Page 3545 of 4801

NISSAN TEANA 2014 Service Manual
PWC-38
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
3. CHECK HARNESS CONTINUITY
(REAR POWER WINDOW SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main

PWC-38
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER SUPPLY AND GROUND CIRCUIT
3. CHECK HARNESS CONTINUITY
(REAR POWER WINDOW SWITCH RH)
1. Turn ignition switch OFF.
2. Disconnect main power window and door lock/unl ock switch and rear power window switch RH.
3. Check continuity between main power window and door lock/unlock switch connector and rear power win-
dow switch RH connector.
4. Check continuity between main power window and door lock/unlock switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the harness or connectors.
4. CHECK HARNESS CONTINUITY
1. Disconnect BCM, power window and door lock/unlock s witch RH, rear power window switch LH and rear
power window switch RH.
2. Check continuity between BCM connector and rear power window switch connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-80, "Removal and Installation".
NO >> Repair or replace harness or connectors.
5. CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Refer to PWC-38, "REAR POWER WINDOW SWITCH : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace rear power window switch. Refer to PWC-67, "Removal and Installation"
.
REAR POWER WINDOW SWITCH : Component InspectionINFOID:0000000009460847
COMPONENT INSPECTION
1. CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Main power window and door lock/ unlock switch connector Te r m i n a lRear power window switch
RH connector Terminal Continuity
D12 6
D303 7
Ye s
78
Main power window and door lock/un- lock switch connector Te r m i n a l
GroundContinuity
D12 6
No
7
BCM
connector Terminal Rear power window switch connector Terminal Continuity
M21 140 LH D203
4Yes
RH D303
BCM connector Terminal GroundContinuity
M21 140 No
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3546 of 4801

NISSAN TEANA 2014 Service Manual
POWER SUPPLY AND GROUND CIRCUITPWC-39
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Rear power window switch is OK.

Page 3547 of 4801

NISSAN TEANA 2014 Service Manual
PWC-40
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
POWER WINDOW MOTOR
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000009460848
Door glass moves UP/DOWN by receiving the

Page 3548 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-41
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace main power window and door lock/unloc

POWER WINDOW MOTORPWC-41
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace main power window and door lock/unlock switch. Refer to PWC-65, "Removal and Instal-
lation". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
NO >> Repair or replace harness.
3. CHECK FRONT POWER WINDOW MOTOR LH
Check front power window motor LH.
Refer to PWC-41, "DRIVER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace front power window motor LH. Refer to GW-16, "Removal and Installation - Front Regula-
tor". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
DRIVER SIDE : Component InspectionINFOID:0000000009460851
COMPONENT INSPECTION
1.CHECK FRONT POWER WINDOW MOTOR LH
Check motor operation by connecting the battery voltage directly to power window motor D9.
Is the inspection result normal?
YES >> Front power window motor LH is OK.
NO >> Replace front power window motor LH. Refer to GW-16, "Removal and Installation - Front Regula-
tor". After that, refer to PWC-41, "DRIVER SIDE : Special Repair Requirement".
DRIVER SIDE : Special Repair RequirementINFOID:0000000009460852
1. PERFORM INITIALIZATION PROCEDURE
Perform initialization procedure.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check intermittent incident. Refer to GI-43, "Intermittent Incident"
.
2. CHECK ANTI-PINCH OPERATION
Check anti-pinch operation.
Refer to PWC-27, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special
Repair Requirement".
Is the inspection result normal?
YES >> Inspection end.
NO >> Refer to PWC-40, "DRIVER SIDE : Component Function Check"
.
PASSENGER SIDE
Main power window and door lock/un-
lock switch connector Te r m i n a l
GroundContinuity
D8 17
No
19
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3549 of 4801

NISSAN TEANA 2014 Service Manual
PWC-42
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
PASSENGER SIDE : Description
INFOID:0000000009460853
Door glass moves UP/DOWN by receiving the signal from main power wi

