Page 2057 of 4801
![NISSAN TEANA 2014 Service Manual
VALVE TIMING CONTROLEM-59
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Valve Timing Control CoverINFOID:0000000009460497
REMOVAL
1. Remove the intake valve timing intermedia NISSAN TEANA 2014 Service Manual
VALVE TIMING CONTROLEM-59
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Valve Timing Control CoverINFOID:0000000009460497
REMOVAL
1. Remove the intake valve timing intermedia](/manual-img/5/57390/w960_57390-2056.png)
VALVE TIMING CONTROLEM-59
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
Valve Timing Control CoverINFOID:0000000009460497
REMOVAL
1. Remove the intake valve timing intermediate lock control solenoid valve, intake valve timing control sole-
noid valve, exhaust valve timing control solenoid valve. Refer to EM-58, "Intake Valve Timing Intermediate
Lock Control Solenoid Valve, Intake Valve Timing Control Solenoid Valve, and Exhaust Valve Timing Con-
trol Solenoid Valve".
2. Remove harness grounds and retainers from the top if the engine mount bracket.
3. Loosen the valve timing control cover bolts in the reverse order shown.
a. Remove the valve timing control cover bolts.
b. Remove the valve timing control cover by cutting the liquid gas- ket using Tool (A).
NOTE:
Do not loosen screws (A) on the back of the valve timing control
cover.
INSTALLATION
1. Install valve timing control cover with the following procedure.
a. Install intake valve timing intermediate lock control solenoid valve, intake valve timing control solenoid
valve and exhaust valve timing control solenoid valve to valve timing control cover.
b. Install O-ring to front cover side. CAUTION:
Do not reuse O-ring.
ALBIA0839GB
Tool number : KV10111100 (J-37228)
AWBIA1257GB
AWBIA1361ZZ
Revision: November 20132014 Altima NAM
Page 2058 of 4801
EM-60
< REMOVAL AND INSTALLATION >[QR25DE]
VALVE TIMING CONTROL
c. Apply liquid gasket to the positions shown. Refer to
GI-21, "Rec-
ommended Chemical Products and Sealants".
d. Install valve timing control cover. • Tighten the bolts to specification in the numerical order shown.Diameter (A) : 3.4 - 4.4 mm (0.134 - 0.173 in)
AWBIA1362ZZ
ALBIA0839GB
Revision: November 20132014 Altima NAM
Page 2059 of 4801
![NISSAN TEANA 2014 Service Manual
TIMING CHAINEM-61
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
TIMING CHAIN
Exploded ViewINFOID:0000000009460498
1. O-rings 2. Timing chain slack guide 3. Chain tensioner
4 NISSAN TEANA 2014 Service Manual
TIMING CHAINEM-61
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
TIMING CHAIN
Exploded ViewINFOID:0000000009460498
1. O-rings 2. Timing chain slack guide 3. Chain tensioner
4](/manual-img/5/57390/w960_57390-2058.png)
TIMING CHAINEM-61
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
TIMING CHAIN
Exploded ViewINFOID:0000000009460498
1. O-rings 2. Timing chain slack guide 3. Chain tensioner
4. Timing chain 5. Camshaft sprocket (EXH) 6. Camshaft sprocket (INT)
7. Oil filter 8. Front cover 9. Oil pressure sensor
10. Valve timing control cover O-rings (EXH) 11. Valve timing co
ntrol cover O-rings
(INT) 12. Valve timing control cover
13. Valve timing control solenoid valve O- rings 14. Intake valve timing intermediate lock-
control solenoid valve 15. Intake valve timing control sole-
noid valve
16. Exhaust valve timing control solenoid valve 17. Crankshaft pulley bolt 18. Crankshaft pulley
19. Front oil seal 20. Balancer unit timing chain 21. Balancer unit sprocket
22. Balancer unit 23. Timing chain tension guide 24. Balancer unit timing chain ten- sioner
25. Crankshaft sprocket 26. Oil pump drive spacer A. Follow the installation procedure
ALBIA0937ZZ
Revision: November 20132014 Altima NAM
Page 2060 of 4801
![NISSAN TEANA 2014 Service Manual
EM-62
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
Removal and Installation
INFOID:0000000009460499
CAUTION:
Apply new engine oil to parts as indicated in the illustration before installation. NISSAN TEANA 2014 Service Manual
EM-62
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
Removal and Installation
INFOID:0000000009460499
CAUTION:
Apply new engine oil to parts as indicated in the illustration before installation.](/manual-img/5/57390/w960_57390-2059.png)
EM-62
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
Removal and Installation
INFOID:0000000009460499
CAUTION:
Apply new engine oil to parts as indicated in the illustration before installation.
