< SERVICE DATA AND SPECIFICATIONS (SDS) 2014
QUICK REFERENCE CHART: ALTIMA
QUICK REFERENCE CHART: ALTIMA
Engine Tune-up Data: QR25DEINFOID:0000000010112422
GENERAL SPECIFICATIONS
DRIVE BELTS
SPARK PLUG
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Engine Tune-up Data: VQ35DEINFOID:0000000010112419
GENERAL SPECIFICATIONS
Cylinder arrangement
In-line 4
Displacement cm
3 (in3) 2,488 (151.82)
Bore and stroke mm (in) 89.0 x 100 (3.50 x 3.94)
Valve arrangement DOHC
Firing order 1-3-4-2
Number of piston rings Compression
2
Oil 1
Compression ratio 10.0:1
Compression pressure
kPa (kg/cm
2, psi) / 250 rpm Standard 1410 (14.4, 204.5)
Minimum
1220 (12.4, 176.9)
Differential limit between cylinders 100 (1.0, 14)
Tension of drive belts Auto adjustment by drive belt auto-tensioner
Make DENSO
Type* StandardFXE20HE11C
Gap (nominal) 1.1 (0.043)
Cylinder arrangement V-6
Displacement cm
3 (cu in) 3,498 (213.45)
Bore and stroke mm (in) 95.5 x 81.4 (3.760 x 3.205)
Valve arrangement DOHC
Firing order 1-2-3-4-5-6
Number of piston rings Compression 2
Oil 1
Number of main bearings 4
Compression ratio 10.3:1
Compression pressure
kPa (kg/cm
2, psi)/300 rpm Standard 1,275 (13.0, 185)
Minimum
981 (10.0, 142)
Differential limit between cylinders 98 (1.0, 14)

EC-86
< SYSTEM DESCRIPTION >[QR25DE]
DIAGNOSIS SYSTEM (ECM)
*: Leaving cooling fan OFF with CONSULT while engine is running may cause the engine to overheat.
DTC WORK SUPPORT MODE
DTC WORK SUPPORT Mode
ALTERNATOR
DUTY • Engine: Idle
• Change duty ratio using CON-
SULT. Battery voltage changes.
• Harness and connectors
•IPDM E/R
•Alternator
FUEL PUMP RELAY • Ignition switch: ON (Engine
stopped)
• Turn the fuel pump relay “ON”
and “OFF” using CONSULT and
listen to operating sound. Fuel pump relay makes the operat-
ing sound. • Harness and connectors
• Fuel pump relay
VIAS S/V-1 • Ignition switch: ON
• Turn intake manifold tuning valve
“ON” and “OFF” using CONSULT
and listen to operating sound. Intake manifold tuning valve motor
makes an operating sound. • Harness and connectors
• Intake manifold tuning valve mo- tor
TUMBLE CONTROL
VA LV E • Ignition switch: ON
• Turn intake manifold runner con-
trol valve “ON” and “OFF” using
CONSULT and listen to operating
sound. Intake Manifold Runner control
valve motor makes an operating
sound. • Harness and connectors
• Intake Manifold Runner control valve motor
IGNITION TIMING • Engine: Return to the original
trouble condition
• Timing light: Set
• Retard the ignition timing using
CONSULT. If trouble symptom disappears, see
CHECK ITEM. • Perform Idle Air Volume Learn-
ing.
POWER BALANCE • Engine: After warming up, idle the
engine.
