
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDUR

Page 234 of 4801

NISSAN TEANA 2014 Service Manual
BRC-88
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1143 STEERING ANGLE SENSOR
C1143 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009463796
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIA

Page 235 of 4801

NISSAN TEANA 2014 Service Manual
C1143 STEERING ANGLE SENSORBRC-89
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
NO >> GO TO 4.
4.CHECK STEERING ANGLE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch

Page 236 of 4801

NISSAN TEANA 2014 Service Manual
BRC-90
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1144 INCOMPLETE STEERING
ANGLE SENSOR ADJUSTMENT
C1144 INCOMPLETE STEERING ANGLE SENSOR ADJUSTMENT
DTC LogicINFOID:0000000009463798
DTC DETECTION LOGIC

Page 237 of 4801

NISSAN TEANA 2014 Service Manual
C1154 PNP SWITCHBRC-91
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1154 PNP SWITCH
DescriptionINFOID:0000000009463800
The transmission range switch signal is transmit

C1154 PNP SWITCHBRC-91
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1154 PNP SWITCH
DescriptionINFOID:0000000009463800
The transmission range switch signal is transmitted to t he ABS actuator and electric unit (control unit) using
the CAN communication lines.
DTC LogicINFOID:0000000009463801
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF DIAGNOSTIC RESULT
With CONSULT.
1. Turn the ignition switch OFF to ON.
2. Perform self diagnostic result.
Is DTC C1154 detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-91, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000009463802
1.CHECK DATA MONITOR
Select “SLCT LVR POSI” in “Data Monitor” and check transmission range switch signal.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> GO TO 2
2.CHECK TRANSMISSION RANGE SWITCH
Perform transmission range switch inspection. Refer to TM-180, "Inspection"
(RE0F10D) or TM-379, "Inspec-
tion" (RE0F10E).
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-128, "Removal and Installa-
tion".
NO >> Repair or replace malfunctioning components.
Special Repair RequirementINFOID:0000000009463803
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-58, "Work Procedure"
.
DTC Display Condition Possible Cause
C1154 PNP POS SIG Transmission range switch signal or communication line
between the ABS actuator and el ectric unit (control unit)
and TCM is open or shorted. • Harness or connector
• Transmission range switch
Selector lever position SLCT LVR POSI (Data monitor)
P position P
R position R
N position N
D position D
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 238 of 4801

NISSAN TEANA 2014 Service Manual
BRC-92
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1154 PNP SWITCH
>> END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 239 of 4801

NISSAN TEANA 2014 Service Manual
C1155 BR FLUID LEVEL LOWBRC-93
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
N
O P
C1155 BR FLUID LEVEL LOW
DTC LogicINFOID:0000000009463804
DTC DETECTION LOGIC
DTC CONFIRMAT

Page 240 of 4801

NISSAN TEANA 2014 Service Manual
BRC-94
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1155 BR FLUID LEVEL LOW
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning components.
4.CHECK BRAKE FLUID LEVEL S