REMOVAL
1. Remove the engine and transaxle assembly. Refer to EM-84, "Removal and Installation".
2. Separate the engine from the transaxle assembly. Refer to EM-84, "Removal and Installation"
.
3. Remove the drive plate assembly if using an engine stand that attaches to the rear of the engine block.
4. Install engine to a suitable engine stand.
5. Remove the upper and lower oil pan, oil strainer, and O-ring. Refer to EM-36, "Removal and Installation"
.
6. Remove generator and bracket. Refer to CHG-32, "Removal and Installation"
.
7. Remove the engine mount bracket. Refer to EM-84, "Removal and Installation"
.
8. Set the No.1 cylinder at TDC on the compression stroke using the following procedure:
a. Rotate the crankshaft pulley clockwise and align the mating mark (B) to the timing indicator (A) on the front cover.
NOTE:
Do not use the white paint marks (C).
b. At the same time, make sure that the camshaft sprocket mating marks (B) line up with the painted marks on the timing chain (A).
• If not lined up, rotate the crankshaft pulley one more turn to line up the mating marks to the positions as shown.
9. Remove crankshaft pulley (1) using the following procedure:
a. Hold the crankshaft pulley (1) using suitable tool (A), then loosen and remove the crankshaft pulley bolt.
ALBIA0840GB
ALBIA0841GB
ALBIA0857GB
Revision: November 20132014 Altima NAM
Page 2061 of 4801
TIMING CHAINEM-63
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
b. Attach suitable tool (A) in the
M 6 (0.24 in diameter) thread hole
on crankshaft pulley (1), and remove crankshaft pulley.
10. Remove the intake valve timing control cover. Refer to EM-59, "Valve Timing Control Cover"
.
11. Remove the front cover using the following procedure:
a. Loosen the bolts in reverse order as shown, and remove them.
b. Cut liquid gasket using Tool (A). CAUTION:
Be careful not to damage the front cover.
c. Remove the front cover.
d. Remove front oil seal using suitable tool, (if necessary). CAUTION:
Be careful not to damage the front cover.
12. Remove timing chain tensioner (primary) and timing chain using the following procedure:
a. Pull the lever down and release the plunger stopper tab.
ALBIA0858GB
(A) : Dowel pin
ALBIA0944ZZ
Tool number : KV10111100 (J-37228)
AWBIA1257GB
Revision: November 20132014 Altima NAM
Page 2062 of 4801
![NISSAN TEANA 2014 Service Manual
EM-64
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Plunger stopper tab can be pushed up to release (coaxial
structure with lever).
b. Insert the stopper pin into the tensioner body hole to h NISSAN TEANA 2014 Service Manual
EM-64
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Plunger stopper tab can be pushed up to release (coaxial
structure with lever).
b. Insert the stopper pin into the tensioner body hole to h](/manual-img/5/57390/w960_57390-2061.png)
EM-64
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Plunger stopper tab can be pushed up to release (coaxial
structure with lever).
b. Insert the stopper pin into the tensioner body hole to hold the lever and keep tab released.
NOTE:
Allen wrench [2.5 mm (0.098)] is used for a stopper pin as an
example.
c. Insert plunger into tensioner body by pressing slack guide.
d. Keep slack the guide pressed and hold it by pushing the stopper pin through the lever hole and body hole.
e. Remove the bolts and remove the timing chain tensioner (pri- mary).
f. Remove the timing chain. CAUTION:
Do not rotate the crankshaft or camshafts while the timing chain is removed. It can cause damage
to the valve and piston.
13. Remove the camshaft sprockets using the following procedure:
a. Secure hexagonal part of the camshaft with a wrench and loosen the camshaft sprocket bolt.
b. Remove the camshaft sprocket bolt and camshaft sprockets for both camshafts.