• A/C switch OFF
• Selector lever: P or N
• Cut off each fuel injector signal one at a time using CONSULT. Engine runs rough or stops. • Harness and connectors
• Compression
• Fuel injector
• Power transistor
• Spark plug
• Ignition coil
VENT CONTROL/V • Ignition switch: ON (Engine
stopped)
• Turn solenoid valve “ON” and “OFF” using CONSULT and listen
to operating sound. Solenoid valve makes an operating
sound. • Harness and connectors
• Solenoid valve
INT V/T ASSIGN AN-
GLE • Engine: Return to the original
trouble condition
• Change intake valve timing using
CONSULT. If trouble symptom disappears, see
CHECK ITEM. • Harness and connectors
• Intake valve timing control sole- noid valve
EXH V/T ASSIGN
ANGLE • Engine: Return to the original
trouble condition
• Change exhaust valve timing us- ing CONSULT. If trouble symptom disappears, see
CHECK ITEM. • Harness and connectors
• Exhaust valve timing control so-
lenoid valve
COOLING FAN* • Ignition switch: ON
• Turn the cooling fan “LOW”, “HI” and “OFF” using CONSULT. Cooling fan moves and stops. • Harness and connectors
• IPDM E/R (Cooling fan relay)
• Cooling fan motor
Test item Condition Judgment Check item (Remedy)
Test mode Test item Corresponding DTC No. Reference page
EVAPORATIVE SYSTEM PURG FLOW P0441 P0441
EC-337
PURG VOL CN/V P1444 P0443EC-342
A/F SEN1 A/F SEN1(B1) P1276 P0130 EC-258
HO2S2HO2S2(B1) P1146 P0138
EC-274HO2S2(B1) P1147 P0137EC-268
HO2S2(B1) P0139 P0139EC-282
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-318
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P0300, P0301,
P0302, P0303, P0304 MISFIRE
P0300, P0301, P0302, P0303, P0304 MISFIRE
DTC LogicINFOID:0000000009462255
DTC DETECTION LOGIC
When a misfire occurs, engine speed will fluctuate. If the engine speed fluctuates enough to cause the crank-
shaft position (CKP) sensor (POS) signal to vary , ECM can determine that a misfire is occurring.
The misfire detection logic consists of the following two conditions.
1. One Trip Detection Logic (Three Way Catalyst Damage) On the 1st trip, when a misfire condition occurs that can damage the three way catalyst (TWC) due to
overheating, the MIL will blink.
When a misfire condition occurs, the ECM monitors the CKP sensor signal every 200 engine revolutions
for a change.
When the misfire condition decreases to a level that will not damage the TWC, the MIL will turn off.
If another misfire condition occurs that can dam age the TWC on a second trip, the MIL will blink.
When the misfire condition decreases to a level that will not damage the TWC, the MIL will remain on.
If another misfire condition occurs that can damage the TWC, the MIL will begin to blink again.
2. Two Trip Detection Logic (Exhaust quality deterioration) For misfire conditions that will not damage the TWC (but will affect vehicle emissions), the MIL will only
light when the misfire is detected on a second trip. Du ring this condition, the ECM monitors the CKP sen-
sor signal every 1,000 engine revolutions.
A misfire malfunction can be detected on any one cylinder or on multiple cylinders.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-1
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Restart engine and let it idle for about 15 minutes.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-319, "Diagnosis Procedure".
Sensor Input signal to ECM ECM function
Crankshaft position sensor (POS) Engine speed On board diagnosis of misfire
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P0300 MULTI CYL MISFIRE
(Random/multiple cylinder misfire detected) Multiple cylinder misfire.
• Improper spark plug
• Insufficient compression
• Incorrect fuel pressure
• Fuel Injector circuit is open or shorted
• Fuel injector
• Intake air leak
• Ignition signal circuit is open or shorted
• Lack of fuel
• Signal plate
• A/F sensor 1
• Incorrect PCV hose connection
P0301
CYL 1 MISFIRE
(Cylinder 1 Misfire Detected) No. 1 cylinder misfires.
P0302 CYL 2 MISFIRE
(Cylinder 2 Misfire Detected) No. 2 cylinder misfires.
P0303 CYL 3 MISFIRE
(Cylinder 3 Misfire Detected) No. 3 cylinder misfires.
P0304 CYL 4 MISFIRE
(Cylinder 4 Misfire Detected) No. 4 cylinder misfires.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P117A AIR FUEL RATIOEC-417
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P117A AIR FUEL RATIO
DTC LogicINFOID:0000000009462347
DTC DETECTION LOGIC
NOTE:
If DTC P117A is displayed with other DTC, first perf orm the trouble diagnosis for the other DTC. Refer
to EC-105, "DTC Index"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING-1
If DTC Confirmation Procedure has been previously conduc ted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
NOTE:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PRECONDITIONING-2
1. Turn ignition switch ON.
2. Clear the mixture ratio self-learning value. Refer to EC-181, "Work Procedure"
.
Will CONSULT be used?
YES >> GO TO 3.
NO >> GO TO 6.
