DAS-104
< BASIC INSPECTION >[LDW]
ACTION TEST
ACTION TEST
DescriptionINFOID:0000000009464737
• Perform action test to verify the customer's concern.
• Perform action test and check the syst em operation after system diagnosis.
WARNING:
Be careful of traffic conditions and safety ar ound the vehicle when performing road test.
CAUTION:
• Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-73, "Precaution for LDW System Service"
.
- System description for LDW: Refer to DAS-77, "System Description"
.
- System description for BSW: Refer to DAS-152, "System Description"
.
- System description for MOD: Refer to DAS-228, "System Description"
.
- Handling precaution: Refer to DAS-82, "Precautions for Lane Departure Warning"
.
Inspection ProcedureINFOID:0000000009464738
WARNING:
Be careful of traffic conditions and safety ar ound the vehicle when performing road test.
CAUTION:
• Fully understand the following it ems well before the road test;
- Precautions: Refer to DAS-73, "Precaution for LDW System Service"
.
- System description for LDW: Refer to DAS-77, "System Description"
.
- System description for BSW: Refer to DAS-152, "System Description"
.
- System description for MOD: Refer to DAS-228, "System Description"
.
- Handling precaution: Refer to DAS-232, "Precautions for Moving Objects Detection"
.
1.CHECK LDW SYSTEM SETTING
1. Start the engine.
2. Check that the LDW system setting can be enabled/disabled on the vehicle information display.
3. Turn OFF the ignition switch and wait for 30 seconds or more.
4. Check that the previous setting is saved when the engine starts again.
>> GO TO 2.
2.ACTION TEST FOR LDW
1. Enable the setting of the LDW system on the vehicle information display.
2. Turn warning systems switch ON (w arning systems ON indicator is ON).
3. Check the LDW operation according to the following table.
Vehicle condition/ Driver's operation Action Warning sys-
tems ON indi-
cator Indication on the combination
meter Buzzer
Less than
Approx. 60 km/h (40 MPH) Close to lane marker No action ON —
ALOIA0191GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 538 of 4801
DAS
ACTION TESTDAS-105
< BASIC INSPECTION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
NOTE:
After the operating conditions of warning are satisf ied, the warning continues until the vehicle speed
reaches approximately 60 km/h (40 MPH). Refer to DAS-77, "System Description"
.
>> Inspection End.
Approx. 70 km/h (45 MPH) or more Close to lane marker
Warning
• Buzzer sounds
• Warning lamp
blinks ON
Short contin-
uous beeps
• Close to lane marker
• Turn signal ON (Deviate side) No action ON —
Vehicle condition/ Driver's operation Action
Warning sys-
tems ON indi-
cator Indication on the combination
meter BuzzerALOIA0190GB
ALOIA0191GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 539 of 4801
![NISSAN TEANA 2014 Service Manual
DAS-106
< BASIC INSPECTION >[LDW]
ADDITIONAL SERVICE WHEN
REPLACING REAR VIEW CAMERA
ADDITIONAL SERVICE WHEN R EPLACING REAR VIEW CAMERA
DescriptionINFOID:0000000009464739
Always perform the calibra NISSAN TEANA 2014 Service Manual
DAS-106
< BASIC INSPECTION >[LDW]
ADDITIONAL SERVICE WHEN
REPLACING REAR VIEW CAMERA
ADDITIONAL SERVICE WHEN R EPLACING REAR VIEW CAMERA
DescriptionINFOID:0000000009464739
Always perform the calibra](/manual-img/5/57390/w960_57390-538.png)
DAS-106
< BASIC INSPECTION >[LDW]
ADDITIONAL SERVICE WHEN
REPLACING REAR VIEW CAMERA
ADDITIONAL SERVICE WHEN R EPLACING REAR VIEW CAMERA
DescriptionINFOID:0000000009464739
Always perform the calibration after removing and installing or replacing the rear view camera.
CAUTION:
The system does not operate normally unless the rear view camera aiming adjustment is performed.
Always perform it.
Work ProcedureINFOID:0000000009464740
1.CAMERA AIMING ADJUSTMENT
Perform the camera aiming adjustment with CONSULT. Refer to DAS-107, "Description"
.
>> GO TO 2.
2.PERFORM SELF-DIAGNOSIS
Perform the self-diagnosis of rear view camera with CONSULT. Check if any DTC is detected.
Is any DTC detected?
YES >> Perform the trouble diagnosis fo r the detected DTC. Refer to DAS-89, "DTC Index".
NO >> GO TO 3.
