REAR VIEW CAMERA CALIBRATION
REAR VIEW CAMERA CALIBRATION
DescriptionINFOID:0000000009464906
Always perform the calibration after removing and installing or replacin

Page 690 of 4801

NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA CALIBRATIONDAS-257
< BASIC INSPECTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
>> Refer to DAS-257, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:00000

DAS
REAR VIEW CAMERA CALIBRATIONDAS-257
< BASIC INSPECTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
>> Refer to DAS-257, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000009464908
CAUTION:
• Perform this operation in a horizontal position wh ere there is a clear view for 3 m (9.84 ft) backward
and 4 m (13.12 ft) wide.
• Place the target in a well-lig hted location. (Poor lighting may make it hard to adjust.)
• The target may not be detected when it shines by the reflected light of the sun or lighting.
• The target may not be detected when there is the same pattern of black and white as the target when
the pattern is within 0.5 m (1.64 ft) from either si de and upward/downward position from the target. (It
is desirable that the vehicle is pos itioned on a single-color floor.)
1.TARGET SETTING
1. Mark points “A”, “B”, “C” and “D” at the center of the lateral sur- face of each wheel.
NOTE:
Hang a string with a cone from the fender so as to pass through
the center of wheel, and then mark a point at the center of the
lateral surface of the wheel.
2. Draw line “LH” passing through points “A” and “B” on the left side of vehicle.
NOTE:
Approximately 2.2 m (7.22 ft) or more at the rear from the rear
axle.
3. Mark point “E” on the line “LH” at the positions 2125 mm (83.66
in) from point “B”.
4. Draw line “RH” passing through points “C” and “D” on the right side of vehicle in the same way as step 2.
5. Mark point “F” on the line “RH” at the positions 2125 mm (83.66 in) from point “D”.
6. Draw line “RW” passing through the points “E” and “F” on the rear of the vehicle. NOTE:
Approximately 1.8 m (5.91 ft) or more at bot h left and right sides from vehicle center.
7. Mark point “C
t” at the center of point “E” and “F” on the line “RW”.
CAUTION:
Make sure that “E” to “C
t” is equal to “F” to “Ct”.
8. Mark point "Lt" and "Rt" on the line "RW" at t he positions 1500 mm (59.06 in) from point "Ct".
9. Position the center of the ta rget mark to point of “Ct”.
Side distance (S
d): “B” – “E” (“D” – “F”)
: 2125 mm (83.66 in)
Left distance (L
d): “Ct” – “Lt” : 1500 mm (59.06 in)
Right distance (R
d): “Ct” – “Rt” : 1500 mm (59.06 in)
ALOIA0187GB
PKIB7667E
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 691 of 4801

NISSAN TEANA 2014 Service Manual
DAS-258
< BASIC INSPECTION >[MOD]
REAR VIEW CAMERA CALIBRATION
CAUTION:
Make sure that the black/white pattern of the center target is rotated as compared with the left and
right targets.
>> Go to

Page 692 of 4801

NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA CALIBRATIONDAS-259
< BASIC INSPECTION > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
NOTE:
Replace camera unit if “00H Routine not activated” or “10H Writing error” are repeat

Page 693 of 4801

NISSAN TEANA 2014 Service Manual
DAS-260
< DTC/CIRCUIT DIAGNOSIS >[MOD]
C1A03 VEHICLE SPEED SENSOR
DTC/CIRCUIT DIAGNOSIS
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000009464910
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.P

Page 694 of 4801

NISSAN TEANA 2014 Service Manual
DAS
C1A04 ABS/TCS/VDC SYSTEMDAS-261
< DTC/CIRCUIT DIAGNOSIS > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000009464912
DTC DETECTION LOGIC
DTC CONFIRMATION PRO

Page 695 of 4801

NISSAN TEANA 2014 Service Manual
DAS-262
< DTC/CIRCUIT DIAGNOSIS >[MOD]
C1A39 STEERING ANGLE SENSOR
C1A39 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000009464914
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMAT

Page 696 of 4801

NISSAN TEANA 2014 Service Manual
DAS
U0122 VDC P-RUN DIAGDAS-263
< DTC/CIRCUIT DIAGNOSIS > [MOD]
C
D E
F
G H
I
J
K L
M B
N P
A
U0122 VDC P-RUN DIAG
DTC LogicINFOID:0000000009464916
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1