PWC-42
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
PASSENGER SIDE : Description
INFOID:0000000009460853
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
power window and door lock/unlock switch RH.
PASSENGER SIDE : Component Function CheckINFOID:0000000009460854
1. CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT
Check front power window motor RH operation with main power window and door lock/unlock switch or power
window and door lock/unlock switch.
Is the inspection result normal?
YES >> Front power window motor RH is OK.
NO >> Refer to PWC-42, "PASSENGER SIDE : Diagnosis Procedure"
.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000009460855
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Front Power Window Motor RH Circuit Check
1. CHECK POWER WINDOW AND DOOR LO CK/UNLOCK SWITCH RH OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front power window motor RH.
3. Turn ignition switch ON.
4. Check voltage between front power window motor RH connector D111 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect power window and door lock/unlock switch RH.
3. Check continuity between power window and door lock/unlock switch RH connector D110 and front power
window motor RH connector D111.
4. Check continuity between power window and door lock/unlock switch connector D110 and ground.
Te r m i n a l
Front power window motor RH condition Voltage (V)
(Approx.)
(+)
(–)
Front power window motor RH
connector Te r m i n a l
D 111 1
Ground UP Battery voltage
DOWN 0
3 UP 0
DOWN Battery voltage
Power window and door lock/un- lock switch RH connector Te r m i n a l
Front power window motor RH
connector Terminal Continuity
D110 7
D 111 1
Ye s
63
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3550 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-43
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace power window and door lock/unlock swi

POWER WINDOW MOTORPWC-43
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Replace power window and door lock/unlock switch RH. Refer to PWC-65, "Removal and Installa-
tion".
NO >> Repair or replace the harness or connectors.
3. CHECK FRONT POWER WINDOW MOTOR RH
Check front power window motor RH.
Refer to PWC-43, "PASSENGER SIDE : Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator".
PASSENGER SIDE : Component InspectionINFOID:0000000009460856
COMPONENT INSPECTION
COMPONENT INSPECTION
1. CHECK FRONT POWER WINDOW MOTOR RH
Check motor operation by connecting the battery volt age directly to front power window motor RH D111.
Is the inspection result normal?
YES >> Power window motor is OK.
NO >> Replace front power window motor RH. Refer to GW-16, "Removal and Installation - Front Regu-
lator".
REAR LH
REAR LH : DescriptionINFOID:0000000009460857
Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or
rear power window switch LH.
REAR LH : Component Function CheckINFOID:0000000009460858
1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT
Check rear power window motor LH operation with main power window and door lock/unlock switch or rear
power window switch LH.
Is the inspection result normal?
YES >> Rear power window motor LH is OK.
NO >> Refer to PWC-43, "REAR LH : Diagnosis Procedure"
REAR LH : Diagnosis ProcedureINFOID:0000000009460859
Regarding Wiring Diagram information, refer to PWC-18, "Wiring Diagram - With Left Front Only Power Win-
dow Anti- Pinch".
Power window and door lock/unlock switch RH
connector Te r m i n a l
Ground Continuity
D110 7
No
6
Te r m i n a l Motor condition
(+) (–)
31 DOWN
13 UP
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

Page 3551 of 4801

NISSAN TEANA 2014 Service Manual
PWC-44
< DTC/CIRCUIT DIAGNOSIS >[LH FRONT ONLY ANTI-PINCH]
POWER WINDOW MOTOR
Rear Power Window Motor LH Circuit Check
1. CHECK REAR POWER WINDOW SWITCH LH OUTPUT SIGNAL
1. Turn ignition switch OFF.

Page 3552 of 4801

NISSAN TEANA 2014 Service Manual
POWER WINDOW MOTORPWC-45
< DTC/CIRCUIT DIAGNOSIS > [LH FRONT ONLY ANTI-PINCH]
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Is the inspection result normal?
YES >> Rear power window motor LH is OK.
NO >> Repl