3.PERFORM DTC CONFIRMATION PROCEDURE-1
1. Turn ignition switch ON.
2. Select “COOLAN TEMP/S” in “DATA MONI TOR” mode of “ENGINE” using CONSULT.
3. Start engine.
4. Make sure that “COOLAN TEMP/S” indicates more than 80 °C (176 °F).
>> GO TO 4.
4.PERFORM DTC CONFIRMATION PROCEDURE-2
With CONSULT
1. Select “SYSTEM 1 DIAGNOSIS B B1” and “SYSTEM 1 DIAGNOSIS A B1” in “DATA MONITOR” mode of
“ENGINE” using CONSULT.
2. Drive vehicle under the following conditions for at least 5 consecutive seconds.
CAUTION:
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P117A AIR FUEL RATIO B1
(AIR FUEL RATIO B1) ECM detects a lean/rich air fuel ratio state in any
cylinder for a specified length of time. • Fuel injector
• Exhaust gas leaks
• Incorrect fuel pressure
• Mass air flow sensor
• Intake air leaks
• Lack of fuel
• Incorrect PCV hose connection
• Improper spark plug
• Insufficient compression
• The fuel injector circuit is open or shorted
• ignition coil
• The ignition signal circuit is open or shorted
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-420
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P117A AIR FUEL RATIO
Perform the following procedure in a place with
no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Confirm that the engine is cooled down and there are no fire hazards near the vehicle.
3. Disconnect all fuel injector harness connectors.
4. Remove fuel tube assembly. Refer to EM-41, "Removal and Installation"
.
Keep fuel hose and all fuel injectors connected to fuel tube.
5. Disconnect all ignition coil harness connectors.
6. Prepare pans or saucers under each fuel injector.
7. Crank engine for approximately 3 seconds.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace fuel injector. Refer to EM-41, "Removal and
Installation".
7.CHECK FUNCTION OF IGNITION COIL-1
CAUTION:
Perform the following steps in a well -ventilated area with no combustibles.
1. Turn ignition switch OFF.
2. Remove fuel pump fuse from IPDM E/R to release fuel pressure.
NOTE:
CONSULT must not be used to release fuel pressu re. It develops again during the following steps,
if released by using CONSULT.
3. Start the engine.
4. After an engine stall, crank the engine two or three times to release all the fuel pressure.
5. Turn ignition switch OFF.
6. Disconnect all the harness connectors of ignition coil to prevent electric discharge from occurring in igni-
tion coil.
7. Remove ignition coil assembly and spark plug of cylinder. Refer to EM-40, "Removal and Installation"
.
8. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
9. Connect spark plug and harness connector to ignition coil.
10. Allow a 13-17mm (0.52-0.66 in) spacing between spark plug and
grounded metal portion as shown in the figure to fix the ignition
coil with a rope or an equivalent.
11. Crank the engine for approximately 3 seconds to see if sparking occurs between spark plug and the grounded metal portion.
CAUTION:
• The discharge voltage becomes 20 kV or higher. There- fore, always stay away from the spark plug and ignition
coil at least 50 cm (19.7 in) during the inspection.
• Leaving a space of more than 17mm (0.66 in) may damage the ignition coil.
NOTE:
When the gap is less than 13 mm (0.52 in), a the sp ark might be generated even if the coil is mal-
functioning.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 10.
8.CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-26, "Compression pressure"
.
Is the inspection result normal?
• Fuel should be sprayed evenly for each fuel injector.
• Fuel must not drip from the tip of fuel injector.
PBIA9666J
Spark should be generated.
JMBIA0066GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P0300, P0301, P0302, P0303, P0304, P0305, P0306 MISFIRE
EC-809
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
P0300, P0301, P0302, P0303,
P0304, P0305, P0306 MISFIRE
DTC LogicINFOID:0000000009462666
DTC DETECTION LOGIC
When a misfire occurs, engine speed will fluctuate. If the engine speed fluctuates enough to cause the crank-
shaft position (CKP) sensor (POS) signal to vary , ECM can determine that a misfire is occurring.
The misfire detection logic consists of the following two conditions.
1. One Trip Detection Logic (Three Way Catalyst Damage) On the 1st trip, when a misfire condition occurs that can damage the three way catalyst (TWC) due to
overheating, the MIL will blink.
