< ECU DIAGNOSIS INFORMATION >[CVT: RE0F10D]
TCM
G SPEEDVehicle stopped 0.00 G
During acceleration The value changes to the positive side
along with acceleration.
During deceleration The valu

TM-50
< ECU DIAGNOSIS INFORMATION >[CVT: RE0F10D]
TCM
G SPEEDVehicle stopped 0.00 G
During acceleration The value changes to the positive side
along with acceleration.
During deceleration The value changes to the positive side
along with deceleration.
ACCEL POSI SEN 1 Accelerator pedal released 0.00 deg
Accelerator pedal fully depressed 80.00 deg
VENG TRQ While driving The value changes along with acceleration/
deceleration.
PRI TRQ While driving The value changes along with acceleration/
deceleration.
TRQ RTO While driving The value changes along with acceleration/
deceleration.
SEC PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
PRI PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0.40 – 0.45 MPa
FLUID TEMP Ignition switch ON. Displays the CVT fluid temperature.
DSR REV While driving It varies along with the driving condition.
TGT PLLY GR RATIO In driving (forward) 2.70
− 0.38
In driving (reverse) 2.70
LU PRS • Engine started
• Vehicle is stopped. −
0.500 MPa
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.450 MPa
LINE PRS • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
TRGT PRI PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0.40 – 0.45 MPa
TRGT SELECT PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 0 MPa
• Selector lever: “D” position
•At idle 0.3 – 0.5 MPa
TRGT SEC PRESSURE • After engine warm up
• Selector lever: “N” position
•At idle 1.1 MPa
ISOLT1 • Engine started
• Vehicle is stopped. 0.000 A
• Selector lever: “D” position
• Accelerator pedal position: 1/8 or less
• Vehicle speed: 20 km/h (12 MPH) or more 0.500 A
ISOLT2 • After engine warm up
• Selector lever: “N” position
•At idle 0.800 – 0.850 A
Monitor item Condition Value/Status (Approx.)
