2014 NISSAN TEANA Service Manual

set clock navigation rear entertainment jacking power steering window

Page 1969 of 4801

NISSAN TEANA 2014 Service Manual
IGNITION SIGNALEC-969
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness or connectors.
7.CHECK IGNI

Page 1970 of 4801

NISSAN TEANA 2014 Service Manual
EC-970
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
IGNITION SIGNAL
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident".
NO >> Replace malfunctioning ig

EC-970
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
IGNITION SIGNAL
Is the inspection result normal?
YES >> Check intermittent incident. Refer to
GI-43, "Intermittent Incident".
NO >> Replace malfunctioning ignition coil with power transistor. Refer to EM-162, "Removal and Instal-
lation LH" or EM-162, "Removal and Installation RH".
Component Inspection (Igniti on Coil with Power Transistor)INFOID:0000000009462850
1.CHECK IGNITION COIL WITH POWER TRANSISTOR-I
1. Turn ignition switch OFF.
2. Disconnect ignition coil harness connector.
3. Check resistance between ignition coil terminals as per the following.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace malfunctioning ignition coil with power transistor. Refer to EM-162, "Removal and Instal-
lation LH" or EM-162, "Removal and Installation RH".
2.CHECK IGNITION COIL WITH POWER TRANSISTOR-II
CAUTION:
Perform the following procedure in a place with no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Remove fuel pump fuse in IPDM E/R to release fuel pressure.
NOTE:
Do not use CONSULT to release fuel pressure, or fuel pressure applies again during the following proce-
dure.
4. Start engine.
5. After engine stalls, crank it 2 or 3 times to release all fuel pressure.
6. Turn ignition switch OFF.
7. Remove all ignition coil harness connectors to avoi d the electrical discharge from the ignition coils.
8. Remove ignition coil and spark plug of the cylinder to be checked.
9. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
10. Connect spark plug and harness connector to ignition coil.
11. Fix ignition coil using a rope etc. with gap of 13 - 17 mm (0.52 - 0.66 in) between the edge of the spark plug and grounded metal
portion as shown in the figure.
12. Crank engine for approximately 3 seconds, and check whether spark is generated between the spark plug and the grounded
metal portion.
CAUTION:
• During the operation, always stay 0.5 m (19.7 in) or more
away from the spark plug and the ignition coil. Be careful
not to get an electrical s hock while checking, because the
electrical discharge voltage becomes 20 kV or more.
• It might cause to damage the igni tion coil if the gap of more than 17 mm (0.66 in) is taken.
NOTE:
When the gap is less than 13 mm (0.52 in), the sp ark might be generated even if the coil is mal-
functioning.
Is the inspection result normal?
YES >> INSPECTION END
Terminal No. (Polarity) Resistance Ω [at 25 °C (77 °F)]
1 and 2 Except 0 or ∞
1 and 3 Except 0
2 and 3
Spark should be generated.
JMBIA0066GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1971 of 4801

NISSAN TEANA 2014 Service Manual
IGNITION SIGNALEC-971
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Replace malfunctioning ignition coil with power transistor. Refer to
EM-162, "Removal and Instal-
lati

Page 1972 of 4801

NISSAN TEANA 2014 Service Manual
EC-972
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
INFORMATION DISPLAY (ASCD)
INFORMATION DISPLAY (ASCD)
Component Function CheckINFOID:0000000009462852
1.CHECK INFORMATION DISPLAY
1. Start engine.
2. Press M

Page 1973 of 4801

NISSAN TEANA 2014 Service Manual
MALFUNCTION INDICATOR LAMPEC-973
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
MALFUNCTION INDICATOR LAMP
Component Function CheckINFOID:0000000009462854
1.CHECK MIL FUNCTION
1.