When a misfire condition occurs, the ECM monitors the CKP sensor signal every 200 engine revolutions
for a change.
When the misfire condition decreases to a level t hat will not damage the TWC, the MIL will turn off.
If another misfire condition occurs that can damage the TWC on a second trip, the MIL will blink.
When the misfire condition decreases to a level t hat will not damage the TWC, the MIL will remain on.
If another misfire condition occurs that can damage the TWC, the MIL will begin to blink again.
2. Two Trip Detection Logic (Exhaust quality deterioration) For misfire conditions that will not damage the TWC (but will affect vehicle emissions), the MIL will only
illuminate when the misfire is detected on a second tr ip. During this condition, the ECM monitors the CKP
sensor signal every 1,000 engine revolutions.
A misfire malfunction can be detected in any one cylinder or in multiple cylinders.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and let it idle for approximately 15 minutes.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
Sensor Input signal to ECM ECM function
Crankshaft position sensor (POS) Engine speed On board diagnosis of misfire
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0300 Multiple cylinder misfires detected Multiple cylinders misfire. • Improper spark plug • Insufficient compression
• Incorrect fuel pressure
• The fuel injector circuit is open or shorted
• Fuel injector
• Intake air leakage
• The ignition signal circuit is open or shorted
• Lack of fuel
• Signal plate
• A/F sensor 1
• Incorrect PCV hose connection
P0301 No. 1 cylinder misfire detected No. 1 cylinder misfires.
P0302 No. 2 cylinder misfire detected No. 2 cylinder misfires.
P0303 No. 3 cylinder misfire detected No. 3 cylinder misfires.
P0304 No. 4 cylinder misfire detected No. 4 cylinder misfires.
P0305 No. 5 cylinder misfire detected No. 5 cylinder misfires.
P0306 No. 6 cylinder misfire detected No. 6 cylinder misfires.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EM-1
ENGINE
C
D E
F
G H
I
J
K L
M
SECTION EM
A
EM
N
O P
CONTENTS
ENGINE MECHANICAL
QR25DE
PRECAUTION ................ ...............................
4
PRECAUTIONS .............................................. .....4
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
4
Precaution for Draining Coolant ................................4
Precaution for Disconnecting Fuel Piping .................4
Precaution for Removal and Disassembly ................4
Precaution for Inspection, Repair and Replace-
ment .................................................................... ......
4
Special Cautions to Ensure the Safe Disposal of
Sodium-filled Exhaust Valves .............................. ......
5
Precaution for Assembly and Installation ..................6
Parts Requiring Angular Tightening ..........................6
Precaution for Liquid Gasket ............................... ......6
PREPARATION ............................................8
PREPARATION .............................................. .....8
Special Service Tool ........................................... ......8
Commercial Service Tool ........................................10
SYMPTOM DIAGNOSIS ..............................13
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ ....
13
NVH Troubleshooting - Engine Noise ................. ....13
Use the Chart Below to Help You Find the Cause
of the Symptom ................................................... ....
14
PERIODIC MAINTENANCE .........................16
SPARK PLUG .. .............................................. ....16
Exploded View .................................................... ....16
Removal and Installation .........................................16
DRIVE BELTS ................................................ ....19
Exploded View .................................................... ....19
Checking Drive Belts ...............................................19
Tension Adjustment ............................................. ....19
Removal and Installation .........................................19
Removal and Installation of Drive Belt Auto-ten-
sioner ................................................................... ....
20
AIR CLEANER FILTER .....................................22
Exploded View .........................................................22
Removal and Installation .........................................22
CAMSHAFT VALVE CLEARANCE ..................23
Camshaft valve clearance .......................................23
COMPRESSION PRESSURE ...........................26
Compression pressure ............................................26
REMOVAL AND INSTALLATION ...............28
ENGINE ROOM COVER ...................................28
Exploded View ..................................................... ....28
Removal and Installation .........................................28
AIR CLEANER AND AIR DUCT .......................29
Exploded View .........................................................29
Removal and Installation .........................................29
INTAKE MANIFOLD .........................................30
Exploded View .........................................................30
Removal and Installation .........................................30
EXHAUST MANIFOLD AND THREE WAY
CATALYST ........................................................