3.LDW/BSW SYSTEM ACTION TEST
1. Perform the LDW/BSW system action test. Refer to DAS-104, "Description"
.
2. Check that the LDW/BSW system operates normally.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 4.
4.LDW/BSW ACTIVE TEST
1. Perform WASH ACTIVE on Active Test using CONSULT.
2. Perform air and washer tube connection check by AIR & WASH ACTIVE on Active Test:
(1) Washer fluid output count on the rear view camera is 3 to 5 times → OK
(2) Washer fluid output count on the rear view camera is 10 times → Check tube with yellow marking
(3) Washer fluid output count on the rear view camera is 1 time → Check tube with green marking
(4) No washer fluid output → Check tube with blue marking or check valve
>> Inspection End.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 540 of 4801
![NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA CALIBRATIONDAS-107
< BASIC INSPECTION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
REAR VIEW CAMERA CALIBRATION
DescriptionINFOID:0000000009464741
Always perform the calibration after NISSAN TEANA 2014 Service Manual
DAS
REAR VIEW CAMERA CALIBRATIONDAS-107
< BASIC INSPECTION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
REAR VIEW CAMERA CALIBRATION
DescriptionINFOID:0000000009464741
Always perform the calibration after](/manual-img/5/57390/w960_57390-539.png)
DAS
REAR VIEW CAMERA CALIBRATIONDAS-107
< BASIC INSPECTION > [LDW]
C
D E
F
G H
I
J
K L
M B
N P
A
REAR VIEW CAMERA CALIBRATION
DescriptionINFOID:0000000009464741
Always perform the calibration after removing and installing or replacing the rear view camera.
CAUTION:
• Place the vehicle on level ground when the calibration is performed.
• Follow the CONSULT when performing the calib ration. (Rear view camera calibration cannot be
operated without CONSULT).
Work Procedure (Preparation)INFOID:0000000009464742
1.PERFORM SELF-DIAGNOSIS
Perform self-diagnosis of the ITS control unit.
Is any DTC detected?
Except "U1308">> Perform diagnosis on the detected DTC and repair or replace the applicable item. Refer to
DAS-89, "DTC Index"
.
"U1308" or no DTC>>GO TO 2.
2.PREPARATION BEFORE REAR VIEW CAMERA CALIBRATION
NOTE:
Select the "AVM" to diagnose the ITS control unit by CONSULT.
1. Perform pre-inspection for diagnosis. Refer to DAS-103, "Inspection Procedure"
.
2. Adjust the tire pressure to the specified pressure value.
3. Maintain no-load in vehicle.
4. Check if coolant and engine oil are filled up to correct level and fuel tank is full.
5. Situate vehicle where the camera is ex posed at an atmosphere temperature between 0 °C (32 °F) and
30 °C (86 °F)
6. Move the shift selector to P (Park) and release the parking brake.
7. Clean the rear view camera.
>> GO TO 3.
3.PREPARATION OF CALIBRATION TARGET MARK
Prepare the calibration target mark according to the following figure:
ALOIA0186ZZ
(1) : Left and right targets
(2) : Center target
(A) : Side of the black or white area = 200 mm (7.87 in)
(B) : Side of the square target = 400 mm (15.75 in)
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 541 of 4801
![NISSAN TEANA 2014 Service Manual
DAS-108
< BASIC INSPECTION >[LDW]
REAR VIEW CAMERA CALIBRATION
>> Refer to
DAS-108, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000009464743
CAUTION:
• Perform th NISSAN TEANA 2014 Service Manual
DAS-108
< BASIC INSPECTION >[LDW]
REAR VIEW CAMERA CALIBRATION
>> Refer to
DAS-108, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000009464743
CAUTION:
• Perform th](/manual-img/5/57390/w960_57390-540.png)
DAS-108
< BASIC INSPECTION >[LDW]
REAR VIEW CAMERA CALIBRATION
>> Refer to
DAS-108, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000009464743
CAUTION:
• Perform this operation in a horizo ntal position where there is a clear view for 3 m (9.84 ft) backward
and 4 m (13.12 ft) wide.
• Place the target in a well-lighted location. (Poor lighting may make it hard to adjust.)
• The target may not be detected when it shines by the reflected light of the sun or lighting.
• The target may not be detected when there is the same pattern of black and white as the target when
the pattern is within 0.5 m (1.64 ft) from either si de and upward/downward position from the target. (It
is desirable that the vehicle is positioned on a single-color floor.)
1.TA R G E T S E T T I N G
1. Mark points “A”, “B”, “C” and “D” at the center of the lateral sur-