Page 1974 of 4801

NISSAN TEANA 2014 Service Manual
EC-974
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Component Function CheckINFOID:0000000009462856
1.CHECK ORVR FUNCTION
Check

Page 1975 of 4801

NISSAN TEANA 2014 Service Manual
ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-975
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace refueling EVAP

ON BOARD REFUELING VAPOR RECOVERY (ORVR)EC-975
< DTC/CIRCUIT DIAGNOSIS > [VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace refueling EVAP vapor cut valve with fuel tank. Refer to FL-10, "Removal and Installation"
.
7.CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent c ontrol valve and EVAP control system pressure sensor
attached. Refer to FL-14, "Removal and Installation"
.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be l ess than 2.1 kg (4.6 lb).
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 9.
8.CHECK IF EVAP CANISTER IS SATURATED WITH WATER
Check if water will drain from EVAP canister.
Does water drain from the EVAP canister?
YES >> GO TO 6.
NO >> GO TO 11.
9.REPLACE EVAP CANISTER
Replace EVAP canister with a new one. Refer to FL-14, "Removal and Installation"
.
>> GO TO 10.
10.DETECT MALFUNCTIONING PART
Check the EVAP hose between EVAP canister and vehicle frame for clogging or poor connection.
>> Repair or replace EVAP hose. Refer to FL-16, "Removal and Installation"
.
11 .CHECK VENT HOSES AND VENT TUBES
Check hoses and tubes between EVAP c anister and refueling control valve for clogging, kinks, looseness and
improper connection.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace hoses and tubes.
12.CHECK FILLER NECK TUBE
Check recirculation line for clogging, dents and cracks.
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace filler neck tube.
13.CHECK REFUELING EVAP VAPOR CUT VALVE
Check refueling EVAP vapor cut valve. Refer to EC-976, "Component Inspection"
.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace refueling EVAP vapor cut valve with fuel tank. Refer to FL-10, "Removal and Installation"
.
14.CHECK FUEL FILLER TUBE
Check filler neck tube and hose connected to the fuel tank for clogging, dents and cracks.
JMBIA1134GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 1976 of 4801

NISSAN TEANA 2014 Service Manual
EC-976
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace fuel filler tube. Refer to FL-10, "Removal and Inst

EC-976
< DTC/CIRCUIT DIAGNOSIS >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace fuel filler tube. Refer to FL-10, "Removal and Installation"
.
15.CHECK ONE-WAY FUEL VALVE-I
Check one-way valve for clogging.
Is the inspection result normal?
YES >> GO TO 16.
NO >> Repair or replace one-way fuel valve with fuel tank. Refer to FL-10, "Removal and Installation"
.
16.CHECK ONE-WAY FUEL VALVE-II
1. Check that fuel is drained from the tank.
2. Remove fuel filler tube and hose. Refer to FL-10, "Removal and Installation"
.
3. Check one-way fuel valve for operation as per the following.
When a stick is inserted, the valve should open, when removing
stick it should close.
Do not drop any material into the tank.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace fuel filler tube or replace one-way fuel valve
with fuel tank. Refer to FL-10, "Removal and Installa-
tion".
Component InspectionINFOID:0000000009462858
1.INSPECTION START
Will CONSULT be used?
Will CONSULT be used?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK REFUELING EVAP VAPOR CUT VALVE
With CONSULT
1. Turn ignition switch OFF.
2. Remove fuel tank. Refer to FL-10, "Removal and Installation"
.
3. Drain fuel from the tank as per the following:
- Remove fuel feed hose located on the fuel gauge retainer. Refer to FL-10, "Removal and Installation"
.
- Connect a spare fuel hose, one side to fuel gauge re tainer where the hose was removed and the other
side to a fuel container.
- Drain fuel using “FUEL PUMP RELAY” in “ACTIVE TEST” mode with CONSULT.
4. Check refueling EVAP vapor cut valve for being stuck to close as per the following. Blow air into the refueling EVAP vapor cut valv e (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
5. Check refueling EVAP vapor cut valve for being stuck to open as per the following.
- Connect vacuum pump to hose end.
- Remove fuel gauge retainer with fuel gauge unit.
Always replace O-ri ng with new one.
- Turn fuel tank upside down.
- Apply vacuum pressure to hose end [ −13.3 kPa ( −0.136 kg/cm
2, −1.93 psi)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
SEF665U
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