33
Exploded View ..................................................... ....33
Removal and Installation .........................................33
OIL PAN AND OIL STRAINER .........................36
Exploded View .........................................................36
Removal and Installation .........................................36
IGNITION COIL .................................................40
Exploded View .........................................................40
Removal and Installation .........................................40
FUEL INJECTOR AND FUEL TUBE ................41
Revision: November 20132014 Altima NAM

EM-2
Exploded View ........................................................41
Removal and Installation ........................................41
ROCKER COVER ..............................................45
Exploded View ..................................................... ...45
Removal and Installation ........................................45
CAMSHAFT .......................................................47
Exploded View ..................................................... ...47
Removal and Installation ........................................47
Inspection After Installation ................................. ...56
VALVE TIMING CONTROL ............................ ...58
Exploded View ..................................................... ...58
Intake Valve Timing Intermediate Lock Control
Solenoid Valve, Intake Va lve Timing Control Sole-
noid Valve, and Exhaust Valve Timing Control So-
lenoid Valve ......................................................... ...
58
Valve Timing Control Cover ....................................59
TIMING CHAIN ............................................... ...61
Exploded View ..................................................... ...61
Removal and Installation ........................................62
OIL SEAL ...........................................................70
Removal and Installation of Valve Oil Seal .......... ...70
Removal and Installation of Front Oil Seal .............71
Removal and Installation of Rear Oil Seal ..............72
CYLINDER HEAD ..............................................74
Exploded View ..................................................... ...74
Removal and Installation ........................................74
Disassembly and Assembly ....................................76
Inspection After Disassembly .................................78
UNIT REMOVAL AND INSTALLATION .. ...83
ENGINE ASSEMBLY ...................................... ...83
Exploded View ..................................................... ...83
Removal and Installation ........................................84
UNIT DISASSEMBLY AND ASSEMBLY ....87
CYLINDER BLOCK ........................................ ...87
Exploded View ..................................................... ...87
Disassembly and Assembly ....................................88
Inspection After Disassembly .................................96
HOW TO SELECT PISTON AND BEARING .. .105
How to Select Piston and Bearing ....................... ..105
SERVICE DATA AND SPECIFICATIONS
(SDS) .............. ............................................
111
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................... .
111
Standard and Limit .............................................. ..111
VQ35DE
PRECAUTION .............. ..............................
123
PRECAUTIONS .............................................. .123
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. .
123
Precaution for Draining Coolant ............................123
Precaution for Disconnecting Fuel Piping .............123
Precaution for Removal and Disassembly ............123
Precaution for Inspection, Repair and Replace-
ment ..................................................................... .
123
Precaution for Assembly and Installation ..............123
Parts Requiring Angular Tightening ..................... .124
Precaution for Liquid Gasket .................................124
PREPARATION .........................................126
PREPARATION .............................................. ..126
Special Service Tool ............................................ .126
Commercial Service Tool ......................................127
SYSTEM DESCRIPTION ..........................130
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING ......................... ..
130
NVH Troubleshooting - Engine Noise .................. .130
Use the Chart Below to Help You Find the Cause
of the Symptom .................................................... .
131
PERIODIC MAINTENANCE ......................132
SPARK PLUG ... .............................................. ..132
Exploded View ..................................................... .132
Removal and Installation .......................................132
DRIVE BELTS ................................................ ..134
Exploded View ..................................................... .134
Checking Drive Belts .............................................134
Tension Adjustment ..............................................134
Removal and Installation .......................................134
Removal and Installation of Drive Belt Auto-ten-
sioner ................................................................... .
135
AIR CLEANER FILTER ....................................137
Exploded View ..................................................... .137
Removal and Installation .......................................137
CAMSHAFT VALVE CLEARANCE ............... ..138
Valve Clearance ................................................... .138
COMPRESSION PRESSURE ..........................142
On-Vehicle Service .............................................. .142
REMOVAL AND INSTALLATION .............143
ENGINE ROOM COVER ................................ ..143
Exploded View ..................................................... .143
Removal and Installation .......................................143
AIR CLEANER AND AIR DUCT ..................... ..144
Exploded View ..................................................... .144
Removal and Installation .......................................144
INTAKE MANIFOLD COLLECTOR ............... ..146
Exploded View ..................................................... .146
Revision: November 20132014 Altima NAM