14. Remove the chain slack guide, tension guide, and oil pump drive spacer.
PBIC2107E
PBIC2108E
ALBIA0844GB
Revision: November 20132014 Altima NAM
Page 2063 of 4801
![NISSAN TEANA 2014 Service Manual
TIMING CHAINEM-65
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
15. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain NISSAN TEANA 2014 Service Manual
TIMING CHAINEM-65
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
15. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain](/manual-img/5/57390/w960_57390-2062.png)
TIMING CHAINEM-65
< REMOVAL AND INSTALLATION > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EM
NP
O
15. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain tensioner (1) for the
balancer unit.
• The slack guide (B) is released by pressing the stopper tab
(A). As a result, the slack guide (B) can be moved.
16. Insert stopper pin (D) into tensioner body hole (C) to secure tim- ing chain slack guide (B).
NOTE:
Use a hard metal pin with a diameter of approximately 1.2 mm
(0.047 in) as a stopper pin.
17. Remove timing chain tensioner (1) for balancer unit.
18. Secure width across flats of the balancer unit LH side shaft using a suitable tool. Loosen the balancer unit sprocket bolt.
19. Remove balancer unit timing chain, balancer unit sprocket and crankshaft sprocket.
20. Loosen bolts in the reverse order shown, and remove balancer unit.
CAUTION:
• Do not disassemble balancer unit.
INSPECTION AFTER REMOVAL
Timing Chain
Check the timing chain for cracks or excessive wear. If a defect is
found, replace the timing chain.
Balancer Unit Bo lt Outer Diameter
PBIC5314E
: Engine front
AWBIA1380ZZ
PBIC0282E
Revision: November 20132014 Altima NAM
Page 2064 of 4801
![NISSAN TEANA 2014 Service Manual
EM-66
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Measure outer diameters (d1, d2)
at the two positions as shown.
• Measure d2 within the range (A).
• If the value difference (d1 - d2 NISSAN TEANA 2014 Service Manual
EM-66
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Measure outer diameters (d1, d2)
at the two positions as shown.
• Measure d2 within the range (A).
• If the value difference (d1 - d2](/manual-img/5/57390/w960_57390-2063.png)
EM-66
< REMOVAL AND INSTALLATION >[QR25DE]
TIMING CHAIN
• Measure outer diameters (d1, d2)
at the two positions as shown.
• Measure d2 within the range (A).
• If the value difference (d1 - d2) exceeds the limit, replace the bal-
ancer unit bolt with a new one.
INSTALLATION
1. Make sure the crankshaft key points straight up.
2. Install the balancer unit and tighten the bolts in the numerical order as shown:
CAUTION:
• When reusing a bolt, check its outer diameter before installation. Follow the Balan cer Unit Bolt Outer Diameter
procedure.
• Apply new engine oil to threads and seating surfaces of bolts.
• Check tightening angle with an angle wrench (A) or a pro- tractor. Do not make judgme nt by visual check alone.
3. Install the crankshaft sprocket (1) and timing chain (2) for the balancer unit.
• Make sure that the crankshaft sprocket (1) is positioned with
mating marks (A) on the block and sprocket meeting at the
top.
• Install it by lining up mating marks on each sprocket (A), (C) and timing chain (B), (D).
• (B): Pink link
• (D): Yellow link Limit : 0.15 mm (0. 0059 in) or more
KBIA0126E
: Engine front
AWBIA1324GB
Tool number : KV10112100 (BT-8653-A)
Step 1 Bolts 1-5 : 42 N·m (4.3 kg-m, 31 ft-lb)
Bolt 6 : 36 N·m (3.7 kg-m, 27 ft-lb)
Step 2 Bolts 1-5 : 120
° + 5 °
Bolt 6 : 90 ° + 5 °
Step 3 Loosen in reverse order : 0 N·m (0 kg-m, 0 ft-lb)
Step 4 Bolts 1-5 : 42 N·m (4.3 kg-m, 31 ft-lb)
Bolt 6 : 36 N·m (3.7 kg-m, 27 ft-lb)
Step 5 Bolts 1-5 : 120
° + 5 °
Bolt 6 : 90 ° + 5 °
ALBIA0201ZZ
ALBIA0860GB
Revision: November 20132014 Altima NAM
